Side 1/2

Features

DisplayPort Male

Rocstor introduces the DisplayPort1.4 to Triple HDMI Adapter, designed to expand a

DisplayPort-based host to three HDMI ports with ultra-high denition capability.

Supporting DP1.4 alt mode, this product enables the output of dual maximum

4K/60Hz videos or triple videos (maximum 4K/60Hz + 2x4K/30Hz) simultaneously

under MST mode.

Before attempting to use this unit, please check the packaging and make sure the

following items are contained in it:

• Main Unit x1

• Micro USB to USB-A Cable x1

• User Manual

HDMI Female X3

• Compliant with DP1.4 alt mode up to

8.1Gbps (HBR3), downward compatible

with 5.4 Gbps (HBR2), 2.7 Gbps (HBR)

and 1.62 Gbps (RBR)

• Supports HDMI max 4K/60Hz per port,

dual max 4K/60Hz under MST (output

dierent pictures simultaneously) or

output triple displays (max

4K/60Hz+2x4K/30Hz) under MST

• Supports 8/10/12 bit color depth output

• Supports output pixel format

RGB/YCbCr4:4:4/YCbCr4:2:2/YCbCr4:2:0

• Supports HDCP2.2&1.4

• Supports HDR which ensures every

moment of a video is displayed at its

ideal values for depth, detail, brightness,

contrast and wider color gamuts on a

scene by scene or even a frame by frame basis

Note: To achieve the above resolution, the

host should support DP1.4, when

working on DP1.2 host, the correspond-

ing resolution will be decreased due to

bandwidth limitation. The above

resolution combination is for theoretical

reference, the actual output resolution

depends on the connected host and

displays

Upstream:

Downstream:

• Supports DP1.4 Alt mode

Micro USB X1 (For Power)

• Supports Gigabit

Ethernet,10M/100M/1000M

• Supports Wake-On-LAN

• Supports full duplex ow control

• Light indicates the state, no

light when no Internet connected,

orange light turns on when network

connection is established, yellow light

ashes when transmitting data

Package Contents

Specication

Input

Output

Operating Temperature

Storage Humidity

Storage Temperature

Operating Humidity

Introduction

Environmental

Input / Output Connector

Certications

Regulatory Approvals

User Manual

Accessory Adapter

Warranty

Limited Warranty

HDMI

HDR

Resolution

Size (L-W-H)

Mechanical

Weight (Net)

Standby Power Consumption

HDCP Version

Power Requirement

Power Source

HDMI Female x3

DisplayPort Male x1

3 Years

0°C to 45°C (32°F to 113°F)

5% to 90 % RH (no condensation)

-10°C to 70°C (14°F to 158°F)

10% to 85% RH (no condensation)

FCC, CE

English Version

Support

Max dual 4K/60Hz

3.9x1.4x0.45in (100.82x36x11.5mm)

1.98lbs (56.2g)

≤0.3W

HDCP2.2&1.4

Micro USB

DisplayPort 1.4 to Triple HDMI

Adapter with MST

User Manual

Y10A314-B1

Congratulations

Thank you for purchasing this premium Rocstor product. For optimum performance and

safety, please read these instructions carefully before connecting, operating or using this

product. Please keep this manual for future reference.

Technical Support / RMA

Hours: 9:00 am - 5:00 pm PST

Monday to Friday (except holidays)

Tell: +1 (818) 727-7000

(National and international)

Fax: +1 (818) 875-0002

Support

Warranty Information

Technical support is available to all the registered users of Rocstor products.

Connection Diagram

Safety Information:

Apple®, the Apple logo, Mac®, MacBook®, MacBook Pro®, MacBook Air®, iPad®, iPad Air®, iPad mini®,

iPad Air®, iPhone®, MacOS® are registered trademarks of Apple, Inc. Google® and Chromebook™ are

registered trademarks of Google, LLC. Microsoft® is registered trademarks of Microsoft corporation. Al

other product names and logos mentioned herein may be trademarks of their respective companies.

Thunderbolt is a trademark of Intel Corporation or its subsidiaries. USB Type-C® and USB-C® are

registered trademark of USB Implementers Forum. The terms HDMI, HDMI High-Denition

Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks

of HDMI Licensing Administrator, Inc. Feature and specication are subject to change without notice.

Email: support@rocstor.com

WARNING:

Please follow these safety instructions. Failure to do so may result damages or injury.

It is normal that the device adapter becomes very warm during use.

Please note that:

Continuous contact with warm surfaces for extended time may cause discomfort or injury. In order to

reduce the possibility of overheating or heat-related injuries, always allow needed ventilation around

the device and use care when handling it. Avoid instances where your skin is in extended contact

with the device when plugged into the host computer. It is not recommended to sleep with the

device when plugged into a host computer. Avoid placing the device under a pillow, blanket, or your

body when connected to a host computer. If you have a medical condition that aects your ability to

detect heat against the body, extra care should be used. Never use the device in locations with water,

such as a sink, bathtub, or shower stall. Never connect or disconnect the device with wet hands.

Limitation of Liability

In no event shall the liability of Rocstor, Inc. and Rocstor (or their ocers, directors, employees or

agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or

otherwise), loss of prots, loss of business, or any pecuniary loss, arising out of or related to the use of

the product exceed the actual price paid for the product. Some states do not allow the exclusion or

limitation of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

Warranty Information

This product is backed by a (3) three-year warranty. Rocstor warrants its products against defects in

materials and workmanship for the periods noted, following the initial date of purchase. During this

period, the products may be returned for repair, or replacement with equivalent products at our

discretion. The warranty covers parts and labor costs only. Rocstor does not warrant its products from

defects or damages arising from misuse, abuse, alteration, or normal wear and tear.

HDMI Display 1

5V Power Supply

HDMI Display 3

PC with DisplayPort Connector

HDMI Display 2

Dual max 4k/60Hz or triple displays under MST mode
