Radio | mains adaptor | quick start guide | safety/warranty leaet
Features
Controls
continued overleaf...
What is in the Box?
• DAB+ / FM RDS digital radio
• Bluetooth audio streaming from smartphone, tablet or laptop
• 20 radio station presets (10x DAB and 10x FM)
• AC adaptor included
• 40mm full range and 26mm tweeter with passive radiator
• LCD display with adjustable display brightness
• 2 alarms timers (DAB/FM/buzzer)
• Clock and sleep timer
• Stereo headphone output (3.5mm jack)
• USB charging of smartphone, tablet or similar device
A - Connect to the mains
ON
1 Power/ Volume/Sleep
2 Mode button
3 Brightness button
4 Ambient light sensor
5 Favourites button
6 Info/Menu button
7 Tuning, Select & Navigation
8 Alarm 1 button
9 Tweeter
10 Alarm 2 button
11 LCD display
12 Full range loudspeaker
13 USB 5V 1A output charging port
14 DC input socket
15 Passive radiator
16 Headphone socket
17 External aerial
1
10 11
1712 13
2
3
4
5 6
7
8 9
STEP 1 - Plug in & play DAB radio STEP 2 - Play FM radio
Please read the safety leaet provided before connecting
your radio to the mains.
1 Place your radio on a at surface.
2 Fully extend the aerial located on the bottom right hand
corner.
3 Plug the cable from the mains adaptor into the DC power input socket. Plug the mains adaptor
into a wall socket and switch on the socket.
4 A start up screen will be displayed and a scan of the Band III DAB channels will be carried out.
5 When a signal has been found, the current time will appear on the display.
Note: If no signals are found it may be necessary to relocate your radio to a position giving
better reception and carry out a scan for new stations.
B - Select a DAB radio station
1 If needed, press and release the button until the DAB Mode
mode is selected.
2 Rotate the Tuning control to step through the list of available
DAB stations.
3 Press the Tuning control to select the station. Adjust the Volume.
4 Some radio stations may have one or more additional broadcasts
associated with them. If these are available they will appear
immediately after the main station.
5 Press the button to cycle through the various display Info/Menu
options.
The display options are station name, scrolling text, program
type, multiplex name, channel / frequency, bit rate, signal
strength (the minimum signal marker ( ) shows the minimum
strength needed for good DAB reception), date.
STEP 4 - Bluetooth
1 Ensure Bluetooth is enabled on your smart device.
2 Ensure your radio is switched on. Press and release the Mode
button until the Bluetooth mode is selected on your radio.
3 The radio will show that it is ‘PAIRING’.
4 On your smart device select ‘Revival Rest’. Once the
connection is established, you may now play your music.
Adjust the volume on your Bluetooth device or on your radio.
14 15 16
A short press will switch your radio On or to Standby.
Rotate to adjust the volume level.
A long press will access the sleep timer when the unit is playing
A short press will access each operating mode in turn.
A short press will display information relating to the music being played.
A long press will access the current menu system.
Press Info/Menu button to go back to a higher level menu or if an error is made.
Rotate clockwise or anti-clockwise to scroll menu items.
A short press on Tuning/Select will select highlighted menu items.
A short press in FM mode scans for stations.
A short press in Bluetooth mode will play/pause audio.
A short press will recall presets 1 - 10.
A long press will allow preset stations 1 - 10 to be saved.
Press to change the display brightness setting.
A short press will change alarm status.
A long press will access alarm settings.
A - Search tuning - FM
1 Fully extend the aerial.
2 Press and release the button until FM is selected.Mode
3 Rotate the Tuning control clockwise or anti-clockwise to
manually tune your radio. Press the Tuning control to scan
upwards or downwards (direction is set by the last manual
rotation). The radio will stop automatically when it nds a
station of sufcient strength.
4 If the signal is strong enough and there is RDS data present
then the radio will display the station name. Adjust the
Volume.
• Press the Info/Menu button to cycle through the various
display options.
The display options are station name, scrolling text, program
type, frequency, audio type, signal strength, date.
Connecting Bluetooth devices
1 The audio player in your smart device may be able to respond
to the Play/Pause, Next or Previous track on the radio.
2 Press the Tuning control to pause playback. Press the control
again to resume playback.
3 Rotate the control clockwise or anti-clockwise to skip to the
next or previous track.
Note: Not all player applications or devices may respond to
all of these controls.
1 To connect a different device, long press on the Info/Menu button, select ‘DISCONNECT’,
rotate the Tuning control to show ‘Y’ and press to conrm. Your radio will become
discoverable by other devices.
2 To clear all Bluetooth pairings, long press on the button, select Info/Menu ‘CLEAR PAIRING’
rotate the Tuning control to show ‘Y’ and press to conrm.
Playing audio
Connect a different device
C - Scan for DAB stations
As time passes new stations may become available or you may have
moved to a different part of the country.
1 Press and release the button until DAB is selected.Mode
2 Press and hold the Info/Menu button and then select ‘SCAN’
by pressing the Tuning control
3 Your radio will perform a scan of the Band III DAB channels. As
new stations are found, they will be added to the list stored in
the radio.
Preset radio stations
There are 20 memory presets, 10 for DAB and 10 for FM. Presets
are remembered in the event of a power failure.
To store a preset
1 Tune to the required radio station.
2 Long press on the Favourites button
3 Use the Tuning control to scroll to an unused preset or a
preset you wish to change.
4 Press Tuning control to store. ‘Preset Saved’ will be
displayed. The preset number will be shown on the playing
display when in FM mode.
To recall a preset
1. Choose DAB or FM mode.
2 Short press on the Favourites button.
3 Use the Tuning control to scroll to the desired preset.
4 Press the Tuning control to select it.
STEP 3 - Presets
STEP 6 - Menu options
Other information
Circuit features
DAB+ / FM RDS / Bluetooth Alarm Clock Radio
Please read this guide, safety/warranty
and streaming leaet before use
Revival Rest
Headphone socket 3.5mm dia.
Aerial System DAB/FM External aerial
Bluetooth standards A2DP, AVRCP, Bluetooth codecs supported SBC & AAC.
Bluetooth BLE EIRP POWER (MAX.) 3.71dBm
Bluetooth EDR EIRP POWER (MAX.) 3.68dBm
Frequency coverage FM 87.5 - 108MHz, DAB 174.928 - 239.200MHz
Bluetooth 5.2 frequencies 2.402 - 2.480GHz
Product markings
DC Power input 7.5V / 1.6A USB output 5V/1A
This symbol indicates AC voltage. This symbol indicates DC
voltage.
Mains adaptor
Manufacturer of AC Adaptor: Teka, Model:TEKA-TB075160BS, Input voltage:
AC100 - 240V, Input AC frequency: 50/60Hz, Output voltage: DC7.5V, Output
current: 1.6A, Output power: 12.0W, Average active efciency:
>
88.72%,
Efciency at low load (10%) 85.26%, No-load power consumption: < 0.1W
Please handle with care. The leather-cloth nish may be susceptible to
damage if mistreated. Avoid all contact with any abrasive material, chemical
substances or cleaning solutions. Your radio may be wiped with a clean
lightly damp cloth. Please ensure that the product is unplugged from the
mains socket outlet before attempting this procedure.
Display Brightness USB Charging
Equaliser
Sleep
Specications
Power requirements
Mains (adaptor): 100 - 240V 50/60Hz
DCin 7.5V 1.6A
DC Out USB Type A. 5V / 1A
Menu options
Snooze
1 Long press the Info/Menu button to access
your radio’s menu system.
2 Rotate Tuning control to show menu
options.
3 Press Tuning control to select menu
options.
4 To exit a menu, press the button Info/Menu
as needed.
1 Long press on the button to enter the alarm settings and display the Alarm ‘ALARM’ time.
2 To set the time for the alarm to come on, rotate the Tuning control and press to set the hour. Repeat for setting
the minutes.
3 Choose whether the alarm ‘MODE’ is to be , .‘DAB’ ‘FM’ or ‘BUZZER
4 If ‘MODE’ is set to either , an option to set a radio ‘PRESET’ is available. Select either ‘LAST LISTENED’ ‘DAB’ or ‘FM’
or one of the saved presets ‘01-10’ (‘Empty’ cannot be selected).
5 Next, select the days that the alarm will sound on. Choose to set the days from ‘DAILY’ (the alarm will sound
everyday), ‘ ’ (the alarm will sound once). ‘ONCE WEEKDAYS’ (the aram will sound on Monday-Friday) or
‘ ’ (the alarm will sound onSaturdy and Sunday). WEEKENDS
6 Next, select the ‘VOLUME’ to set the alarm volume level from 9-32. The volume level will increase gradually
upto the set level.
7 Finally, select whether the alarm is .‘ON’ or ‘Off’
The alarm is cancelled by pressing the button. Alarm
When in standby mode or on, the display will show a clock and the alarm state.
Apply a short press to the buttons when the radio is on, or in standby, to toggle the alarms on/off.Alarm
STEP 5 - Alarms
Sleep - Your radio can be set to turn off after
15-120 minutes has elapsed.
Sleep - Your radio can be set to turn off after
15-120 minutes has elapsed.
Brightness - Access the Display brightness
settings.
Time/Date - Your radio will usually set the
time using the DAB signal. Choose and ‘TIME’
the options include:
SET 12/24 HOUR | AUTO UPDATE | SET TIME
DAB menu
FM menu
System settings
When in DAB mode, long press the Info/
Menu button to access the following DAB
menu options. Rotate the control and press
to select an option.
When in FM mode, long press the Info/Menu
button to access the following FM menu
options. Rotate the control and press to select
an option.
Apply a long press on the Info/Menu button
to access the current menu options. Rotate the
control to ‘SYSTEM’ and press to select.
To set the brightness of the display, there are 3 settings.
TIMEOUT - to adjust the length of time before the backlight turns off
ON LEVEL - to adjust the brightness when the radio is in use
DIM LEVEL - to adjust the brightness when the radio is in standby.
The product features a light sensor on the top panel to detect the ambient
room brightness. When in ‘ ’, the display will be bright in a bright AUTO
room, but will go dim in a dark room.
You can charge your mobile device (e.g. MP3 player, mobile phone etc.)
through the USB socket on this unit with a USB cable (not supplied).
The maximum current for USB charging is 1A.
The sound on your radio can be adjusted to suit your personal taste for
the material that you are listening to.
Select from 7 different proes,
NORMAL | CLASSIC | JAZZ | POP | ROCK | SPEECH | MY EQ.
MY EQ ‘TREBLE’, ‘BASS’ enables levels to be set.
Your radio can be set to turn off after a preset
time has elapsed. With the unit switched on,
press and hold the Power/ Volume control.
Rotate the Tuning control to select the
required sleep time between 15-120 minutes.
An indicator on the right of the display
shows that there is an active sleep timer.
To cancel the sleep timer, enter the ‘Sleep’
menu and select ‘ ’ or press the power OFF
button to cancel the sleep timer and switch
your radio off.
Scan - Choose ‘SCAN’ to scan the band III
DAB channels.
Alarms - Access the alarm settings.
Recall Preset - Access the favourites list. Recall Preset - Access the favourites list.
Save Preset - Access the favourites list.
Save Preset - Access the favourites list.
Manual tune - Choose ‘Manual Tune’ and then
choose the desired DAB channel. The signal
strength will be displayed. The signal marker
( ) shows the minimum strength needed for
good DAB reception.
Station order - Choose ‘STATION ORDER’
and then choose either ‘ALPHANUMERIC’,
‘ENSEMBLE’.
DRC - Choose from ‘DRC OFF’, ‘DRC HIGH’ or
‘DRC LOW’. The DRC facility can make quieter
sounds easier to hear when your radio is used
in a noisy environment. Note: Not all DAB
broadcasts use the DRC function.
Scan Setting - Choose ‘SCAN SETTING’ and
then choose ‘DISTANT’ (your radio will scan
for both weak and strong signals) or ‘LOCAL’
(your radio will scan for stations with good
reception).
Audio Setting - Allows selection of ‘AUTO’ or
‘MONO’. ‘AUTO’ enables stereo to be played
through headphones if a strong enough signal
is present. If a station has a weaker signal
and alternates between stereo and mono
playback, selecting forces the signal ‘Mono’
to play mono.
Equaliser - Choose from 7 sound proles to suit
the material that you are listening too.
Language - Choose a desired language from
the list.
Factory Reset - to completely reset your radio to
its initial state perform a factory reset. Choose,
‘FACTORY RESET’ then ‘YES’. All user entered
settings will be erased.
SW Version - The software display cannot be
altered and is just for your reference. Choose
‘SW VERSION’.
SW Update - Software updates for the radio
may be avaible in the future. Do not update
unless recommended by customer support.
Prune - Choose ‘YES’ to remove any stations
that are no longer available.
Snooze the alarm for 9 minutes by pressing the Power/ Volume dial.
ROBERTS RADIO LIMITED
www.robertsradio.com
© 2024 Roberts Radio Limited
Issue 1
2024-08-21
Designed & Engineered in the UK
Roberts Radio Ltd, Roberts House, Hanworth Lane, Chertsey, KT16 9JX, UK
Glen Dimplex Europe Ltd, Airport Road, Cloghram, Co. Dublin, K67 VE08, Ireland

Produkt Specifikationer

Mærke: Roberts
Kategori: Radio
Model: REVIVAL REST

Har du brug for hjælp?

Hvis du har brug for hjælp til Roberts REVIVAL REST stil et spørgsmål nedenfor, og andre brugere vil svare dig


Radio Roberts Manualer

Roberts

Roberts REVIVAL REST Manual

17 August 2025
Roberts

Roberts Sound 49 Manual

25 Juli 2025
Roberts

Roberts Stylus Luxe Manual

23 Februar 2025
Roberts

Roberts Classic DAB Manual

30 December 2025
Roberts

Roberts Blutune 300L Manual

24 November 2024
Roberts

Roberts Rambler Max Manual

24 Oktober 2024
Roberts

Roberts Duet 2 Manual

4 Oktober 2024
Roberts

Roberts Revival Icon Manual

3 September 2024
Roberts

Roberts Revival Petite 2 Manual

30 August 2024
Roberts

Roberts Ecologic 2 Manual

26 August 2024

Radio Manualer

Nyeste Radio Manualer

Philips

Philips DA1000 Manual

15 August 2025
Philips

Philips AZ3013 Manual

14 August 2025
Philips

Philips AQ4150 Manual

14 August 2025
Sencor

Sencor SRD 1000SCL GR Manual

14 August 2025
Sencor

Sencor SCT 5052BMR Manual

14 August 2025
Eton

Eton Field Radio 550 Manual

13 August 2025
Eton

Eton Scorpion Rugged Manual

13 August 2025
Pryme

Pryme SPM-600-M8-AMP Manual

12 August 2025
Camry

Camry CR 1910 Manual

12 August 2025
Eton

Eton Mini NGWMINIB Manual

12 August 2025
