EX3-8K
HDMI 2.1 (40Gbps) 90m Extender with eARC,
1Gb LAN, IR, RS232, & USB 2.0
VER 1.1
Thank you for purchasing this device
The Simplified MFG EX3-8K was designed to provide years of reliable service.
At Simplified MFG we want your experience with this device to be the best
possible and are committed to helping achieve that experience. Please read
and keep this manual for future reference.
Surge protection device recommended
This product contains sensitive electrical components that may be damaged
by electrical spikes, surges, electric shock, lighting strikes, etc. Use of surge
protection systems is highly recommended to protect and extend the life of
your equipment. Set top boxes (cable and satellite) can pass surges through
the HDMI connection, a Simplified MFG HDSURGE is suggested.
Table of Contents
1. Introduction. ..............................................................................
1
2. Features. ....................................................................................
1
3. Package Contents. .....................................................................
2
4. Specifications. ............................................................................
2
5. Operation Controls and Functions……………………………………..5
5.1 Transmitter Panel
..................................................................5
5.2 Receiver Panel
………………………………………………………….8
5.3
USB Mode Applications………………………………………………10
5.4
IR Pin Definition……………………………………………………….11
6. Application Example………………………………………………………12
7.
Warranty……………………………………………………………………..13
8. Contact………………………………………………………………………..14
**Please use 568b protocol when terminating the category cable.
