CABLE JUNCTION BOX

WKE 4 - 5 x 16²

Cable junction box

CUSTOMIZABLE

165 x 165 x 76 mm

Article number: 86050401

Junction box with IP54 / IP65 certified as per EN 60670, with

electrical functional integrity E30 – E90 acc. to DIN 4102 Part

12, with insulation integrity FE180 acc. IEC 60331-11 as well

as functional class F400 acc. EN 12101, halogen-free

enclosure made from special duroplastic, terminals made

from high temperature-proof special ceramics, rapid

mounting thanks to external fixing brackets and wall + ceiling

fastening parts kit D6

Connection box 5-pole 1.5 - 16 mm², Junction box 5-pole 1.5 -

6 mm², Number of conductors per pole:, 10 x 1.5² / 8 x 2.5² /

4 x 4² / 4 x 6² / 2 x 10² / 2 x 16², Accessories supplied:, Drilling

template, D6 wall + ceiling attachment set, 4 IP54 attachment

bushes M40, seal range 17 - 30 mm, 1 IP54 sealing plug M40,

seal range 17 - 30 mm

Technical data

Measures

Width: 165 mm

Length: 165 mm

Height: 76 mm

Material:

Box: Duroplastic

Cover: Duroplastic

Sealing: thermoplastic

elastomer

Cover screw: stainless steel V2A

Certificates

Accessory

AST M20-or - Attachment bushes

AST M32-or - Attachment bushes

KVR M32-MGM/or - Cable gland

KVR M40-MGM/or - Cable gland

KVR M20-MGM/or - Cable gland

KVR M25-MGM/or - Cable gland

VST M20-or - Sealing plugs

VST M32-or - Sealing plugs

Created on 2017-04-28. No responsibility is taken for the correctness of this information. Improvements for technical progress reserved. Page 1 of 2

Günther Spelsberg GmbH + Co. KG · Im Gewerbepark 1 · D-58579 Schalksmühle · Germany · Phone: +49 (0) 23 55 / 892-0 · Fax: +49 (0) 23 55 / 892-299

CABLE JUNCTION BOX

WKE 4 - 5 x 16²

material: Duroplastic

Other attributes

Color: orange

Equiqment: Terminal

Entries: 12

Rated cross section: 16 mm²

Tackable: No

Rated insulation voltage AC: 450 V

Explosion safety: none

Functional integrity: E 90

sealable: No

Heavy metals-free: Yes

PVC-free: Yes

Silicone-free: Yes

Ingress protection: IP65 - acc. to EN

60529 / DIN VDE

0470-1

weatherproof: Yes

Cover screw torque: 1.8 N m

AST M25-or - Attachment bushes

VST M25-or - Sealing plugs

Environmental attributes

Ambient temperature (min.): -25 °C

Ambient temperature (max.): 40 °C

Ambient temperature (24 h): 35 °C

Max. rel. humidity at 25° C (short

term):

95%

Max. rel. humidity at 40° C: 50%

Created on 2017-04-28. No responsibility is taken for the correctness of this information. Improvements for technical progress reserved. Page 2 of 2

Günther Spelsberg GmbH + Co. KG · Im Gewerbepark 1 · D-58579 Schalksmühle · Germany · Phone: +49 (0) 23 55 / 892-0 · Fax: +49 (0) 23 55 / 892-299

Produkt Specifikationer

Mærke:	Spelsberg
Kategori:	Ikke kategoriseret
Model:	WKE 4 - 5 x 16²
Kode for international beskyttelse (IP):	IP65
Bredde:	165 mm
Dybde:	165 mm
Højde:	76 mm
Produktfarve:	Orange
Materiale:	Duroplast
