Side 1/4

Industrial/Medical Grade

Washable Backlit Keyboard

Installation Guide

Introduction

The Industrial/Medical Grade Washable Backlit

Keyboard with Pointing Device is a silicone sealed

IP68 rating, easy to clean keyboard that's suited

for industrial, medical and manufacturing

environments.

Key Features and Benefits

• Compact and space saving QWERTY

keyboard with 89 keys

• Rugged and fully sealed & compliant with

IP68 rating

• Adjustable LED backlit brightness levels

• Integrated pointing device

• Easy to clean surface

• Nano Silver antibacterial technology

Package Contents

• Industrial/Medical Grade Washable Backlit

Keyboard with Pointing Device

• Waterproof cap

• Installation guide

System Requirements

• PC or Mac computer with an available USB

port

• Windows

8 (32-/64-bit) / 7 (32-/64-bit)

/ Vista (32-/64-bit) / XP (32-/64-bit)

• Windows Server

2003 & 2008 (32-/64-bit)

/ 2008 R2 / 2012/ 2012 R2

• Mac

X v10.6 or later

1. ON/OFF button: Press the ON/OFF button

for 5 seconds to turn on / off the power

of the keyboard.

NOTE: To clean the keyboard, press ON/

OFF button for 5 seconds to shut it down

before cleaning

2. Light down: Press and hold the Fn key,

then press F11 to turn down the light.

3. Light up: Press and hold the Fn key, then

press F12 to turn up the light.

4. Num Lock LED indicator: On: enabled,

Off: disabled

5. Light on/off: Press to turn on/off the

backlight

6. Waterproof cap

Important: Always cover the keyboard's

USB port completely and securely with

the attached waterproof cap before

washing the keyboard

7. Scroll Lock LED indicator: On: enabled, Off:

disabled

8. Right Mouse Button: Functions as right

mouse button

Figure 1: Layout

1 2 3 5

9 8 6710

04-0973A

1 2

Specifications

• USB cable:

- Hard wired

- Type A, Male

- Compliant with USB 2.0 specification

- Length: Approx. 5 ft

• Key switch:

- Number of keys: 89 keys

- Letter key press force: 100+/- 10g

- Key travel: 2.0+/- 0.5mm

- Key switch life: ~ 2 million cycles

• Pointing Device:

- New low power, sealed, optical pointing

device

- DPI: 800~1,000

• Backlit: 4 levels brightness adjustable and

memorized

• Keyboard dimensions: 11.26"(W) x 0.43"

(H) x 5.83"(D)

• Weight: 1.32 lbs

• Color: Black

• Environmental conditions:

- Operating temperature: -40 to 140 F

- Storage temperature: -58 to 140 F

- Operating humidity: 100% RH

• Power consumption:

- Operating voltage: 5V +/- 5%

- Working current with LEDs on: 250 mA

(Max)

- Working current with LEDs off: 30mA

• Certifications/Standards: FCC, CE, RoHS

• Warranty: 2 years limited

• Country of origin: China

Layout

9. Track Pointer: Pointing device

10. Left Mouse Button: Functions as left mouse

button

11. Caps Lock LED indicator: On: uppercase,

Off: lowercase

Attention

• Use a soft cloth or sponge to clean

• To protect the keyboard surface, DO

NOT use a stiff brush or hand scrub it

when cleaning

• DO NOT use corrosive cleaning

solvents for cleaning

• DO NOT expose the keyboard to

temperatures above 140 F

Technical Support and Warranty

QUESTIONS? SIIG’ s Online Support has answers! Simply visit our web site

at www.siig.com and click Support. Our online support database is updated

daily with new drivers and solutions. Answers to your questions could be just

a few clicks away.

You can also submit questions online and a technical support analysts will

promptly respond.

SIIG offers a 2-year manufacturer warranty with this product. This warranty

covers the original purchaser and guarantees the product to be free of any defects

in materials or workmanship for two (2) years from the date of purchase of the

product.

SIIG will, at our discretion, repair or replace (with an identical product or

product having similar features and functionality) the product if defective in

materials or workmanship. This warranty gives you specific legal rights, and

you may also have other rights which vary from state to state. Please see our web

site for more warranty details.

If you encounter any problems with this product, please follow the procedures

below.

A) If it is within the store's return policy period, please return the product to the

store where you purchased from.

B) If your purchase has passed the store's return policy period, please follow the

steps below to have the product repaired or replaced.

Step 1: Submit your RMA request.

Go to www.siig.com, click Support, then RMA to submit a request to

SIIG

RMA or fax a request to 510-657-5962. Your RMA request will be processed,

if the product is determined to be defective, an RMA number will be issued.

Step 2: After obtaining an RMA number, ship the product.

• Properly pack the product for shipping. All accessories that came with

the original package must be included.

• Clearly write your RMA number on the top of the returned package.

SIIG will refuse to accept any shipping package, and will not be

responsible for a product returned without an RMA number posted on

the outside of the shipping carton.

• You are responsible for the cost of shipping to SIIG. Ship the product to

the following address:

SIIG, Inc.

6078 Stewart Avenue

Fremont, CA 94538-3152, USA

RMA #:

• SIIG will ship the repaired or replaced product via Ground in the U.S.

and International Economy outside of the U.S. at no cost to the customer.

4 5 6

PRODUCT NAME

Industrial/Medical Grade Washable Backlit Keyboard

FCC RULES: TESTED TO COMPLY WITH FCC PART 15, CLASS B

OPERATING ENVIRONMENT: FOR HOME OR OFFICE USE

FCC COMPLIANCE STATEMENT:

This device complies with part 15 of the FCC Rules. Operation is subject

to the following two conditions: (1) This device may not cause harmful

interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

THE PARTY RESPONSIBLE FOR PRODUCT COMPLIANCE

SIIG, Inc.

6078 Stewart Avenue

Fremont, CA 94538-3152, USA

Phone: 510-657-8688

About SIIG, Inc.

Founded in 1985, SIIG, Inc. is a leading manufacturer of IT connectivity

solutions (including Serial ATA and Ultra ATA Controllers, FireWire, USB,

and legacy I/O adapters) that bridge the connection between Desktop/

Notebook systems and external peripherals. SIIG continues to grow by

adding A/V and Digital Signage connectivity solutions to our extensive

portfolio.

SIIG products offer comprehensive user manuals, many user-friendly features,

and are backed by an extensive manufacturer warranty. High quality control

standards are evident by the overall ease of installation and compatibility of

our products, as well as one of the lowest defective return rates in the industry.

SIIG products can be found in computer retail stores, mail order catalogs,

through major distributors, system integrators, and VARs in the Americas

and the UK, and through e-commerce sites.

Industrial/Medical Grade Washable Backlit Keyboard is a trademark of SIIG,

Inc. SIIG and the SIIG logo are registered trademarks of SIIG, Inc. Microsoft and

Windows are registered trademarks of Microsoft Corporation. All other names

used in this publication are for identification only and may be trademarks of their

respective owners.
