Features

DisplayPort Male

(Connect to host computer)

• Supports DP1.2

Introduction

Package Contents

Before attempting to use this unit, please check the packaging and make sure

the following items are contained in the Packaging:

• Main unit x1

• User Manual x1

Operation

1- Connect DisplayPort of this product to a DisplayPort display

2- Connect HDMI port of this product to an HDMI monitor

This Premium Rocstor DisplayPort® 1.4 to HDMI 2.0 Active Adapter - 4K/60Hz allows

you to transmit signals from your host PC to an HDMI monitor. This adapter enables to

output HDMI video with max 4k/60Hz.

HDMI

• Support HDMI resolution up to 4kx2k@60HZ

• 18Gbps HDMI bandwidth

• Supports 8/10/12 bit color depth output

• Support output pixel format RGB/YCbCr4:4:4/YCb

Cr4:2:2/YCbCr4:2:0

• Support HDCP 2.2&HDCP1.4

• Support HDR

Upstream:

Downstream:

Specication

Input / Output Connector

Input

Output

HDMI Female p1-x1

DisplayPort Male x1

Warranty

Limited Warranty 3 Year

Environmental

Operating Temperature

Operating Humidity

Storage Temperature

Storage Humidity

0°C to + 45°C - (32°F to + 113°F)

10% to 90 % RH (no condensation)

-10°C to + 70°C - (14°F to + 158°F)

10% to 90 % RH (no condensation)

Regulatory Approvals

Certications

Resolution

HDMI Resolutions Up to 4KX2K@60HZ

HDMI Bandwidth 18Gbps

Power

Input Voltage 3.3V

Power Consumption 0.65W

Size (LxWxH) 8”x0.88”x0.45” - 205x22.5x11.5 mm

Weight 0.9oz - 26gr

Accessory

User Manual English Version

FCC, CE

Congratulations

Thank you for purchasing this premium Rocstor product. For optimum performance and

safety, please read these instructions carefully before connecting, operating or using this

product. Please keep this manual for future reference.

DisplayPort® 1.4 to HDMI Active Adapter

4K/60Hz – Black

User Manual

Y10A296-B1

Technical Support / RMA

Hours: 9:00 am - 5:00 pm PST

Monday to Friday (except holidays)

Tell: +1 (818) 727-7000

( )National and international

Fax: +1 (818) 875-0002

Email: support@Rocstor.com

Support

Warranty Information

Technical support is available to all the registered users of Rocstor products.

Safety Information:

Apple®, the Apple logo, Mac®, MacBook®, MacBook Pro®, MacBook Air®, iPad®, iPad Air®, iPad mini®,

iPad Air®, iPhone®, MacOS® are registered trademarks of Apple, Inc. Google® and Chromebook™ are

registered trademarks of Google, LLC. Microsoft® is registered trademarks of Microsoft corporation. Al

other product names and logos mentioned herein may be trademarks of their respective companies.

USB Type-C® and USB-C® are registered trademark of USB Implementers Forum. Feature and

specication are subject to change without notice. All trademarks and registered trademarks are the

Monitor or Projector

HDMI

Host Computer with

DP port

WARNING: Please follow these safety instructions. Failure to do so may result damages or injury.

It is normal that the Rocstor adapter becomes very warm during use.

Please note that:

continuous contact with warm surfaces for extended time may cause discomfort or injury. In order to

reduce the possibility of overheating or heat-related injuries, always allow needed ventilation around

the Rocstor adapter and use care when handling it. Avoid instances where your skin is in extended

contact with the hub when plugged into the host computer. It is not recommended to sleep with the

adapter when plugged into a host computer. Avoid placing the hub adapter under a pillow, blanket,

or your body when connected to a host computer. If you have a medical condition that aects your

ability to detect heat against the body, extra care should be used. Never use the adapter in locations

with water, such as a sink, bathtub, or shower stall. Never connect or disconnect the adapter with wet

hands.

Limitation of Liability

In no event shall the liability of Rocstorage, Inc. and Rocstor (or their ocers, directors, employees or

agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or

otherwise), loss of prots, loss of business, or any pecuniary loss, arising out of or related to the use of

the product exceed the actual price paid for the product. Some states do not allow the exclusion or

limitation of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

Warranty Information

This product is backed by a (3) three-year warranty. Rocstor warrants its products against defects in

materials and workmanship for the periods noted, following the initial date of purchase. During this

period, the products may be returned for repair, or replacement with equivalent products at our

discretion. The warranty covers parts and labor costs only. Rocstor does not warrant its products from

defects or damages arising from misuse, abuse, alteration, or normal wear and tear.

Connection Diagram

Produkt Specifikationer

Mærke:	Rocstor
Kategori:	Kabler til pc'er og periferiudstyr
Model:	Y10A296-B1
Bredde:	22.5 mm
Dybde:	205 mm
Højde:	11.5 mm
Vægt:	26 g
Antal pr. pakke:	1 stk
Brugervejledning:	Ja
Produktfarve:	Sort
Pakkevægt:	36 g
Pakkedybde:	240 mm
Pakkebredde:	178 mm
Pakkehøjde:	10 mm
Understøttede videotilstande:	1080p, 2160p
Opbevaringstemperatur (T-T):	-10 - 70 °C
Relativ luftfugtighed ved drift (H-H):	10 - 90 %
Relativ luftfugtighed ved opbevaring (H-H):	10 - 90 %
HDCP:	Ja
Driftstemperatur (T-T):	0 - 45 °C
Maksimal opløsning:	3840 x 2160 pixel
Pakketype:	Polybag
Understøttede grafikopløsninger:	1920 x 1080 (HD 1080), 3840 x 2160
Audio Return Channel (ARC):	Ja
High Dynamic Range (HDR) understøttet:	Ja
Kabellængde:	- m
Oprindelsesland:	Vietnam
Plug and play:	Ja
Maksimal opdateringshastighed:	60 Hz
HDMI-version:	2.0
DisplayPort-version:	1.4
Stik 1:	DisplayPort
Stik 2:	HDMI
Stik 1 køn:	Hanstik
Stik 2 køn:	Hunstik
Dataoverførselshastighed:	18 Gbit/sek.
HDCP-version:	1.4/2.2
Kabeltype:	Rundt kabel
Stik 1 formfaktor:	Lige
Stik 2 formfaktor:	Lige
Konverter type:	Aktiv videoomformer
Understøttede lydkanaler:	7.1
Opdateringshastighed ved maksimal opløsning:	60 Hz
Garantiperiode:	3 År
DisplayPort Content Protection (DPCP):	Ja
Farveprøvetagning:	4:2:2, 4:4:4, 4:2:0
Mærkespænding:	3.3 V
Stik 1 dimensioner (BxDxH):	19.7 x 28 x 11.5 mm
Stik 2 dimensioner (BxDxH):	22.5 x 48.7 x 11.5 mm
