Side 1/16

 

 

 

 

 

 

 

 

 

 

 

 

 

 

KSG52HPE

KSG70HPE

The product is designed for the extraction of cooking fumes

and steam and it is for domestic use only.

Strictly observe the instructions in this manual. No

liability shall be accepted for any inconvenience, damage

or fire caused to the product as a result of not following the

instructions given in this manual.

The device may have different aesthetic features with

respect to the illustrations in this handbook, however

the operating, maintenance and installation

instructions remain the same.

• It is important to keep all the manuals accompanying the

product so that they can be consulted at all times. If sold,

transferred or moved, make sure it remains with the

product. • Read the instructions carefully: they contain

important information on installation, operation and safety. •

Check the integrity of the product prior to its installation.

Otherwise, contact the dealer and do not continue with the

installation.

NOTES

: the items marked with this symbol are optional

accessories supplied only with some models or items that

cannot be supplied but can be purchased.

1. SAFETY AND REGULATIONS

GENERAL SAFETY

•Do not make electrical or mechanical changes on the

product or on the exhaust pipes. •Before doing any cleaning

or maintenance work, disconnect the product from the

mains power supply by removing the plug or turning off the

mains switch. •For all installation and maintenance

operations, always wear work gloves. •The product can be

used by children over the age of 8 and by people with

reduced physical, sensory or mental capabilities or without

experience or the necessary knowledge, as long as they

are properly supervised or have been instructed on how to

safely use the device and understand the inherent dangers.

•Children must be supervised to make sure that they do not

play with the product. •Cleaning and maintenance must

never be performed by children unless they are properly

supervised. •The room must have sufficient ventilation

when the product is used at the same time as other

appliances burning gas or other fuels. •The product must be

cleaned frequently both inside and out (AT LEAST ONCE A

MONTH); always follow the instructions given in the

maintenance manual. •Failure to comply with the rules

indicated for cleaning the product and replacing/cleaning

the filters may result in the risk of fire. •It is strictly forbidden

to cook food on the flame under the product.• WARNING:

•When the hob is on, the accessible parts of the product

may become hot. •Do not connect the product to the

electrical power supply until the installation is complete.

•The regulations laid down by local authorities must be

strictly followed with regard to the technical and safety

measures to adopt for fume extraction. •The extracted air

must not be conveyed through the same ducts used to

extract the fumes generated by gas combustion or other

types of combustion products. •Do not use or leave the

product without appropriately installed lamps, as this may

result in the risk of electric shock. •The product must

NEVER be used without the grille correctly fitted. •The

product must NEVER be used as a support surface unless

expressly indicated.

● Range hoods and other cooking fume extractors may

adversely affect the safe operation of appliances burning

gas or other fuels (including those in other rooms) due to

back flow of combustion gases. These gases can

potentially result in carbon monoxide poisoning. After

installation of a range hood or other cooking fume

extractor, the operation of flued gas appliances should be

tested by a competent person to ensure that back flow of

combustion gases does not occur.

• To replace the lamp, only use the lamp indicated in the

maintenance/lighting system section of this manual. • Using

a naked flame may damage the filters and cause a fire

hazard, and must therefore be avoided under all

circumstances. • Extra care must be taken when frying to

prevent the oil from overheating and catching fire. • In case

of doubt, contact the authorised service centre or similar

qualified personnel.

INSTALLATION SAFETY

•Use the fixing screws supplied with the product only if

suitable for the surface; otherwise purchase the correct

type of screws. •Check for accessories (e.g. bags

containing screws, warranty certificates, etc.) inside the

product (placed there for transport reasons). If there are

any, remove them and keep them safe. • WARNING:

Failure to install screws and fasteners in accordance with

these instructions may result in electrical hazards. •The

exhaust pipe is not supplied and must be purchased. •The

diameter of the exhaust pipe must be equivalent to the

diameter of the connecting ring. •For installation of the

product on the hob, respect the height indicated in the

drawings •The minimum distance between the surface of

the container supports on the cooker and the lowest part of

the range hood must not be less than 45 cm (not less than

65 cm only for Australia and New Zealand) for electric

cookers and 65 cm for gas or mixed cookers. •If the

installation instructions of the gas cooker specify a greater

distance, take it into account.

ELECTRICAL CONNECTION SAFETY

•The mains voltage must correspond to the voltage

indicated on the label found inside the product. •If it

features a plug, connect the product to a socket that

complies with current standards, located in an area

accessible even after installation. •If it does not feature a

Produkt Specifikationer

Mærke:	Smeg
Kategori:	Emhætte
Model:	KSG52HPE
Type:	Indbygget
Vekselstrømsindgangsspænding:	220 -240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	514 mm
Dybde:	283 mm
Vægt:	5800 g
Produktfarve:	Rustfrit stål
Kontroltype:	Knapper
Antal hastigheder:	3
Indbygget skærm:	Ingen
Motoreffekt:	175 W
Ledningslængde:	1 m
Pakkevægt:	7400 g
Pakkedybde:	323 mm
Pakkebredde:	334 mm
Pakkehøjde:	572 mm
Årligt energiforbrug:	75 kWh
Strømforbrug (standby):	0.49 W
Tilsluttet belastning:	285 W
Lampetype:	LED
Støjniveau:	65 dB
Energieffektivitetsskala:	A+++ til D
Pæreeffekt:	5 W
Energieffektivitetsindeks (EEI):	69.6
Farvetemperatur:	2700 K
Antal lyskilder:	2 pære(r )
Maksimal ekstraktionseffekt:	580 m³/t
Fedtfilter type:	Aluminium
Aftageligt filter:	Ja
Belysningsstyrke:	221 Lux
Højde (maks.):	251 mm
Støjniveau (lav hastighed):	46 dB
Væske - dynamisk effektivitetsklasse:	C
Lys - effektivitetsklasse:	A
Fedt - filtrering effektivitetsklasse:	C
Belysningsposition:	Front
Antal filtre:	1 stk
Minimum afstand fra elektrisk komfur:	500 mm
Minimum afstand fra gaskomfur:	650 mm
Tryk (Pa):	355
