3m Mini DisplayPort™ to DisplayPort 1.2 Adapter Cable M/M - DisplayPort 4k

StarTech ID: MDP2DPMM3M

The MDP2DPMM3M 3m Mini DisplayPort™ to DisplayPort Adapter Cable, features a Mini DP male connector on

one end, and a DP male connector on the other, allowing you to connect any Mini DisplayPort-equipped laptop

(including the Mac® family of products) to an HDTV, monitor or projector that uses a standard DisplayPort

connection.

The mDP to DP cable supports high resolutions of up to 4k x 2k (3840 x 2160) @ 60Hz with a maximum HBR2

bandwidth of 21.6 Gbps. The cable also supports Multi-Stream (MST) for daisy chaining multiple monitors and

provides optional audio support.

The MDP2DPMM3M is backed by StarTech.com’s Lifetime Warranty, for guaranteed reliability and ensures that

digitally protected content is displayed properly, with both HDCP and DPCP capability.

Please Note: Newer laptop and desktop computers (e.g. Apple®) come equipped with Thunderbolt™ ports only.

Our Mini DP to DP Cables can be connected to the Thunderbolt ports, enabling you to connect your DP compatible

displays.

Applications

Connect a DisplayPort monitor or projector to devices equipped with a Mini DisplayPort connection port

www.startech.com

1 800 265 1844

Features

High resolution support of up to 4k x 2k

Support for High Bit Rate 2 (HBR2) bandwidth of up to 21.6 Gbps

Designed and manufactured to DisplayPort 1.2 standards

Backward compatible with DisplayPort 1.1

Supports the DPCP (DisplayPort Content Protection) standard in addition to HDCP

Gold-plated connectors

Technical Specifications

Warranty Lifetime

Number of Conductors 19

Connector Plating Gold

Cable Jacket Type PVC - Polyvinyl Chloride

Cable Shield Type Aluminum-Mylar Foil with Braid

Fire Rating CMG Rated (General Purpose)

Connector A 1 - Mini-DisplayPort (20 pin) Male

Connector B 1 - DisplayPort (20 pin) Latching Male

Color Black

Wire Gauge 32 AWG

Cable Length 9.8 ft [3 m]

Product Length 9.8 ft [3 m]

Product Width 0.4 in [10 mm]

Product Height 0.4 in [10 mm]

Product Weight 3.7 oz [105 g]

Package Quantity 1

Shipping (Package) Weight 4 oz [114 g]

Included in Package 1 - 3m Mini DisplayPort® to DisplayPort Adapter Cable – M/M

Certifications, Reports and Compatibility

www.startech.com

1 800 265 1844

Produkt Specifikationer

Mærke:	StarTech.com
Kategori:	Kabler til computere og periferiudstyr
Model:	MDP2DPMM3M
Vægt:	102 g
Antal pr. pakke:	1 stk
Produktfarve:	Sort
Pakkevægt:	110 g
Pakkedybde:	220 mm
Pakkebredde:	200 mm
Pakkehøjde:	22 mm
Opbevaringstemperatur (T-T):	-10 - 80 °C
Relativ luftfugtighed ved drift (H-H):	5 - 80 %
Driftstemperatur (T-T):	0 - 35 °C
Maksimal opløsning:	3840 x 2400 pixel
Understøttede grafikopløsninger:	3840 x 2400,2560 x 1600 (WQXGA)
Kabellængde:	3 m
Harmoniseret systemkode (HS):	84733080
Bæredygtighedscertifikater:	RoHS, CE
Hovedkassen højde (udvendigt):	210 mm
Hovedkassens længde (udvendigt):	500 mm
Hovedkassens bredde (udvendigt):	320 mm
Maksimal opdateringshastighed:	120 Hz
DisplayPort-version:	1.2
Produkter pr. hovedkasse (udvendigt):	50 stk
Stik 1:	Mini DisplayPort
Stik 2:	DisplayPort
Stik 1 køn:	Hanstik
Stik 2 køn:	Hanstik
Stikforbindelse kontakter plettering:	Guld
Stik 1 formfaktor:	Lige
Stik 2 formfaktor:	Lige
Båndbredde:	21600 MB/s
Materiale for kapper:	Polyvinylchlorid (PVC)
AWG-ledningsstørrelse:	32
Kabelafskærmning:	Aluminium mylar folie
Kabel vurdering:	CMG (CM)
Multi-Stream Transport (MST):	Ja
Antal ledere:	19
