Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support

Manual Revision: December 13, 2023

Product Diagram (MR12GI-NETWORK-CARD)

M.2 Network Card

CAT6 Cable Adapter

Port/LED/Connector Function

1M.2 Connector

• Insert the into a M.2 Network Card M.2 PCI Express

Slot Host Computer on the

• Supports or B Key M Key Slots

2Ethernet Port • Connect the CAT6 Cable Adapter

3LED Indicators

• Right LED Indicator Link Speed is

• Solid Green: 2.5 Gbps

• Solid Amber: 1 Gbps

• O: 100 or 10 Mbps

• Left LED Indicator Link Status is

• Solid Green: Active link

• Flashing Green: Activity

M.2 2.5GBase-T Ethernet Network Card - PCIe 2.0

4RJ45 Connector

• Insert into the on the Ethernet Port M.2 Network

Card

5Bracket Mount

• Screw-in design for securing the CAT6 Cable Adapter

onto the or Full Prole Low Prole Bracket

(not pictured)

6Ethernet Port

• Connect a to the Network Cable CAT6 Cable

Adapter

• Supports 2.5 Gbps, 1 Gbps, 100 Mbps, and 10 Mbps

Package Contents

• M.2 Network Card x 1

• CAT6 Cable Adapter x 1

• Full Prole Bracket x 1

• Low Prole Bracket x 1

• Quick-Start Guide x 1

Requirements

For the latest requirements, please visit www.startech.com/MR12GI-NETWORK-CARD

• Host computer with an available B or M key M.2 PCI Express slot

• Phillips head screwdriver

Installation

Install the M.2 PCI Express Card

WARNING!

Static Electricity can severely damage Expansion Cards. Ensure that you are

adequately Grounded before you open your Host Computer Case or touch the

Expansion Card. You should wear an Anti-Static Strap or use an Anti-Static Mat

when installing any Host Computer component. If an Anti-Static Strap isn’t available,

discharge any built-up static electricity by touching a large Grounded Metal Surface

for several seconds. Only handle the Expansion Card by its edges and don’t touch the

gold connectors.

1. Turn o the and any that are connected to it Host Computer Peripheral Devices

(e.g. printers, external hard drives, etc.).

2. Unplug the from the .Power Cable Host Computer

3. Disconnect any that are connected to the .Peripheral Devices Host Computer

*Product may vary from image
