Silva Schneider Explore 2X Manual

Silva Schneider Lommelygte Explore 2X

Læs gratis den danske manual til Silva Schneider Explore 2X (1 sider) i kategorien Lommelygte. Denne vejledning er vurderet som hjælpsom af 19 personer og har en gennemsnitlig bedømmelse på 4.8 stjerner ud af 10 anmeldelser. Har du et spørgsmål om Silva Schneider Explore 2X, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/1

Visit: www.silva/enviroment

for more information about the

Waste Electrical and Electronic

Equipment (WEEE) Directive.

SILVA EXPLORE 2, EXPLORE 2X AND INTELLIGENT LIGHT

Thank you for choosing SILVA Explore 2 headlamp. This extra durable and waterproof head-

lamp is designed for use in rough environments.

Explore 2 is equipped with Intelligent Light

which is a light distribution technology that

combines a wide-angle flood light with a long reach spot light. This unique light image gives the

user peripheral and long distance vision at the same time.

PRODUCT OVERVIEW

The Explore 2/2X packaging consists of the following parts:

• Headlamp unit

• Head band

• USB charge cable (Explore 2X only)

• 3xAAA batteries (Explore 2 only)

• Helmet bracket including 3M adhesive

• Quick guide

BEFORE USE

Charging the Li-ion battery (Explore 2X)

Before first use the battery must be charged. Open the lid on the right-hand side of the headlamp

by turning the lid counter clock wise. Connect the charge cable and the red indicator LED will

light up. When the light is turns green, the battery is fully charged. Disconnect the charge cable.

Note! Make sure to close the lid when the charging is finished to assure water protection.

INSERT BATTERIES (EXPLORE 2)

Open the lid on the right-hand side of the headlamp by turning the lid counter clock wise. Note

polarity markings inside the headlamp body and insert the batteries.

Note!

• Make sure to close the lid when the batteries are inserted to assure water protection.

• Do not mix brands of batteries

• Do not mix new and old batteries

ADJUST THE HEADBAND

The elastic headband with anti-slip rubber on the inside is designed to give a comfortable fit at

times. Adjust the headband by moving the sliding buckle to fit it onto your head.

DURING USE

SWITCH ON YOUR HEADLAMP

On the left-hand side of the headlamp body there is a push button which controls all light

modes.

BATTERY STATUS INDICATION

When the headlamp is turned OFF, a small LED is turned on inside the front of the headlamp to

indicate the status of the batteries. This indication will be on for 3 seconds.

Explore 2X:

• Green light – Battery in good - medium condition

• Red light – Battery needs charging

Explore 2:

• Green light – Battery in good condition

• Orange light – Battery in medium condition

• Red light – Battery needs to be replaced

AFTER USE

MAINTENANCE

To make sure you get maximum performance from your Explore 2 headlamp, clean it regularly

with a damp cloth. Headset cleaning – wash in washing machine at 40ºC.

RECHARGEABLE BATTERY PRECAUTIONS (EXPLORE 2X)

• Explore 2X has an internal Li-ion battery and should be stored in a dry environment within

the temperature range of -20ºC to +35 ºC.

• If you would like to store your lamp for longer periods (more than 30 days) the battery

should be 50% charged. Recharge at least every 6 months.

• Do not expose the lamp with battery to extreme temperatures which may cause fire or

explosion.

• Do not disassemble or mistreat the battery, risk for chemical burn.

• Recharge only with a USB cable. The charger’s output voltage must not exceed 5 5V. Use

only a CE/UL approved charger, computer or portable power supply.

• Never leave the lamp unattended while charging.

TECHNICAL SPECIFICATIONS

Explore 2X:

Headlamp weight: 73g

Battery type: Li-Po, 700mAh, 3.7V

Light distance Max/Med/Min: 65m / 50m / 20m

Lumen Max/Med/Min: 250/150/50

Burn time: Max/Med/Min/Blink: 4h/6h/20h/30h

Charging time: 2.5h

Water resistance: IPX7

Operative temperature range: -20ºC - +60ºC

Storage temperature: -20ºC - +35 ºC

Explore 2:

Headlamp weight incl batteries: 88g

Battery type: 3xAAA alkaline

Light distance Max/Med/Min: 65m / 50m / 20m

Lumen Max/Med/Min: 250/150/50

Burn time Max/Med/Min/Blink: 30h/50h/90h/100h

Water resistance: IPX7

Operative temperature range: -20ºC - +60ºC

Storage temperature: -20ºC - +35 ºC

PROTECT THE ENVIRONMENT.

Headlamp and batteries should be recycled and must not be thrown in the regular trash.

Dispose these items in accordance with applicable local regulations.

WARRANTY

SILVA warrants that, for a period of two (2) years, your SILVA Product will be substantially free

of defects in materials and workmanship under normal use. SILVA’s liability under this war-

ranty is limited to repairing or replacing the product. This limited warranty extends only to the

original purchaser.

If the Product proves defective during the Warranty Period please contact the original place

of purchase. Make sure to have your proof of purchase on hand when returning the product.

Returns cannot be processed without the original proof of purchase. This warranty does not

apply if the Product has been altered, not been installed, operated, repaired, or maintained in

accordance with instructions supplied by SILVA, or has been subjected to abnormal physical

or electrical stress, misuse, negligence or accident. Neither does the warranty cover normal

wear and tear. SILVA is not responsible for any consequences, direct or indirect, or damage

resultant from use of this product. In no event will SILVA’s liability exceed the amount paid by

you for the product. Some jurisdictions do not allow the exclusion or limitation of incidental or

consequential damages, so the above limitation or exclusion may not apply to you. This War-

ranty is valid and may be processed only in the country of purchase.

For more information please visit www.silva.se

SHORT PRESS

LONG PRESS

MAX

MED

MIN

BLINK

OFF

RED

ORANGE

OFF

FULL VERSION MANUAL

EXPLORE 2 / EXPLORE 2X

EXPLORE 2

Art.no 37643

EXPLORE 2X

Art.no 37644

Produkt Specifikationer

Mærke:	Silva Schneider
Kategori:	Lommelygte
Model:	Explore 2X
Kode for international beskyttelse (IP):	IPX7
Antal effektniveauer:	3
Vægt:	47 g
Antal pr. pakke:	1 stk
Brugervejledning:	Ja
Produktfarve:	Sort
Batterispænding:	3.7 V
Batterikapacitet:	700 mAh
Lampe type:	LED
Batteriteknologi:	Lithium polymer (LiPo)
Driftstemperatur (T-T):	-20 - 60 °C
Husmateriale:	Acrylonitrile butadiene styrene (ABS), Thermoplastic urethane (TPU)
Vandfast:	Ja
Indikator for batteriniveau:	Ja
Kabler inkluderet:	USB
Batterier inkluderet:	Ja
Batterilevetid (maks.):	40 t
Batteritype:	Indbygget
Antal understøttede batterier:	1
Antal lamper:	1 Lampe( r)
Opladningstid for batteri:	2.5 t
Numre af batterier medfølger:	1 stk
Opladningskilde:	USB
Lommelygte type:	Hovedbånd lommelygte
Lysstråle afstand (maks.):	40 m
Lys output (maks.):	250 lm
Antal lystilstande:	5
Lys output (min.):	50 lm
Lysstråle afstand (min.):	20 m
