PLUMBER NOTE

҃On-site testing using higher water pr ess ures must be condu cted

with th e Mixer in the closed p osition. (STATIC TEST )

҃Un der no circumstances is th e Mixer to be opened wh en

exceeding the maxi mum stated water pr essure.

҃At the comple tion of testing, do not relieve any hig h water

press ure by ope nin g the Mixer.

҃Exp osing th e intern als of the Mixer Cartridge to hig her than

speci fi ed water p res sur es will void the manuf acturers warr anty

INSTALL ATION GUIDELINES

҃The Mixer is supplied assembled, only the Fixing nut and the Brass

Clamp need to be removed.

҃Decide if the Optional Base Flange is to be us ed .

҃If using the Opti onal Base Flange discard the smaller Base O Ring.

҃Add the base Flange to base of Mi xer and attach the Flexi ble Hoses

to the Mixer Hose extensions.

҃In some cases the Flexible Hoses may need to be fed thr ough from

under the mounting sur face an d th en attach.

҃Once th e Flexible Hoses have been secur ed, lower the Mixer onto

the mounting surface.

҃Working from underneath the mounting sur face fi t Clamp and

Fixing Nut.

҃Before f ully securing th e Mixer ens ure that the Bas e O Rin g is

intact and the Mixer is cente red over the mounting surface hole .

҃The Mixer mounting surf ace mus t be completely water-tight.

҃Connect the Hot and Cold Flexible hoses to the corresponding

1/2”BSP water feed lines.

҃The 1/2” connection of the Flexi ble h os es have a conical seal,

ens ure the mating th reads are cut sq uare and burr fr ee.

҃Isolating stop valves are recommended wi th all installati ons.

(not supplied)

҃Ensu re all fi ttings and conne ctions are water-tight.

NO T E: Op tio nal B as e Flange mu st b e us ed w hen t he c lea rance

ho le fo r mou nti ng the Mi xer exc ee ds 35m m. If t he m oun tin g

ho le cl ear an ce exce ed s 45 mm a cu stom ma de B ase f lan ge

will be required.

Handle

Body

Sink Mixer

Body

Sink Mixer

Stand

32 - 35mm

Hose extension

(Do not remove)

Base Flange

Clamp

Fixing

Nut

Surface

Flexible Hose

Vod a Sin k Mi xer Ri ght H an d

Product code: Available opons:

VSM Sink Mixer

VSMC Sink Mixer Curved

VSMQ Sink Mixer Square

VSMCS SRH Sink Mixer Curved 316 S/S

VSMQSSR H Sink Mixer Square 316 S/S

INSTALLATION GUIDE

sussextaps.com.au

Tapware is to b e in st al le d by a Li cen se d

Plu mb er i n accord an ce wi th AS/NZ S 350 0: 20 0 3

Recomm en de d wor king w ater pressure 3 0 0 -50 0 k pa.

Maxi mum water te m p erature is 65 deg . c.

sussextaps.com.au

IM P O R TAN T NOT E: To provi d e p roper f unction,

th e Sin k Mi xer m us t be i nstall ed wi th t he h an dle

to th e R I G H T- H A N D s ide o f th e op er ator.

NOTE : Mixer handl e

to be R I G H T- H A N D

sid e of th e op erato r.
