Side 1/2

1.0 Introduction

A key component of a physical security electronic access control

system, a mobile-ready reader combining BLE and proximity

technologies is based on RFID technology. In operation it is capable of

reading data stored on a proximity credential via radio frequency—or

reading data from mobile credential stored in a smartphone’s wallet

app via BLE technology—and without physical contact, and then

passing the data obtained to the physical access control system.

Access control systems typically manage and record the movement of

individuals through a protected area, such as a locked door.

2.0 Mounting Provisions

Each reader may be installed either indoors or outdoors. Mounting

options shown in the table below. Use supplied #6 mounting screws,

or equivalent security screws, for installation.

Model Mullion Mount Single-Gang Wall Mount*

APCR35L

APCR35LAPCR35L • •

*Plastic or metal

3.0 Reader Wiring

Wiegand Magstripe

Conductor Function Conductor Function

Red DC (8-14 VDC) Red DC (8-14 VDC)

Black Ground Black Ground

Green Data 0 Green Clock

White Data 1 White Data

Brown Red LEDaBrown Red LED

Orange Green LEDbOrange Green LED

Yellow Card Present Yellow Card Present

Blue Beeper Blue Beeper

Violet ﬂeaPower Violet ﬂeaPower

Drain Shield Ground Drain Shield Ground

WIRING NOTES:

a Single Line LED: This is the standard operating mode and does not make use of the

Orange conductor. The LED is Red when the reader is idle and ﬂashes when a card is

presented. The LED turns Green when the Brown Conductor is pulled low by the access

control panel.

b Dual Line LED: This mode makes use of both the Brown and Orange conductors. The

Brown conductor controls the Red LED and the Orange conductor controls the Green

LED. LED states are determined by the access control system option and capability.

Unused conductors should be trimmed, isolated and taped back to prevent unintended

current ﬂows. Apply positive voltage only to the Red DC Conductor.

4.0 Cable Requirements

24 AWG minimum, multi-conductor stranded with an overall foil shield,

for example Belden 9535 or similar, supporting the ﬁve conductors

comprising the physical layer of the Wiegand interface (power, ground,

data 0, data 1, and/or beeper and LED). Alternatively, Belden 9539 or

similar, for all reader functions. Contact your access control system

manufacturer for their speciﬁc requirements. Per the SIA’s Wiegand

speciﬁcation, maximum cable length is 500 feet (152 m).

5.0 Output Formats

• Wiegand (industry standard 26-bit Wiegand

and custom Wiegand formats)

• Magnetic Stripe (ABA Track II, clock and data,

with card present)

6.0 Grounding

Shield (drain) continuity must run from the reader to the access panel.

Shield (drain) and reader ground must be tied together at the access

panel and connect to an earth ground at one point.

7.0 Power

Reader may be powered by the access panel. A linear power supply is

recommended for best operation.

8.0 Voltage and Current

Voltage: 8 to 14 VDC

Current Draw: 60mA typical, 90mA peak

9.0 ﬂeaPower™ Control Line

To reduce the average current required by the reader, pull the purple

conductor low.

10.0 Connection

Connection must be done in accordance with NFPA 70. Do not

connect to a receptacle controlled by a switch. Connect to a power

limited DC voltage source.

11.0 Troubleshooting

1. When the reader is ﬁrst powered on it will beep 4-times, and the

LED will shine red.

2. Presenting a supported access credential will result in the reader

beeping and the LED ﬂashing once.

3. Mobile operation is optimized for smartphones supporting BLE

(Bluetooth LE) version 4.2 or newer. Further, for the downloading

of mobile access credentials, a stable, high-quality internet

connection is recommended.

QUICK ART IDE ST GU

MOBILE-READY ROXIMI Y EADERS P T R

This Quick Start Guide is intended for experienced installing technicians. It is a basic reference to ensure all connections are properly made.

Models include . APCR35L

NOTE: The access panel controls LED functionality,

such as switching the LED to green.

If the reader does not recognize the mobile credential or card or tag

(no beep, no LED ﬂash) or exhibits short read range, please see the

table below for possible causes and solutions.

Possible Cause Corrective Action

Incorrect cabling Verify gauge, connections and

cabling length

Not enough power 12 VDC recommended

Incorrect credential used Verify if credential technology

is supported

Reader/access panel not

properly grounded

Earth ground needed—verify shield

and reader ground are tied at access

panel and connect to ground at

one point

Supply generating

interference

Linear power supply recommended,

verify switching power supply

before use

Should any of the corrective actions mentioned above not improve

performance, disconnect the reader from the access panel and power

it with a separate power supply or 9VDC battery, and re-test card

functionality. By powering the readers separately, most variables that

may lead to reduced performance can be eliminated. Should the

problem persist, please contact directly.Speco Technologies

Operating Temperature: –31° F to +150° F (–35° C to +66° C)

Operating Humidity: 0% to 90% Relative Humidity

IP Rating: IP67-rated for outdoor use

Access Control Performance Levels Conforming to UL STD 294:

Model

Destructive

Attack

Line

Security Endurance

Standby

Power

APCR35L

APCR35LAPCR35L Level I Level I Level IV Level I

Grade Classiﬁcation Certiﬁed to CAN/ULC STD 60839-11-1:

Risk Level Application

Skill/

Knowledge

of Attackers

Typical

Examples

Grade 2 Grade 2 Grade 2 Grade 2

Many Readers carry the following certifications:Speco Technologies

FCC Compliance Statement: This device complies with part 15 of the FCC rules.

Operation is subject to the following two conditions: (1) this device may not cause

harmful interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

Caution: Changes or modifications not expressly approved by could Speco Technologies

void the user's authority to operate the equipment.

Product can be used without license conditions or restrictions in all European Union

countries, including Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark,

Estonia, Finland, France, Germany, Greece, Hungary, Ireland, Italy, Latvia, Lithuania,

Luxembourg, alt M a, etherlands, land, rtugal, omania, N Po Po R Slovakia, pain, S

Sweden, United Kingdom, as well as other non-EU countries, including Iceland,

Norway, nd witzerland. a S

This device contains licence-exempt transmitter(s)/receiver(s) that comply with

Innovation, Science and Economic Development Canada’s licence-exempt RSS(s).

Operation is subject to the following two conditions: (1) This device may not cause

interference. (2) This device must accept any interference, including interference that

may cause undesired operation of the device.

L’émetteur/récepteur exempt de licence contenu dans le présent appareil est

conforme aux CNR d’Innovation, Sciences et Développement économique Canada

applicables aux appareils radio exempts de licence. ’exploitation est autorisée aux L

deux conditions suivantes : (1) L’appareil ne doit pas produire de brouillage; (2)

L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est

susceptible d’en compromettre le fonctionnement.

Note: This equipment has been tested and found to comply with the limits for a

Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at his

own expense.

QUICK ART E ST GUID

MOBILE-READY ROXIMITY ADERS P RE
