Digital clamp meter for photovoltaic installations

CMP-1015-PV

index: WMGBCMP1015PV

Robust design

With the help of the latest tech-

nologies, a compact instrument

for working in the toughest con-

ditions has been created. The rub-

ber housing protects the device

against accidental damage.

Visibility in any conditions

Working in full sun is not difcult

thanks to the high-brightness dis-

play. Darkness in the workplace is

not a problem thanks to the built-

in flashlight.

Multifunctional

The device is versatile due to many

measurement options. In addition

to the basic measurements, the

instrument has a recorder with

graphs, as well as special func-

tions, including inrush current (IN-

RUSH), AC and DC voltage com-

ponents, low-impedance voltage

measurement (Low Z).

Modern clamp

The innovative shape means

easier access in hard to reach

and tight places, as the basis for

mounting special voltage adapt-

ers. The clamp edging is equipped

with a contactless voltage indica-

tor sensor.

Photovoltaics under

close control

The device is dedicated to mea-

sure DC current and voltage in

photovoltaic installations with

voltages of 1500 V. The meter

also provides precise measure-

ments downstream of frequen-

cy converters thanks to the VFD

function.

Wireless communication

Transfer measurement data via

Bluetooth, in “live” mode and

from internal memory to the So-

nel Multimeter Mobile applica-

tion. This allows to record and

store the results and include addi-

tional description or photos. You

can also share measurement data

as an e-mail attachment.

measurement of

PV installations

Voltage measurement up to

3000 V DC

The AHV-3 adapter is used to

measure high DC voltages (up

to 3000 V DC) in collaboration

with a master meter.

page 2 / 3 sonel.com

m.v. - measured value

Technical specications

Measurement functions Range Resolution Accuracy

±(% m.v. + digits)

AC current up to 1000 A from 0.01 A ±(2.5% m.v. + 5 digits)

DC current up to 1000 A from 0.01 A ±(2.0% m.v. + 8 digits)

AC voltage up to 1000 V from 0.001 mV from ±(1.2% m.v. + 5 digits)

DC voltage up to 1500 V from 0.1 mV from ±(0.5% m.v. + 5 digits)

AC+DC voltage up to 1000 V from 0.001 V from ±(1.5% m.v. + 20 digits)

Low Z (AC / DC voltage) up to 1000 V from 0.001 V ±(3.0% m.v. + 40 digits)

Low Z AC+DC up to 1000 V from 0.001 V ±(3.5% m.v. + 40 digits)

Resistance up to 60.00 MΩ from 0.1 Ω from ±(0.8% m.v. + 5 digits)

Frequency up to 10.00 MHz from 0.01 Hz ±(0.2% m.v. + 5 digits)

Capacitance up to 100.0 mF from 0.01 nF from ±(3.0% m.v. + 8 digits)

Duty cycle (%) 10.0…90.0% 0.1% ±(1.2% m.v. + 8 digits)

Temperature measurement -40.0…+1000ºC

-40.0…+1832ºF

0.1ºC

0.1ºF

±(1.5% m.v. + 3ºC)

±(1.0% m.v. + 5.4ºF)

Continuity / Diode test ✓ ✓ /

Basic features

HOLD ✓

Automatic range selection ✓

Advanced features

Current and voltage measurements downstream

the inverter, frequency converter or in the

VFDsystem

✓

High voltage DC measurement (HVDC) ✓

Inrush current ✓

Non-contact voltage detector ✓

MIN / MAX ✓ ✓ /

PEAK HOLD ✓

Relative measurement REL ✓

TRMS measurement ✓

Memory : :

internal measurements: 128 results

recorder: 16 recordings, 100 000 points, sampling frequency: from 1 Hz

external in mobile application

Bluetooth communication ✓

Other features

Auto-off ✓

Battery indication ✓

Integrated flashlight ✓

Beeper ✓

Display

Type graphical LCD

Display backlight ✓

Safety and conditions for use

Measuring category (EN 61010) CAT IV 600 V

CAT III 1000 V

Ingress protection IP40

Dimensions 273 x 96 x 48 mm 10.7” x 3.8” x 1.9”|

Operating temperature 5...40ºC 41...104°F|

Storage temperature -20…+60ºC -4...140°F|
