PACKAGE CONTENTS

• 2-outlet in-wall surge protector

• White decora-style wall plate

• Screws: 2 long and 2 short

• Quick Setup Guide

FEATURES

• Replaces a standard duplex outlet

• Status LED lets you know your devices are

protected

• Tamper-resistant outlets for added safety

• Provides two standard 125V power outlets

• 1,080 joules of surge protection

• Works in nearly all installations

• Compatible with your existing decora wall plate

We recommend that you use a professional electrician to

install the in-wall surge protector.

INSTALLING THE SURGE PROTECTOR

Warning: DISCONNECT POWER. Failure to do so can

result in severe injury or death.

1 Make sure that you disconnect power to the circuit

by removing the fuse from the circuit or turning

OFF the circuit breaker.

2 Remove the wall plate and mounting screws

that cover the old outlet.

3 Carefully remove the existing outlet from the

wall box.

4 Disconnect the wiring from the old outlet.

5 Connect the wires to the surge protector:

• Black lead attaches to the hot wire

• White lead attaches to the neutral wire

• Green lead attaches to the ground wire

You can attach the wires by:

A Inserting straight wires into the holes.

A Wrapping the wires 3/4 of the way around

the terminal screws, making sure that the

wires do not overlap.

B Tighten every screw and make sure that no

bare copper wire is exposed.

SAFETY

Warnings:

• RISK OF ELECTRIC SHOCK — Use only in dry locations

and only indoors.

• All cables should be routed away from the outlet

openings.

• DO NOT use with any aquarium equipment.

• DO NOT install in an outlet that is not grounded.

Notes to the installer:

• This device must be installed in accordance with

National and Local electrical codes.

• To prevent severe shock or electrocution, always turn

power OFF at the service panel before working with

wiring.

• This device should be used with copper or copper-clad

wire. DO NOT use with aluminum wire.

• DO NOT plug this device into a shallow wall box. The

wall box must be deep enough to house the surge

protector. If the box is too shallow, the surge protector.

will not t securely into the wall.

Before using your new product, please read these instructions to prevent any damage.

PROTECTED/

FAULT

FAUL

AC outlets

(2)

Indicator

LED

Ground

(green)

Neutral

(white)

Hot

(black)

Front

QUICK SETUP GUIDE

RF-HTS120W22 | 2-outlet In-wall Surge Protector

Back

V1 ENGLISH 22-0836

6 Carefully insert the surge

protector into the wall box.

7 Secure the surge protector

to the wall box with the two

long screws (provided).

8 Secure the wall plate to the

surge protector with the two

short screws (provided).

9 Restore power by

replacing the fuse or

turning on the circuit

breaker. The surge

protector is ready

to use.

USING THE SURGE PROTECTOR

To power electrical devices (like lamps or laptop), plug

them into the electrical outlets.

LED INDICATOR

• Blue: surge protected

• Red: wiring fault

• LED o: not surge protected

Note: Only applicable if the outlet is receiving power.

The LED is not lit when power is shut o to outlet.

SPECIFICATIONS

Dimensions (H × W × D)

• With plate:

4.7 × 3 × 1.9 in. (120 × 76 × 47.6 mm)

• Without plate:

4.2 × 1.7 × 1.9 in (106 × 44 × 47.6 mm)

Electrical

• Receptacle rating: 15 Amp, 125VAC

• Line voltage: 125V A C @ 60Hz

• Surge protection: 3 lines (L-N / L-G / N-G)

• Clamping voltage: L-N / L-G / N-G = 500 V

• Maximum surge current: 45,000 amps

• Maximum energy dissipation: 1,080 joules

• Wire terminals: #14-#12 AWG

UL-1449 certied

LEGAL NOTICES

FCC Statement

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful interference, and (2) this device must accept

any interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation.

This equipment generates, uses, and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment o and on, the user is encouraged to try to

correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Warning: Changes or modications not expressly approved by the party responsible for

compliance could void the user's authority to operate the equipment.

ICES-003

This Class B digital apparatus complies with Canadian ICES-003.

ONE-YEAR LIMITED WARRANTY

Visit www.rocketﬁshproducts.com for details.

CONTACT ROCKETFISH:

For customer service please call 1-800-620-2790

www.rocketﬁshproducts.com

ROCKETFISH is a trademark of Best Buy and its aliated companies.

Distributed by Best Buy Purchasing, LLC

7601 Penn Ave South, Richeld, MN 55423 U.S.A.
