Side 1/2
2
G11226260
Superior 2U(AR09 series)/3U(AR10 series) server thermal
solution for Intel LGA 115X
AR09-115XP AR10-115XP
SilverStone AR09-115XP/AR10-115XP is a CPU cooler designed for 2U rackmount
server or small form factor cases. Its features three 6mm thick copper heat pipes
connected to the base using heat-pipe direct contact (HDC) technology and a dual
works efficiently with the included air duct to help quickly wick away heat for
exceptional CPU cooling performance.
Three Ø6mm heat-pipes and aluminum fins for excellent heat conducting efficiency
Heat-pipe direct contact (HDC) technology
Dual ball bearing PWM fan
Push-Pin design for convenient installation
Intel LGA1150/1151/1155/1156 compatible
SPECIAL FEATURESWarranty Information
Introduction
This product has a limited 1 year warranty in North America, Europe, and Australia.
For information on warranty periods in other regions, please contact your reseller or SilverStone authorized distributor.
1. Product component defects or damages resulted from defective production is covered under warranty.
Defects or damages with the following conditions will be fixed or replaced under SilverStone Technology’s jurisdiction.
a) Usage in accordance with instructions provided in this manual, with no misuse, overuse, or other inappropriate actions.
b) Damage not caused by natural disaster (thunder, fire, earthquake, flood, salt, wind, insect, animals, etc…)
c) Product is not disassembled, modified, or fixed. Components not disassembled or replaced.
d) Warranty mark/stickers are not removed or broken.
Loss or damages resulted from conditions other than ones listed above are not covered under warranty.
2. Under warranty, SilverStone Technology’s maximum liability is limited to the current market value for the product (depreciated value, excluding
shipping, handling, and other fees). SilverStone Technology is not responsible for other damages or loss associated with the use of product.
3. Under warranty, SilverStone Technology is obligated to repair or replace its defective products. Under no circumstances will SilverStone
Technology be liable for damages in connection with the sale, purchase, or use including but not limited to loss of data, loss of business, loss of
profits, loss of use of the product or incidental or consequential damage whether or not foreseeable and whether or not based on breach of warranty,
contract or negligence, even if SilverStone Technology has been advised of the possibility of such damages.
4. Warranty covers only the original purchaser through authorized SilverStone distributors and resellers and is not transferable to a second hand
purchaser.
5. You must provide sales receipt or invoice with clear indication of purchase date to determine warranty eligibility.
6. If a problem develops during the warranty period, please contact your retailer/reseller/SilverStone authorized distributors or SilverStone
. http://www.silverstonetek.com
Please note that: (i) You must provide proof of original purchase of the product by a dated itemized receipt; (ii) You shall bear the cost of shipping
(or otherwise transporting) the product to SilverStone authorized distributors. SilverStone authorized distributors will bear the cost of shipping
(or otherwise transporting) the product back to you after completing the warranty service; (iii) Before you send the product, you must be issued a
Return Merchandise Authorization (“RMA”) number from SilverStone. Updated warranty information will be posted on SilverStone’s official website.
Please visit for the latest updates.http://www.silverstonetek.com
Warranty terms & conditions
Additional info & contacts
For North America (usasupport@silverstonetek.com)
SilverStone Technology in North America may repair or replace defective product with refurbished product that is not new but has been functionally tested.
Replacement product will be warranted for remainder of the warranty period or thirty days, whichever is longer. All products should be sent
back to the place of purchase if it is within 30 days of purchase, after 30 days, customers need to initiate RMA procedure with SilverStone Technology
in USA by first downloading the “USA RMA form for end-users” form from the below link and follow its instructions.
http://silverstonetek.com/contactus.php
For Australia only (support@silverstonetek.com)
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
Please refer to above “Warranty terms & conditions” for further warranty details.
SilverStone Technology Co., Ltd. 12F No. 168 Jiankang Rd., Zhonghe Dist., New Taipei City 235 Taiwan R.O.C. + 886-2-8228-1238
(standard international call charges apply)
For Europe (support.eu@silverstonetek.de)
For all other regions (support@silverstonetek.com)
Apply included heatsink compound
on you CPU evenly.
Равномерно нанесите
прилагаемую термопасту на
процессор.
Tragen Sie die mitgelieferte
Wärmeleitpaste gleichmäßig auf Ihre
CPU auf.
Appliquez le dissipateur de chaleur
composé sur votre CPU de façon
régulière.
Aplique el compuesto conductor
térmico incluido en su CPU de forma
uniforme.
Applicare in modo uniforme sulla CPU
il composto termico per il dissipatore
di calore fornito in dotazione.
제공된 방열판 접착제를 CPU에
고르게 바릅니다.
請將散熱膏均勻地塗抹在CPU上。
请将散热膏均匀地涂抹在CPU上。
付属のヒートシンクコンパウンドを
CPUにむらなく塗ります。
Place the AR09-115XP/AR10-115XP
cooler on top of the installed CPU, and
align the four fasteners with the holes
on the motherboard.(Make sure each
fastener is oriented as shown, with the
arrow directed outward.)
Поместите кулер AR09-115XP/AR10-115XP
на верхнюю установленного ЦП часть ,
выровняйте четыре зажима и соответствующие
отверстия материнской платы.
( ,Убедитесь, что зажимы ориентированы так
как показано . на рисунке, т е. стрелка
направлена наружу .)
Setzen Sie den AR09-115XP/AR10-115XP
-Kühler auf die installierte CPU auf, achten
Sie darauf, dass die vier Halter über den
Aussparungen im Motherboard sitzen.
(Achten Sie darauf, dass die Halter wie in
der Abbildung ausgerichtet sind – der Pfeil
zeigt nach außen.)
Placez le AR09-115XP/AR10-115XP
par-dessus le processeur installé, et
alignez les 4 fixations rapides avec les
trous de la carte mère. (Vérifiez bien que
chaque fixation rapide est orientée comme
montré,avec la flèche dirigée vers l’extérieur.)
ISitúe el disipador AR09-115XP/AR10-115XP
sobre la CPU instalada y alinee los cuatro
cierres con los agujeros de la placa base.
(Asegúrese de que cada cierre se oriente de
la forma que se muestra, con la flecha hacia
el exterior).
Posizionare il cooler AR09-115XP/AR10-115XP
sul CPU installato ed allineare i quattro ganci
con i fori della scheda madre
(assicurasri che ciascun gancio sia orientate
come mostrato, con la freccia diretta verso l’
esterno).
AR09-115XP/AR10-115XP를 장착된 CPU
위에 위치하고, 4개의 고정 핀을 메인보드의
구멍에 정렬합니다.
( 반드시 고정핀이 그림과 같이 화살표
방향이 바깥쪽으로 위치하도록 합니다. )
將AR09-115XP/AR10-115XP 散熱器置於已安裝
CPU上方，並將四個散熱器螺絲對準主機板上的
孔位。（請確認每個散熱器螺絲的方向與附圖
上的箭頭方向一致）
将 散热器置于已安装AR09-115XP/AR10-115XP
CPU上方，并将四个散热器螺丝对准主板上的孔位。
（请确认每个散热器螺丝的方向与附图上的箭头
方向一致）
AR09-115XP/AR10-115XPクーラーをインストー
ルされた CPUの上に置き、マザーボードの4つの
穴に4個のファスナーを合わせます。
（各ファスナーは図のように矢印を外向きにしてください。）
Specifications
SST-AR09-115XP
Copper heat pipes
with aluminum fins
Intel LGA
1150/1151/1155/1156
Ø6mm heat-pipe x 3
60mm x 60mm x 25mm fan
93mm (W) x 93mm (D)
x 66mm (H) (with Fan)
18.02 ~ 42.5dBA
Dual ball bearing
215g (without fan)
12V
9.6V
0.33 ~ 4.83mmH2O
6.7 ~ 27.9CFM
1200 ~ 5000RPM
70,000 hours
Model No.
Material
Application
Heat Pipe Type
Cooling System
Dimension
Noise
Bearing
Net Weight
Voltage Rating (V)
Start Voltage (V)
Max air pressure
Air Flow (CFM)
Speed (R.P.M.)
Life Expectance (hrs)
SST-AR10-115XP
Copper heat pipes
with aluminum fins
Intel LGA
1150/1151/1155/1156
Ø6mm heat-pipe x 3
70mm x 70mm x 15mm fan
93mm (W) x 93mm (D)
x 79mm (H) (with Fan)
18.07 ~ 39.03dBA
Dual ball bearing
240g (without fan)
12V
9.6V
0.08 ~ 4.83mmH2O
4.83 ~ 19.49CFM
500 ~ 4000RPM
70,000 hours
