Speco Technologies MUHFHH Manual

Speco Technologies Mikrofon MUHFHH

Læs gratis den danske manual til Speco Technologies MUHFHH (1 sider) i kategorien Mikrofon. Denne vejledning er vurderet som hjælpsom af 14 personer og har en gennemsnitlig bedømmelse på 4.9 stjerner ud af 7.5 anmeldelser. Har du et spørgsmål om Speco Technologies MUHFHH, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/1

Specications

Carrier Frequency Range ........ UHF band 540 – 570MHz

Oscillator.................................. PLL synthesized

Modulation ............................... FM

Frequency Stability .................. ±0.005%

S/N Ratio ................................. More than 94dB, at 20kHz deviation

................................................. and 60dBmV antenna input

Maximum Deviation ................. ±48kHz

Image and Spurious Rejection ... 80dB minimum

Receiving Sensitivity................ At 10uV over 80dB S/N ratio

Selectivity ................................ More than 50dB

AF Response ........................... 80Hz – 16kHz (±3dB)

T.H.D. ....................................... More than 1% (at 1kHz)

IF Frequency ........................... 1st: 243.95MHz 2nd:10.7MHz

Dynamic Range ....................... More than 96dB

Tone Signal .............................. 32.768kHz

Audio Output............................ Balanced and unbalanced audio outputs

Power Supply .......................... 12VDC (power supply included)

Current Consumption .............. Single Channel: about 260mA

Dimensions .............................. 7.9” (W) x 1.7” (H) x 4.8” (D)

Specications

Carrier Frequency Range ....UHF band 540 – 570MHz

RF Power Output ...............10mW (max.)

Oscillator............................PLL synthesized

Frequency Stability ............±0.005%

Maximum Deviation ...........±48KHz

Spurious Emission .............More than 60dB below carrier frequency

T.H.D. .................................More than 1% (at 1kHz)

Microphone Cartridge ........(Handheld) uni-directional dynamic or

uni-directional electret condenser unit.

(Lavalier) uni-directional electret condenser unit

Operating Voltage ..............DC1.5V x 2 AA size dry or rechargeable batteries

Current Consumption ........120mA (max.)

Speco Technologies’ UHF 700 frequency-selectable single channel

receiver, handheld and lapel microphone transmitters allow the user

to select and match desired frequencies on each unit. This eliminates

the need to maintain high inventory levels of similar units with locked

frequencies. They provide clear, interference-free channels of

communication for roaming distances in excess of 150 feet.

• Up to 700 selectable pre-programmed frequencies make it easy to set up

multiple system congurations and avoid interference

• Auto-scan function can locate interference-free channels easily

• True Diversity technology ensures quality reception

• Constructed from durable plastic with a ½ rack design

• Squelch adjustment

• Balanced XLR connector and unbalanced ¼” jack audio output

• FCC, CE, RoHS compliant

UHF 700 Frequency-Selectable

Professional Microphone Line

MUHF101 UFH 700 Frequency-selectable single channel true

MUHFHH UFH 700 Frequency-selectable handheld microphone

MUHFLP UFH 700 Frequency-selectable lapel microphone

Features

Speco Technologies is constantly developing and improving products.

We reserve the right to modify product design and specications without notice

and without incurring any obligation. Spec Rev. 2/23/22

800-645-5516 • Fax: 631-957-9142 or 631-957-3880 • specotech.com

*Products are in compliance with NDAA Section 889 Part B Guidelines

Produkt Specifikationer

Mærke:	Speco Technologies
Kategori:	Mikrofon
Model:	MUHFHH
