Installation Manual

REMOTETEST

Wiring Tester

Remote Cable Tester for RJ45 RJ11 and BNC

Overview

The StarTech.com REMOTETEST cable tester is a palm-sized unit with four kinds of

connectors: RJ45, RJ11, USB and BNC, for the testing of today’s most popular media.

This unit can be used to verify the condition of cables, both before and after their

installation. The separable passive module is connected to the remote end of the

installed network cabling.

The tester also offers easy operating; the user begins by testing by simply pushing a

button. Multiple LEDs give a clear indication of testing status and go off automatically,

to maximize power saving.

Features

• Detachable module for testing remote points

• Open/Short wiring testing

• Connected wires display

• Ethernet 10Base2/10Base5 termination value detector

• No wire or termination indicator

• Wrong connection/Non-parallel connection

Specifications

Getting Started

Operating Instruction

To test the cable not installed (RJ45, RJ11, USB, and BNC):

1. Connect one end of the cable to the master’s proper connector, and the other end to

the remote module.

2. Press the test button.

3. When the LEDs stop flashing the result is ready to be read.

Indicators

Connectors

Cable Length

Power

Size

Weight

Battery Good/Battery Low

(Green/Yellow)

No Connection/No Terminator LED

(Yellow)

Non-Parallel/50 Ohm LED (Yellow)

Connected/25 Ohm LED (yellow)

Short LED (Red)

S, C/a, 2, 3, 4, 5, 6, 7, 8 LEDs (Yellow)

RJ45 x 2, RJ11 x 2, USB A x 1, USB B x 1,

BNC x 1

200m for all connectors

9V Alkeline battery

145 x 86 x 26 mm (5.7 x 3.39 x 1.03")

185g (6.53 oz)

Produkt Specifikationer

Mærke:	StarTech.com
Kategori:	Kabler til computere og periferiudstyr
Model:	REMOTETEST
Bredde:	110 mm
Dybde:	180 mm
Højde:	25 mm
Vægt:	170 g
Brugervejledning:	Ja
Produktfarve:	Grå
Pakkevægt:	390 g
Pakkedybde:	266 mm
Pakkebredde:	62 mm
Pakkehøjde:	158 mm
LED-indikatorer:	Ja
Bæredygtighedscertifikater:	CE
Hovedkassen højde (udvendigt):	340 mm
Hovedkassens længde (udvendigt):	540 mm
Hovedkassens bredde (udvendigt):	340 mm
Produkter pr. hovedkasse (udvendigt):	20 stk
Etui til opbevaring:	Ja
Testtype:	Continuity testing, Short circuit testing, Transmission testing
Understøttede stik:	BNC, RJ-11, RJ-45, USB
