Page 4 2221 Highway 36 W St. Paul MN 55113 800.359.5520 www.sanus.com Page 1

the next section. To utilize the steel speaker

studs, simply thread them into the holes in the

corners of the top plates until the end protrudes

1/8 inch through the bottom. Place your speaker

on the steel speaker studs.(Photo 5) Insert the

small allen key into the bottom of each steel

speaker stud and adjust them until the speaker

is level and does not rock back and forth. Lock

in place with a machine nut. Use of the steel

speaker studs is optional.* The Rubber Pads are

Every effort has been made to ensure that your stands are per-

fect. If you have any questions or feel that there is a problem of

any kind, please contact SanusCustomer Support. We can assist

with questions or damaged/missing parts.

Customer Support (800) 359-5520 or www.sanus.com

PHOTO 5

ULTIMATE FOUNDATIONS®

INSTRUCTION MANUAL

provided as an alternative and may be placed in the corners of the top plates.

Simply twist the pads into the holes in the corners of each top plate.

6] A number of manfacturers are providing threaded inserts on the bottom

of their speakers for the new Foundation Mount™ system. The Foundation

Mount™ system allows you to bolt your speaker to the top plate using the

speaker bolts and the remaining allen key provided. This system provides

signiﬁcant safety beneﬁts when used in earthquake areas or around pets and

children. It also offers maximum resonance damping characteristics. The

rubber pads should be sandwiched between the top plate and the speaker to

provide superior damping and prevent damage to the speaker. Do not use the

steel speaker studs when bolt mounting.

*NOTE: The ends of the spiked feet and steel speaker studs are very sharp

and may scratch ﬂoors or furniture. All sharp objects can be hazardous to

children. For this reason rubber pads are provided as an option. The decision

to use spiked feet and/or speaker studs is yours; Sanus Systems will not be

liable for damage or injury.

Page 3 * PLEASE READ THE NOTE ON PAGE 4 OF THIS MANUAL!

ʻTake the time to ﬁnd the right speaker locations for your

listening room.ʼ

Page 2

1] Attach three rubber isolation rings to each NuStone base . (Photo 2) At-

tach three NuStone feet to each NuStone base. (Photo 3)

2] Group three pillars with each NuStone base. Notice that the bolt holes are

countersunk on one side of the base; this side is the bottom and faces away

from the pillar. Align the countersunk holes in the base with the holes in either

end of the pillars. Bolt the pillars and the base together using the long 2"

round head bolts. Do not tighten! If the pillars are not loose, you will not be

able to attach the top plate in the next step.

3] Notice that the bolt holes are countersunk on one side of the top plates;

this is the top side and faces away from the pillars. Adhere the two inch self

adhesive damping washers to the bottom side of each top plate. The holes

in the damping washers line up with the holes in the top plate. The damping

washers will be sandwiched between the top plate and the pillars. (Photo 4)

Align the countersunk holes in the top plate with corresponding holes in the

top of each pillar. With the large allen key, bolt the pillars and the top plate

together using the 1.75" bolts. Tighten, then ﬂip the stand over and tighten

the NuStone base bolts.

4] Both spiked feet and rubber pads are provided for your Ultimate Foun-

dations®. The spiked feet are preferable in terms of performance. Simply

thread a machine nut over the spiked feet and thread the ends of the spiked

feet into the threaded holes in the NuStone feet. Adjust the spiked feet until

Hardware List (Photo 1, 2, & 3)

A] allen keys (3)

B] steel speaker studs (8)

C] spiked feet (6)

D] nuts (14)

E] 1.75" ﬂat head bolts (6)

F] damping washers (6)

G] rubber pads (2 discs of 8)

H] 2" rubber isolation rings (6)

I] NuStone bases (2)

J] NuStone feet (6)

K] 2" round head bolts (6) not pictured

L] top plates (2) not pictured

M] pillars (6) not pictured

N] 5/8" speaker bolts (2) (For Boston

Acoustics VRM series and other bolt -mount

speakers.) not shown

PHOTO 4

PHOTO 1

PHOTO 3

PHOTO 2

the stand is level and lock into place

by tightening the machine nut. Use

of the spiked feet is optional.* The

Rubber Pads are provided as an al-

ternative and may be placed in the

corners of the top plates. Twist the

pads into the holes in the corners of

each top plate.

5] Three forms of speaker mounts

are provided – steel speaker studs,

rubber pads and the new Founda-

tion Mount™ which is discussed in
