Side 1/3
Need more information?
Potrzebujesz więcej informacji?
SILENTIUMPC.COM/SPC308
Accessories / Akcesoria
A
×1
B
×4
C
×4
D
×1
×4
×1
G
×4
H
×4
I
×1
J
×2
K
×1
PH2
screwdriver /
wkrętak
LGA1700
go to
LGA1200 / 115X
A
1
to / idź do
-3°
LGA2066 / 2011-3
B
2
go to / idź do
Choose the socket / Wybierz podstawkę - LGA1700 LGA1200, 115X LGA2066, 2011-3/ /
Motherboard / Płyta główna
C
1
2
D
3
E
4
K
5
6
7 A
H ×4
G ×4
F ×1
7 B
F
H
7 C
G
F
H
Fortis 5 A BRG
I E 1 1NT L: 700 / 200 / 115X 201/ 2066 / 1-3
20211029
Need more information?
Potrzebujesz więcej informacji?
SILENTIUMPC.COM/SPC308
8 A
F
J
8 B
F
J
J
8 C
9
4-PIN PWM
MOTHERBOARD /
YTA GŁÓWNA
EN: The red line shows the connection required for automatic control of the Fortis 5 fans' speed via motherboard. Connect the individual elements according to the red diagram.
PL: Czerwona linia pokazuje połączenie niezbędne do automatycznej kontroli wentylatorów w Fortis 5 przez płytę główną. Połącz poszczególne elementy wg czerwonego schematu.
!
CPU_FAN, CPU_OPT
PUMP, SYS_FAN
EN: A IONAL 4-PIN DDIT
PWM CONNECTOR
PL: DODATKOWE
ZŁĄCZE 4-PIN PWM
NANO-RESET ARGB
or / albo
3-PIN ARGB (5 V)
AU RA SYNC EVO PWMRO
ARGB CONT LLER /RO
KONTROLER AURORA SYNC
EVO PWM ARGB*
EN: Connect ARGB power and signal according to the green lines. You may use either a motherboard 3-pin ARGB header, an included Nano-Reset ARGB controller or separate
Aurora Sync EVO PWM ARGB controller.
PL: Podłącz zasilanie i sygnał sterujący oświetleniem ARGB zgodnie z zielonymi liniami. Użyj 3-pinowego złącza ARGB na płycie głównej, dołączonego kontrolera Nano-Reset ARGB lub
osobnego kontrolera Aurora Sync EVO PWM ARGB.
ARGB
* NOT INCLUDED / BRAK W ZESTAWIE
EN: A NAL 3-PIN ARGB (5 V) CONNECTORDDITIO
PL: DODATKOWE ZŁĄCZE 3-PIN ARGB (5 V)
EN: Tighten the
needed, you may use the
wrench to the remove
PL: Przykręć kołki
dystansowe (C) palcami.
W razie potrzeby
możesz użyć kluczyka do
odkręcenia kołków.
Fortis 5 ARGB
INTEL: 1 1 11700 / 200 / 5X 2066 1- / 01/ 2 3


Produkt Specifikationer

Mærke: SilentiumPC
Kategori: Ikke kategoriseret
Model: Fortis 5 ARGB
Type: Luftkøler
Bredde: 144 mm
Dybde: 207 mm
Højde: 159 mm
Vægt: 835 g
Produktfarve: Black, Grey, Steel
Pakkevægt: 1169 g
Pakkedybde: 140 mm
Pakkebredde: 165 mm
Pakkehøjde: 200 mm
Omdrejningshastighed (min.): 300 rpm
Omdrejningshastighed (maks.): 1400 rpm
Pakketype: Kasse
Harmoniseret systemkode (HS): 84733080
Monteringssæt: Ja
Gennemsnitstid mellem fejl (MTBF): 100000 t
Antal blæsere: 1 blæser(e)
Passende til rumtype: Processor
Ventilator diameter: 140 mm
Ventilatorstik: 4-pin + 4-pin
Understøttede procesorsokler: LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1700, LGA 2011 (Socket R), LGA 2011-v3 (Socket R), LGA 2066, Socket AM2+, Socket AM3+, Socket AM4, Socket FM1, Socket FM2+
Understøttelse af puls-bredde modulering (PWM): Ja
Ventilator tykkelse: 25 mm
Installationsvejledning: Ja
Antal klip: 4
Ventilatorlejeteknologi: Fluid Dynamic Bearing (FDB)
Antal varmerør: 6
