PI9

PhonePatch II

Quick Start Guide

Rolls Corporatio n

Salt Lake City, UT

03/10

SPECIFICATIONS

Input Impedance : s600 Ohm

Output Impedance: 10 K Ohms

Input Level +15 dB ma : x

Out t v : +5 dB xpu Le el ma

Ringer Equivalence 0.0 : A, 0.0 B

Conne ionct s: 11 phone jack,2; RJ

2; RCA jacks

1: Tip-Ring-Sleeve 3.5mm jack

Size: 2.7" W x 1.45" H x 2.32" D

Weight lb: 1 .

PI9 P Patch IIhone

- RCA and 1/8" (3.5mm) Inputs

and Outputs

- 11 RJ Phone and Line jacks

T PI9 he is a passive device for

connecting a phone line to an

audio system or vice versa. Handy

for phone interviews, broadcast, or

laptop presentations with a remote

phone s .ignal

INRODUCTION

Thank you for your purchase of the PI9 PhonePatch II. The PI9

takes a signal from a standard telephone jack and,via transformer

isolation, connects to a pair of RCA jacks, or a stereo 1/8"

(3.5mm) jack. The isolation keeps the output signal separate from

the telephone line, and will not keep the line open unless the

HOOK switch is in the ON positin as described later in the guide.

Applications for the PI9 include broadcast, conference

rooms, phone training, laptop presentations, or wherever a phone

conversation needs to be recorded or heard over a PA system.

The PI9 also works for putting audio onto a phone line. However,

you must ensure the signal level is no hotter than line level (+4

dB) or you will get distortion on the phone line.

WARRANTY

For information on the Rolls One Year Limited Warranty, and to

www.rolls.com

DESCRIPTION

INPUTS: 2 ea: Standard RJ11 phone jacks.

AUDIO LINE: Stereo RCA, 1/8" (3.5mm) jack

ON/MUTE switch: Connects or disconnects the Phone/Line jacks to

the transformer and the Audio output. With the switch in (ON) the audio

is active. When the switch is out (MUTE) the audio signal is muted.

CONNECTION: Re erf to

F 1.igure

Connect a standard telephone cable to an active telephone line,

and to the PI9 Phone Input. To pass the signal on to another

telephone, connect another standard telephone cable from the

PI9 Line jack to a telephone.

Connect either a stereo RCA cable, or stereo 1/8" (3.5mm) cable

to an AUDIO LINE output jack.

Fig reu 1.

HOOK: OFF - ON

An option on the PI9 is the ability to select whether or not

the unit will hold a line open. A line being "held open" acts

like a telephone is off the hook. ON is for the line to be left open

and OFF is when the phone is hung up.

PI9

HOOK

OFF - ON

MUTE

HOOK

OFF - ON

PI9
