BUTTONS AND THEIR FUNCTIONS
The Sportline 345 Pedometer has 3 buttons for operating and programming: MODE/
RESET (located on the front of the unit below the display) and on the back panel of
the unit, the SET and the + (Adjust/increase) buttons.
MODE/RESET (MODE) BUTTON
• Operating Mode: Scrolls through display modes.
• Press & Hold: Resets pedometer data
• Programming Mode: Adjusts (decreases) information being adjusted.
SET BUTTON
• Operating Mode: Press & Hold to enter the Programming Sequence.
• Programming Mode: Accepts the information being adjusted and advances to the
next setting.
+ (ADJUST/INCREASE) BUTTON
• Programming Mode: Adjusts (increases) information being adjusted.
2- REMOVING BATTERY INSULATOR TAB 3- BUTTONS AND THEIR FUNCTIONS
1- INTRODUCTION
Back cover
345 PEDOMETER
USER GUIDE
/INSTRUCTION MANUAL
Congratulations on your purchase of a Sportline 345 Pedometer. The 345 Pedometer
features a highly advanced pedometer technology that accurately measures your
body movements when worn from multiple locations on the body and in multiple
orientations.
Please keep in mind your pedometer is a sensitive technical instrument. With
proper care and maintenance, it will last for many years. However, improper
care and handling can cause the various sensors to be damaged and to stop
functioning.
HOW TO USE THIS MANUAL
Please read all sections of this manual carefully and become fully familiar with
the operation of the pedometer before using it in the fi eld. Proper setup and
operation will greatly enhance the pedometer’s usefulness and your enjoyment.
The steps for the programming or operation are adjacent to the screen illustration.
Key points and important information are shown in highlighted blocks.
CUSTOMER SUPPORT
If you have questions, comments or need assistance with your Sportline
Pedometer, you may contact Customer Support by calling 1-866-694-4575.
NOTE: In order to activate your pedometer after purchase, you must remove the
battery insulator tab inside the battery compartment.
1. Locate the tab on the back of the pedometer.
2. Firmly grasp the tab and pull away from the pedometer until completely
removed from the unit.
3. Remove the label that appears on the pedometer display.
1 2
345 PEDOMETER
www.sportline.com
www.sportline.com
Walking Advantage by Sportline
TM
is distributed for EB Sport Group,
Yonkers, NY. in Canada by / Walking Advantage par Sportline
TM
est distribué pour EB Sport Group, au Canada par ACI Brands Inc,
2616 Sheridan Drive, Oakville, Ontario L6J-7Z2.
All Rights Reserved/Touts droits reservé ©2012
WV1056IS02SCC
Fold 1
Fold 2Fold 3 Fold 3
5- PROGRAMMING THE PEDOMETER
4. Adjust Height by PRESSING the + or - buttons. PRESS the SET button to accept
value.
5. This pedometer has an automatic stride length calculator that sets your length
based on your height. PRESS the SET button to accept this value or you can
adjust your Stride Length (see “Determining Stride Length” on the opposite
page) by PRESSING the + or MODE buttons.
6. PRESS the SET button. The unit is now programmed and ready for use!
4 5 6
4- PROGRAMMING THE PEDOMETER
In order to ensure exercise data is as accurate as possible, you must complete the
following steps to enter your personal profi le. The display will prompt you what
information is being programmed. Adjust information by PRESSING + (to increase)
OR MODE/RESET (MODE) (to decrease). Accept value and advance to the next setting
by PRESSING SET.
1. Enter the Programming Sequence by PRESSING & HOLDING the SET button on
the back of the unit for approximately 3 seconds.
2. Select unit of measure (metric or imperial) by PRESSING the + or MODE buttons
on the back of the unit. PRESS the SET button again.
3. Adjust Weight (in pounds or kilograms) by PRESSING the + (to increase) or MODE
(to decrease) buttons. PRESS the SET button to accept value and advance to set
Height.
1 12 2 33
To adjust value:
PRESS + or MODE/RESET
To accept and advance:
PRESS SET
To adjust value:
PRESS + or MODE/RESET
To accept and advance:
PRESS SET
Scroll through display
modes:
PRESS MODE/RESET
6- OPERATING THE PEDOMETER 7- RESETTING PEDOMETER DATA
The 345 Pedometer automatically begins capturing data once movement
occurs. There are no Start or Stop buttons to push.
Scroll through display modes: STEPS, DISTANCE, CALORIES AND EXERCISE TIME
by PRESSING THE MODE/RESET BUTTON.
TO CLEAR ALL CURRENT PEDOMETER DATA:
1. PRESS & HOLD the MODE/RESET button on the front of the unit.
2. Continue holding as the display reads “RESET”.
3. When pedometer data reads zeros (O), RELEASE THE MODE/RESET button.
The unit is now ready for a new workout.
NOTE: Your personal profi le settings will be saved.
STEPS
EXERCISE TIME CALORIES
DISTANCE
WV1056IS02SCC
9/11 /1 2
Ron
345 PEDOMETER
8- MEASURING STRIDE LENGTH
HOW TO MEASURE YOUR STRIDE LENGTH
The 345 Pedometer automatically sets your stride length based upon your height
input during the Set Up sequence. You may choose to adjust this stride length.
To obtain your personalized measurement, see below.
1. To fi nd out what your stride is, walk or run 10 steps and then measure the
distance with a tape measure from the fi rst step’s toe to the 10th step’s toe.
2. Divide your total distance by 10 to get your average stride length.
3. For a quick estimate, walk 3 steps, measure the distance, and divide by 3.
The more steps you take, the more accurate and realistic your stride will be.
An average walking stride for a female is 2 feet (24 in.), a male is 2.5 feet (30 in.).
START WALKING/RUNNING
BASE LINE
DIVIDE TOTAL
DISTANCE BY 10
1
3
5
79
2
46
8
10
11- CARE & MAINTENANCE
• NEVER get the pedometer wet. This unit is not water resistant.
• NEVER attempt to disassemble or service your unit.
• DO NOT expose the unit to extreme heat, shocks, magnetic fi elds, electrical noise,
strong vibration or long-term exposure to direct sunlight.
• DO NOT drop or step on the pedometer.
• TO CLEAN the unit: wipe with a lightly moistened cloth. Apply mild soap to the
area if there are stubborn stains or marks. Do not expose the unit to strong
chemicals such as gasoline, cleaning solvents, acetone, alcohol, or insect
repellents, as they may damage the unit’s seal, case and/or fi nish.
• STORE the unit in a dry place when you are not using it.
www.sportline.com
13- REPLACING THE BATTERY
The Sportline 345 Pedometer uses one CR2032 3V lithium battery.
Battery replacement will be required from time to time, and should occur when:
1. The display fades in part or completely
2. The pedometer function will not activate
TO REPLACE THE BATTERY:
1. Lift the spring-loaded belt clip on the back of the unit to expose the battery
compartment door. Unscrew the battery compartment door with a small Phillips
screwdriver.
2. Remove the exhausted battery from the unit, and insert a new battery (be sure to
place the positive (+) side of the battery facing up).
3. Replace the battery compartment cover and fasten by sliding back into place).
1 2 3
14- BATTERY SAFETY INFORMATION
CAUTION – BATTERY SAFETY INFORMATION
• Non-rechargeable batteries are not to be recharged
• Rechargeable batteries must be removed before recharging
• Rechargeable batteries should only be recharged under adult supervision
• Do not mix alkaline, standard (carbon-zinc), or rechargeable (nickel-cadmium)
batteries
• Exhausted batteries are to be removed
• Do not mix old and new batteries
• Do not dispose of batteries in fi re; batteries may explode or leak
• Do not dispose of product in fi re; batteries may explode or leak
• If this product will not be used for an extended period of time, remove the
batteries from the product
• The supply terminals are not to be short-circuited
• Batteries are to be inserted with correct polarity
• Clean the battery contacts and also those of the product prior to battery
installation
• As always, dispose of batteries in an eco-friendly manner
The purpose of the crossed-out wheelie bin symbol is to remind us that most electrical products,
and batteries, contain trace elements (including Mercury – Hg, Cadmium – Cd and Lead – Pb)
which could be harmful to our environment and therefore our health. We must all be careful to
dispose of them responsibly in a specifi cally designated way – either using a collection scheme or
into the correctly labeled civic amenity (NOT into general waste) – this will help your local
authority to arrange to recycle or dispose of them in the appropriate manner.
9- HOW TO WEAR THE PEDOMETER
This pedometer will be most accurate when worn close to the body, ideally on your
belt or waist line or inserting the unit into a tight, secure pocket. The pedometer can
also be worn around the neck attached to a lanyard.
10- WARNINGS & CAUTIONS
WARNING: Before starting any exercise program or performing any vigorous
physical activity, we strongly suggest you visit your doctor for a complete physical
and to discuss your plans.
CAUTION: Pedometers are not water resistant.
AVOID exposing the Pedometer to extreme conditions.
AVOID rough uses or severe impacts to the Pedometer.
CLEAN the Pedometer occasionally with a soft, dry cloth.
STORE the Pedometer in a dry place when it is not in use for a long time.
START WALKING/
RUNNING
BASE LINE
DIVIDE TOTAL
DISTANCE BY 3
1
3
2
12- FCC COMPLIANCE
“The device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.”
1. “Changes or modifi cations not expressly approved by the party responsible for
compliance could void the user’s authority to operate the product.”
2. “NOTE: This product has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This product generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If the product
does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the product and receiver.
• Connect the product into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.”

Produkt Specifikationer

Mærke: Sportline
Kategori: Skridttæller
Model: Calorie 345 DS

Har du brug for hjælp?

Hvis du har brug for hjælp til Sportline Calorie 345 DS stil et spørgsmål nedenfor, og andre brugere vil svare dig


Skridttæller Sportline Manualer

Sportline

Sportline Clip 310 Manual

26 September 2025
Sportline

Sportline Distance 340 Manual

25 September 2025
Sportline

Sportline Goal 350 Manual

25 September 2025
Sportline

Sportline ShrinQ 304 Manual

25 September 2025
Sportline

Sportline Traq 370 Manual

25 September 2025
Sportline

Sportline 340 DS Manual

25 September 2025
Sportline

Sportline Calorie 345 DS Manual

25 September 2025
Sportline

Sportline 342 DISTANCE Manual

24 September 2025
Sportline

Sportline 330 DS Manual

8 Juli 2024
Sportline

Sportline 340 STEP and DISTANCE Manual

8 Juli 2024

Skridttæller Manualer

Nyeste Skridttæller Manualer

Timex

Timex W178-M620 Manual

20 September 2025
Yamasa

Yamasa Power-Walker Lite PZ-271 Manual

15 September 2025
Yamasa

Yamasa Power-Walker Lite PZ-270 Manual

14 September 2025
Crivit

Crivit IAN 278509 Manual

30 Juni 2025
Irox

Irox PE-DRO Manual

9 Marts 2025
Timex

Timex W180-M621 Manual

13 Januar 2025
TFA

TFA 42.2003 Manual

5 September 2024
Silva

Silva ex connect Manual

27 August 2024
HMM

HMM smartLAB walkP plus Manual

26 August 2024
BandeeFit

BandeeFit BFX-4 Manual

25 August 2024
