19” Rack Personal SSL Recording Studio
SSL 18 has all the flexibility you’d expect from an SSL equipped studio: a dedicated talkback input with the famous LMC (listen mic
compressor), alternative speaker switching, flexible headphone outputs that can be reconfigured to work with any set of headphones and
the ability to re-purpose outputs 9 and 10 as analogue insert sends on inputs 1 and 2, perfect for tracking with analogue processing in-
line.
SSL 18 Mixer Powered by SSL 360°
The SSL 18’s on-board low-latency mixer is controlled via SSL 360° – the place where you can dial in headphone mixes, adjust metering
preferences, customise the front panel buttons and much more. Think of it as your virtual SSL console environment, perfect for
managing busy sessions all from one place.
Engineered For Excellence
Designed by the same engineering team behind the esteemed range of analogue and digital mixing consoles, SSL’s rich heritage and
know-how for multi-track audio is laced throughout the design. From the class-leading microphone preamps to the choice of industry-
grade components like Alps® pots and Neutrik® connectors, SSL 18 delivers the kind of quality you’d expect from a world-class
recording studio, directly to your own studio.
Features
26-in/28-out USB audio interface for Mac and Windows
8 x SSL-designed microphone/line-level inputs
4K analogue enhancement, Polarity Invert, High-Pass Filters and 48V Phantom Power per channel.
Line inputs bypass preamp – perfect for integrating external preamps Configurable analogue insert points for inputs 1 and 2,
great for tracking with analogue gear
Inputs 1 and 2 switchable to instrument-level
10 x DC-coupled, balanced line-outputs
Alternative speaker switching available for pairs 1&2 and 3&4
+9 dBu/+24 dBu output level configuration options for pairs 1&2 and 3&4 to best match your monitors
DC-coupled outputs are perfect for sending control voltages to synthesisers and modular rigs
2 x independent, powerful headphone outputs with dedicated level controls
3 mode options to suit different headphone impedances – Standard, High Sensitivity, High Impedance
Create custom headphone mixes
Re-purpose as line outputs
Dedicated Talkback input with Listen Mic Compressor (LMC).
Talkback input can also be used in LINE mode for creative processing of stems through the LMC when mixing
+24 dBu operating level for inputs and outputs - perfect for integrating professional outboard gear as hardware inserts.
16 channels of ADAT I/O at 44.1/48 kHz, 8 channels at 96 kHz
2 channels of S/PDIF (coaxial or optical)
