Side 1/33

PRIME C2 PRO

EVERY DAY CARRY LIGHT

2 ENG USER MANUAL

6 GER BENUTZERANLEITUNG

10 FRA MANUEL D’UTILISATEUR

14 RUS РУКОВОДСТВО ПОЛЬЗОВАТЕЛЯ

18 FIN KÄYTTÖOHJE

22 SWE ANVÄNDARMANUAL

26 NOR BRUKSANVISNING

30 POL INSTRUKCJA OBSŁUGI REV_00-0001

2 ENG USER MANUAL Prime C2 PRO

REV_00-0001

Specifications

Every Day Carry light: compact design, convenient side button,

special matt anti-abrasive finish without rough knurling. Durable nylon

holster, strong built-in tail magnet and robust removable steel clip

Bicycle light: body made from durable and lightweight aircraft-grade

aluminium, improved shock resistance, new springs for better bat-

tery and driver protection. Constant light without flickering, optional

quick-release mount

• Powerful electronics provides impressive light output of 2400 lumens

and record 6.5 months in Firefly mode. Constant brightness even at

low ambient temperatures and not fully charged battery

• Multicolor temperature, battery level and state indication with the

ability to turn o the latter

• Convenient wide beam of fully upgraded optical system, TIR-lense

is protected from scratches by tempered glass with anti-reflective

coating

• Innovative technology allows using any 18650 Li-Ion batteries with

10A discharge current and provides full protection against short

circuit even in case of contact between magnetic connector and metal

objects

• Active real-time temperature control to prevent overheating above

+58 °C

• Total protection from water, dirt and dust in accordance with IP68

standard — flashlight continues to work even at 10 meters depth.

Withstands fallings from up to 10 meters

• Robust and water resistant magnetic connector

ENG USER MANUAL

Thank you for choosing the products of Armytek.

Please read this manual carefully before using the flashlight.

Model Prime С2 Pro (White)

LED/Optics Cree XHP50.2/TIR

Brightness stabilization type FULL (constant light)

Light output 2400 lm

Peak beam intensity 3800 cd

Hotspot : Spill 70°:120°

Beam distance 123 m

Modes, light output and runtimes (measured

with 18650 Li-Ion 3500 mAh battery until the

light output drops to 10% of the initial value)

Turbo3 2400 lm/2 h 48 min (610 lm after 30 sec)

Turbo2 1710 lm/2 h 48 min (610 lm after 1 min 30 sec)

Turbo1 815 lm/2 h 44 min (610 lm after 22 min)

Main3 350 lm/5 h 20 min

Main2 150 lm/12 h 30 min

Main1 40 lm/40 h 30 min

Firefly3 5 lm/12 d

Firefly2 1 lm/40 d

Firefly1 0.15 lm/200 d

Strobe3 2400 lm/10 Hz/5 h 45 min (610 lm after 2 min)

Strobe2 2400 lm/1 Hz/12 h (610 lm after 10 min)

Strobe1 150 lm/1 Hz/55 h

Power source 1x18650 Li-Ion

Length/Body diameter/Head diameter 117.7 mm/20.5 mm/25.4 mm

Weight without/with battery 68 g/118 g

Submersion and Impact resistance IP68, 10 m for 2 h. Height up to 10 m

X Light output for flashlights with Warm light is about 7% less, beam distance is about 3% less.

All the above specifications are test results based on ANSI/NEMA FL1-2009 Standard. The tests are performed using the battery included in the set.

The data may vary due to environment, heat dissipation and other factors.
