Side 1/2

Quick-start guide

FR: Guide de l’utilisateur - fr.startech.com

DE: Bedienungsanleitung - de.startech.com

ES: Guía del usuario - es.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

IT: Guida per l’uso - it.startech.com

Manual Revision: 07/15/2016

For the latest information, technical specications, and support for

this product, please visit www.StarTech.com/PEX10000SRI.

Package contents

• 1 x 10G SFP+ ber network card

• 1 x 10GBase-SR SFP+ transceiver module (preinstalled)

• 1 x low-prole bracket

• 1 x quick-start guide

System requirements

• PCI Express® enabled computer with an available PCI Express slot

(x8 or x16)

• Any of the following operating systems:

• Windows® 10 (32-bit and 64-bit)

• Windows 8.1 (32-bit and 64-bit)

• Windows 8 (32-bit and 64-bit)

• Windows 7 (32-bit and 64-bit)

• Windows Server® 2008 R2

• Windows Server 2012

• Linux® Kernel 2.6.24 and later

• Microsoft® Hyper-V®

• Phillips head screwdriver (optional)

System requirements are subject to change. For the latest

requirements, please visit www.StarTech.com/PEX10000SRI.

PEX10000SRI

1-Port 10G SFP+ Fiber Optic Network Card - PCIe - Intel Chip - MM

Introduction

To experience reliable high-performance network connectivity over

multi-mode ber, you can use the PEX10000SRI to add a 10GBase-SR

port to your server or workstation. This SFP+ network card oers up

to 10Gbps of network speed and features the Intel® 82599 chipset.

The PEX10000SRI can be mounted in both low-prole and full-prole

computer systems.

Product diagram

SFP+ slot

Link or activity LED

Mounting bracket

(full-prole pictured)

PCIe p1-x8

connector

*actual product may vary from photos

Bracket screw

Install the low-prole bracket

The PEX10000SRI can be mounted in both low-prole and

full-prole computer systems. The full-prole bracket comes

preinstalled, but you can install the low-prole bracket instead.

1. Remove the 10GBase-SR SFP+ transceiver module from the

SFP+ slot on the SFP+ network card.

2. Use a Phillips head screwdriver to remove the two bracket screws

from the PEX10000SRI.

3. Remove the full-prole bracket from the SFP+ network card.

4. Line up the low-prole bracket with the bracket holes on the back

of the SFP+ network card.

5. Insert the two bracket screws that you removed in step 2 and

tighten them into place.

6. Insert the 10GBase-SR SFP+ transceiver module into the SFP+

slot on the network card

Install the network card in a computer

Warning! PC components can be severely damaged by static

electricity. If an anti-static strap isn’t available, discharge any built-

up static electricity by touching a large, grounded metal surface for

several seconds.

1. Turn o your computer and any devices or peripherals that are

connected to it (for example, printers, external storage, and

so on).

10GBase-SR SFP+

transceiver module

Produkt Specifikationer

Mærke:	StarTech.com
Kategori:	Netværkskort/adapter
Model:	ST10000SPEXI
Bredde:	68.5 mm
Dybde:	152.5 mm
Højde:	121 mm
Vægt:	96 g
Pakkevægt:	200 g
Pakkedybde:	209 mm
Pakkebredde:	145 mm
Pakkehøjde:	40 mm
Opbevaringstemperatur (T-T):	-20 - 60 °C
Relativ luftfugtighed ved drift (H-H):	20 - 80 %
Ethernet LAN-porte (RJ-45):	1
Ethernet LAN:	Ja
Driftstemperatur (T-T):	5 - 50 °C
Ethernet LAN-datahastigheder:	10,100,1000,10000 Mbit/s
Hurtig installationsvejledning:	Ja
Forbindelsesteknologi:	Ledningsført
Certificering:	CE, FCC, REACH
Netværksstandarder:	IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3an, IEEE 802.3u, IEEE 802.3x
LED-indikatorer:	Activity, Link
Harmoniseret systemkode (HS):	85176990
Bæredygtighedscertifikater:	RoHS
Understøttede Mac-operativsystemer:	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave
Understøttede Linux-operativsystemer:	Ja
Hovedkassen højde (udvendigt):	312 mm
Hovedkassens længde (udvendigt):	442 mm
Hovedkassens bredde (udvendigt):	419 mm
Værtsgrænseflade:	PCI Express
Grænseflade:	Ethernet
Intern:	Ja
Maksimal dataoverførselshastighed:	20000 Mbit/s
Produkter pr. hovedkasse (udvendigt):	80 stk
Fuld duplex:	Ja
Ethernet-grænsefladetype:	10 Gigabit Ethernet
Komponent til:	PC
Understøttede operativsystemer til servere:	Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Flowkontrol support:	Ja
Jumbo Frames support:	Ja
Jumbo rammer:	9000
Auto MDIX IEEE:	Ja
PCI-kort formfaktor:	Fuld højde (lav profil)
VLAN mærkning:	Ja
Simpelt beslag:	Ja
Chipsæt:	Intel X550AT
PCI version:	2.0
