Side 1/2
RM316
3 Zone Mixer
Quick Start Guide
ROLLS CORPORATION
SALT LAKE CITY, UTAH
01/19
OUTPUT
-
OFF=UP
ON=DOWN
TALK OVER ZONE ASSIGNMENT
PHANTOM POWER
MIC/LINE
MIC/LINE
INPUT LEVEL
MIC
LINE
POWER
2
3
1
2 3
MIC 1
+15V
WIPER
GND
REMOTE
CHANNEL 3
MIC 2
MIC 3
MIC/LINE
1
3
+
-
PIN 1 GND
PIN 2 +
PIN 3
-
XLR:
MUSIC ON HOLD OUT (SOURCE 1)
1/4” BAL:
TIP +
RING
-
SLEVE GND
1/4” UN BAL:
TIP +
RING NOT USED
SLEVE GND
+15V
WIPER
GND
REMOTE
CHANNEL 2
+
OUTPUT
+15V
WIPER
GND
REMOTE
CHANNEL 1
+
-
OUTPUT
ZONE 1
ZONE 2
ZONE 3
MASTER VOLUME
ZONE
1
2
3
SOURCE 3
ZONE
1
2
3
SOURCE 2
ZONE
1
2
3
SOURCE 1
ZONE
1
2
3
MIC 3
ZONE
1
2
3
MIC 2
ZONE
1
2
3
MIC 1
1/8”
RM316
3 Zone Mixer
IN
MADE IN USA
www.rolls.com
OUTPUT
-
OFF=UP
ON=DOWN
TALK OVER ZONE ASSIGNMENT
PHANTOM POWER
MIC/LINE
MIC/LINE
INPUT LEVEL
MIC
LINE
POWER
2
3
1
2 3
MIC 1
+15V
WIPER
GND
REMOTE
CHANNEL 3
MIC 2
MIC 3
MIC/LINE
1
3
+
-
PIN 1 GND
PIN 2 +
PIN 3
-
XLR:
MUSIC ON HOLD OUT (SOURCE 1)
1/4” BAL:
TIP +
RING
-
SLEVE GND
1/4” UN BAL:
TIP +
RING NOT USED
SLEVE GND
+15V
WIPER
GND
REMOTE
CHANNEL 2
+
OUTPUT
+15V
WIPER
GND
REMOTE
CHANNEL 1
+
-
OUTPUT
ZONE 1
ZONE 2
ZONE 3
MASTER VOLUME
ZONE
1
2
3
SOURCE 3
ZONE
1
2
3
SOURCE 2
ZONE
1
2
3
SOURCE 1
ZONE
1
2
3
MIC 3
ZONE
1
2
3
MIC 2
ZONE
1
2
3
MIC 1
1/8”
RM316
3 Zone Mixer
IN
MADE IN USA
www.rolls.com
OUTPUT
+15V
WIPER
GND
REMOTE
+
-
Connection to output
The remote volume section on the rear panel of the RM316 allows the installer to place remote vol-
ume controls in any or all of the zones connected to the RM316. Wiring information is silk screened
above each remote volume connector.
Q: Does the remote volume wire carry audio signal?
A: No, the remote volume wire only carries a DC control voltage that varies according to the posi-
tion of the remote volume pot (10-100K Ohm linear potentiometer recommended). Use of the remote
volume feature will not introduce any noise or cause any signal loss.
Q: What is the maximum length that I can run a remote volume wire?
A: Wire size can a󰀨ect the maximum length. You can run up to 200 feet reliably, and with high quality
wire up to 1000 feet.
Below is a diagram of how to connect the pots to the remote volume Phoenix connectors.
REMOTE PAD: 5 pin Phoenix connector for connection to a remote potentiometer for remote volume
control. A 100K Ohm potentiometer is recommended (others will work).
+15: Connection to potentiometer.
WIPER: Connection to potentiometers wiper (middle pin).
COMM: Common Ground for connection to pots.
As a note: If the potentiometer pad is working opposite of what you intended just reverse the wires
going to that potentiometer.
SPECIFICATIONS
Input Impedance: 10K Ohms balanced Line
600 Ohms balanced Mic
10K Ohms unbalanced RCA
Output Impedance: 50 Ohms balanced
Max Input Level: Mic: -30 dB
Source: +22 dB
Phantom Power: +15 Volts DC
Input Connectors: XLR and RCA
Outputs: 3 ea. Phoenix connector
Max Gain: 60 dB mic
30 dB line
S/N Ratio: >75 dB
THD: < .3%
IMD (SMPTE): < .3%
CMRR: 60 dB
Frequency Response: 20Hz to 20kHz +/- 0 dB
Power Adapter: 15VDC
Weight: 7 lbs (3KG)
Size: 19” x 1.75” x 6.5”
(48cm x 4.5cm x 17cm)
