Side 1/2
Features
DisplayPort Male
(Connect to host computer)
• Supports DP1.2
Introduction
Package Contents
Before attempting to use this unit, please check the packaging and make sure
the following items are contained in the Packaging:
• Main unit x1
• User Manual x1
Operation
1- Connect DisplayPort of this product to a DisplayPort display
2- Connect HDMI port of this product to an HDMI monitor
This Premium Rocstor DisplayPort 1.2 to HDMI allows you to transmit signal from your
DisplayPort host (PC, tablet) to an HDMI monitor. This adapter enables to output HDMI
video with max 4k/60Hz. Besides, this product supports HDR which enables to ensures
every moment of a video is displayed at its ideal values for depth, detail, brightness,
contrast and wider color gamuts—on a scene-by-scene or even a frame-by-frame
basis. With this product, you can watch videos or slideshows on big screen.
HDMI
• Support HDMI resolution up to 4kx2k@60HZ
• 18Gbps HDMI bandwidth
• Supports 8/10/12 bit color depth output
• Support output pixel format RGB/YCbCr4:4:4/YCb
Cr4:2:2/YCbCr4:2:0
• Support HDCP 2.2&HDCP1.4
• Support HDR
Upstream:
Downstream:
Specication
System Requirement
Input / Output Connector
Input
Output HDMI Female p1-x1
DisplayPort Male x1
Warranty
Limited Warranty 3 Year
Environmental
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
0°C to + 45°C - (32°F to + 113°F)
10% to 90 % RH (no condensation)
-10°C to + 70°C - (14°F to + 158°F)
10% to 90 % RH (no condensation)
Regulatory Approvals
Certications
Resolution
HDMI Resolutions Up to 4KX2K@60HZ
HDMI Bandwidth 18Gbps
Power
Power Source Bus Power
Standby Power Consumption ≤0.1W
Working Power Consumption ≤0.72W
Size (LxHxW) 6.6”x0.86”x0.47” - 168x22x12
Weight 0.7oz - 22gr
Accessory
User Manual English Version
FCC, CE
Host computer with an available DisplayPort
Operating systems
- Windows 7 / 8 / 10 / 11
- Android OS
- Chrome OS
- Linux OS
- Mac OS v10.5 or above
®
Congratulations
Thank you for purchasing this premium Rocstor product. For optimum performance and
safety, please read these instructions carefully before connecting, operating or using this
product. Please keep this manual for future reference.
DisplayPort® 1.2 to HDMI 4Kx2K 60Hz Active
Adapter Converter M/F - Black
User Manual
Y10A101-B2
Technical Support / RMA
Hours: 9:00 am - 5:00 pm PST
Monday to Friday (except holidays)
Tell: +1 (818) 727-7000
( )National and international
Fax: +1 (818) 875-0002
Email: support@Rocstor.com
Support
Warranty Information
Technical support is available to all the registered users of Rocstor products.
Safety Information:
©2021 Rocstroge, Inc. All rights reserved. Rocstor is registered trademark of Rocstorage, Inc.
Apple®, the Apple logo, Mac®, MacBook®, MacBook Pro®, MacBook Air®, iPad®, iPad Air®, iPad mini®,
iPad Air®, iPhone®, MacOS® are registered trademarks of Apple, Inc. Google® and Chromebook™ are
registered trademarks of Google, LLC. Microsoft® is registered trademarks of Microsoft corporation. Al
other product names and logos mentioned herein may be trademarks of their respective companies.
USB Type-C® and USB-C® are registered trademark of USB Implementers Forum. Feature and
specication are subject to change without notice. All trademarks and registered trademarks are the
property of their respective. All rights reserved.
Monitor or Projector
HDMI
Host Computer with
DP port
WARNING: Please follow these safety instructions. Failure to do so may result damages or injury.
It is normal that the Rocstor adapter becomes very warm during use.
Please note that:
continuous contact with warm surfaces for extended time may cause discomfort or injury. In order to
reduce the possibility of overheating or heat-related injuries, always allow needed ventilation around
the Rocstor adapter and use care when handling it. Avoid instances where your skin is in extended
contact with the hub when plugged into the host computer. It is not recommended to sleep with the
adapter when plugged into a host computer. Avoid placing the hub adapter under a pillow, blanket,
or your body when connected to a host computer. If you have a medical condition that aects your
ability to detect heat against the body, extra care should be used. Never use the adapter in locations
with water, such as a sink, bathtub, or shower stall. Never connect or disconnect the adapter with wet
hands.
!
Limitation of Liability
In no event shall the liability of Rocstorage, Inc. and Rocstor (or their ocers, directors, employees or
agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or
otherwise), loss of prots, loss of business, or any pecuniary loss, arising out of or related to the use of
the product exceed the actual price paid for the product. Some states do not allow the exclusion or
limitation of incidental or consequential damages. If such laws apply, the limitations or exclusions
contained in this statement may not apply to you.
Warranty Information
This product is backed by a (3) three-year warranty. Rocstor warrants its products against defects in
materials and workmanship for the periods noted, following the initial date of purchase. During this
period, the products may be returned for repair, or replacement with equivalent products at our
discretion. The warranty covers parts and labor costs only. Rocstor does not warrant its products from
defects or damages arising from misuse, abuse, alteration, or normal wear and tear.
Connection Diagram
