This lock can be installed as passage (hall/closet) or privacy (bed/bath).
See the included Privacy function kit.
a
b
c
d
e
f
b
a
g
h
j
k
i
l
a. Knob/Lever
b. Trim
c. Exterior chassis
d. Latch
e. Interior chassis
f. Chassis screws
g. Backplate
h. Faceplate
i. Drive-in faceplate
j. Latch/strike screws
k. Strike
l. Hex wrench (Do not discard!)
1 Watch the installation video.
Go to Schlage.com/faqs-custom.
2 Check door dimensions.
2a If dimensions do
not match, you
may need to
modify your door.
For further assistance,
call Customer Service
at (888) 805-9837.
2b Check latch length.
Measure the backset as shown above.
• 2 3/8" (60 mm): no adjustment is necessary.
• 2 3/4" (70 mm): see the Adjust latch section.
3 Install the latch.
3a Install backplate.
This backplate
is backward.
Rotate into
place. Notch
goes here.
3a Install drive-in faceplate.
Push to snap.
3b Add faceplate and secure with
screws.
Bevel must face
door frame!
Actual Size (2)
3b Use wood block and hammer.
Bevel must face
door frame!
4 Install the strike onto the door frame.
Actual Size (2)
Use included strike for
best performance.
5 PRIVACY FUNCTION ONLY: Choose privacy pin location.
Location is based on preference and does not change the function.
Pin on bottom, go on to step 6.
Pin on top, go to
Schlage.com/faqs-custom.
6 Identify the exterior and interior chassis
Pegs
Interior
Chassis
Posts
Slots
Exterior
Chassis
7 Install the exterior chassis.
Push rmly!
8 Install the interior chassis.
8a Chassis is spring-loaded. Push pegs into
slots and hold in place.
8b Secure with two (2) screws.
Hold in place!
Actual Size (2)
Make sure
chassis is
straight!
9 Install the trim.
L
Align hole in trim with hole in chassis.
click
hook
OR
click
hook
Repeat for the other side of the door.
10 Install the exterior knob/lever.
10a Push knob/lever rmly into
place.
10b Then tighten set screw.
11 PRIVACY FUNCTION ONLY: Install the privacy pin.
Follow the included
Privacy function kit instructions.
12 Install the interior knob/lever.
12a Push knob/lever rmly into
place.
12b Then tighten set screw.
Adjust latch
For 2 3/4" backset, rotate and pull latch out to long setting.
2 1/8" (54 mm)
hole
Backset
2 3/8" or 2 3/4"
(60mm or 70mm)
1 3/8" - 1 3/4"
(35mm) - (44mm)
1" (25 mm) hole
OR
OR
OR
Emergency
unlock tool
Privacy pin
Pin cap
Model FC21, Combined interior Installation Instructions
