Introducing Your MiniTouch Plus

The MiniTouch Plus has all the features and functions of

a standard 101-key keyboard in two-thirds the size. It

provides compact, space-saving benefits without giving

up the power and the extended functions offered by a

full-sized 101-key keyboard.

Features and Benefits

• 80-key mini-keyboard with 12 function keys

• PS/2 and IBM AT enhanced 101/102-key keyboard

compatible

• PS/2 or AT (5-pin DIN) keyboard connector

(depending on the model purchased)

• Separate Scroll Lock, Num Lock, and Caps Lock

LED indicators

• Embedded numeric keypad with cursor and screen

control capabilities

• Special Fn key for accessing the cursor and screen

control keys, F11 and F12 key functions, and

embedded numeric keypad

• Ctrl and Alt keys, one on each side for added

convenience

• High-quality keyswitches for the click and feel that

typists prefer

• Standard QWERTY keyboard layout

• Snap-open legs for height adjustment

MiniTouch Plus

Quick Installation Guide

04-0131B

Specifications

Electrical characteristics:

• Input power: +5V DC

• Switch activation mechanism: Conductive rubber

Physical & mechanical characteristics:

• Connector type : PS/2 or AT (5-pin DIN)

• Number of keys: 80

• Key switch life: 20 million cycles

• Travel distance: 3.0 + 0.5 mm

• Dimensions: 11 5/8" (L) x 6" (W) x 1 1/2" (H)

• Weight: 1.6 lbs

Environmental operating conditions:

• Operating temperature: 32o F to 130o F

• Storage temperature: 10o F to 160o F

• Relative humidity: 20% to 95%, non-condensing

• Altitude: –1000 ft. to 10,000 ft.

Package Contents

•MiniTouch Plus

• Quick Installation Guide

Setting Up Your Keyboard

Turn your computer OFF before plugging the keyboard

into your computer. The keyboard's connector is keyed

for proper insertion. Use the snap-open legs on the

bottom of the keyboard to adjust the slant/height for

your comfort.

Produkt Specifikationer

Mærke:	SIIG
Kategori:	Tastatur
Model:	MiniTouch PS/2 Plus
Produktfarve:	Sort
Opbevaringstemperatur (T-T):	-12 - 71 °C
Driftstemperatur (T-T):	0 - 54 °C
Forbindelsesteknologi:	Ledningsført
Enhedsgrænseflade:	PS/2
Tastatur vægt:	725 g
Mus inkluderet:	Ingen
Antal taster på tastatur:	80
Tastaturopsætning:	QWERTY
