Side 1/44

Before using the V-1HD, ensure that its system program is at the most recent version. For information on

available upgrades for the system program, see the Roland website (https://proav.roland.com/). You can check

the system program version by pressing and holding the [(TAP) BPM] button g “VERSION” at the SETUP menu.

Owner’s Manual (this document)

Read this rst. It explains the basic things you need

to know in order to use the V-1HD.

PDF Manual (download from the Web)

5 Remote Control Guide

This manual covers remote control of the V-1HD via

MIDI.

To obtain the PDF manual

1. Enter the following URL in your computer.

https://proav.roland.com/

2. Go to the V-1HD product page and click

the “Support.”

Version 2.0 and later

Contents

USING THE UNIT SAFELY . . . . . . . . . . . . . . . . . . . . . 3

IMPORTANT NOTES . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Panel Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Top Panel/Front Panel . . . . . . . . . . . . . . . . . . . . . . . 6

Rear Panel (Connecting Your Equipment) . . . . . . . 8

Side Panel (Connecting Your Equipment) . . . . . . . 10

Basic Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Turning the Power On and O . . . . . . . . . . . . . . . . 11

Turning O the Power Automatically

(Auto O)

. . . . . 11

Using the Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Saving/Recalling Settings (Memory) . . . . . . . . . . . 13

Video Input/Output Settings . . . . . . . . . . . . . . . . . 14

Setting the Video Input/Output Format . . . . . . . . 14

Adjusting Output Video . . . . . . . . . . . . . . . . . . . . . . 14

Switching the View Mode of Preview Output . . . . 15

Inputting Copyright-protected (HDCP) Video . . . 15

Video Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Switching the Video . . . . . . . . . . . . . . . . . . . . . . . . . 16

Switching Using the A/B Fader . . . . . . . . . . . . . . 16

Switching Using the TRANSFORMER Buttons . . 17

Switching in Time with Music (BPM Sync) . . . . . 18

Switching Automatically (Auto Scan) . . . . . . . . . 19

Using a Dierent Transition Pattern . . . . . . . . . . 19

Applying a Fade to the Main Output Video

(Output Fade)

. . . 20

Freezing Input Video (Freeze) . . . . . . . . . . . . . . . . . 20

Video Eect Operations . . . . . . . . . . . . . . . . . . . . . . 21

Using Filter Eects . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Selecting a Filter Eect . . . . . . . . . . . . . . . . . . . . . 21

Applying Filter Eects . . . . . . . . . . . . . . . . . . . . . 21

Using Compositing Eects . . . . . . . . . . . . . . . . . . . 22

Selecting a Compositing Eect . . . . . . . . . . . . . . 22

Compositing Using Luminance Key . . . . . . . . . . 22

Compositing Using Chroma Key. . . . . . . . . . . . . 23

Compositing Using Split . . . . . . . . . . . . . . . . . . . 23

Compositing Using Picture-in-Picture . . . . . . . . 24

Audio Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Adjusting the Volume Level . . . . . . . . . . . . . . . . . . 25

Applying Eects to Audio . . . . . . . . . . . . . . . . . . . . 26

Applying Eects to Input Audio . . . . . . . . . . . . . 26

Applying Eects to Output Audio . . . . . . . . . . . 27

Interlinking Audio Output to Video Switching

(Audio Follow)

. . 28

Other Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Returning to the Factory Settings

(Factory Reset)

. . . 29

Operating the V-1HD by Remote Control . . . . . . . 29

Appendices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Menu List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

MEMORY Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

AUDIO Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

SETUP Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Transition Eects List . . . . . . . . . . . . . . . . . . . . . . . . 37

Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Main Specications . . . . . . . . . . . . . . . . . . . . . . . . . 40

Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Checking the Included Items

The V-1HD includes the following items. Please take a moment to conrm that all of these items have

been included with the V-1HD. If you nd that any item is missing, contact the nearest authorized Roland

distributor in your country.

The unit

Adaptor/power Cord

Cord hook

Owner’s Manual

* The shape of the power cord’s plug

varies depending on the country.

Before using this unit, carefully read “USING THE UNIT

SAFELY” (p. 3) and “IMPORTANT NOTES” (p. 5).

After reading, keep the document(s) including those

sections where it will be available for immediate reference.

Produkt Specifikationer

Mærke:	Roland
Kategori:	Blandekonsol
Model:	V-1HD
Bredde:	313 mm
Dybde:	102 mm
Højde:	59 mm
Vægt:	1200 g
Produktfarve:	Sort
Kontroltype:	Button, Jog dial, T-bar fader
Indbygget skærm:	Ingen
Grænseflade:	USB
Indbygget tastatur:	Ja
