Side 1/2

SPEAKMAN

400 Anchor Mill Rd. New Castle, DE 19720 Phone: 800-537-2107 Fax: 800-977-2747

02/01/18 www.speakman.com 92-SE-570-01

SPEAKMAN

SE-570

Installation, Operation & Maintenance Instructions

EYESAVER® EYEWASH

DESCRIPTION

Deck mounted emergency eyewash. Supplied with a ¼ turn ceramic PERFECT® valve that is activated when

the eyewash is rotated 90° over an open sink. Unit is supplied with an adjustable flow regulator. Aerated

spray outlets with individual flow restrictor, and flip-off dust covers. Unit mounts on counter tops up to

2-1/4” thick.

SPECIFICATIONS

SPRAY HEADS: (2) AERATED YELLOW ABS SPRAY OUTLET, SPRAY FACE, AND DUST COVERS

VALVE: ¼ TURN CERAMIC PERFECT VALVE®

FLOW REGULATOR: BRASS, CHROME-PLATED

INLET: 1/2" NPT MALE

SHIPPING WEIGHT: 6 LB

EMERGENCY SIGN: 7-7/8” X 7-7/8” PLASTIC WALL SIGN

Options:

ILS

In-Line Strainer

Left-Hand Operation

INSTALLATION

NOTE: This unit should be connected to an uninterrupted

source of potable water, with a minimum flowing pressure

of 15 PSI and a maximum static pressure of 80 PSI.

Review drawing (as shown on other side) to assure proper installation. At desired location, use the supplied

deck plate to mark mounting holes. Drill the 1” diameter hole through the countertop (2-1/4” thick max.), and

drill the 1/4” diameter hole a minimum of 5/16” deep. Be sure the holes are drilled as straight as possible.

Place eyewash through drilled holes making sure the threaded shank & ¼” stop screw fit with no interference,

and that the eyewash is resting flat on the deck plate. Attach eyewash to countertop using the supplied

hardware. Install the supplied volume regulator (use thread sealant on all joints), making sure the adjustment

screw is facing in a direction that is easily accessible for later adjustment. Connect a water supply to unit that

is a 1/2” minimum uninterrupted source of potable water (use pipe sealant on connection). Failure to use

potable water can result in emergency units producing impure or contaminated water causing possible

further injury.

OPERATION

Be sure unit is above sink or drain before activating. The eyewash is activated by grasping the eyewash and

rotating it 90° to the full open position. Once the unit is activated, water will discharge from the spray outlets

until the eyewash is manually rotated back to the off position.

TESTING PROGRAM

The American National Standards Institute (ANSI) states that all safety emergency equipment shall be

activated on a weekly basis to flush the line and verify proper operation. Speakman Company furnishes a

testing record tag (91-0635) with each unit. On this tag the date of inspection and the inspectors initials

should be noted.
