Side 1/4

Quick Installation Steps

For more information and complete step-by-step instructions, please refer to the StorageLibrary T40+ Series

Installation and User Guide available at www.tandbergdata.com .

Warning Although the StorageLibrary T40+ may be lifted by one person when drives, ™

power supply, and magazines are removed, for your protection and safety, we

recommend that two people lift the StorageLibrary™ T40+. All-inclusive library

weight = 38 kg / 84 lbs (2 FH drives). Empty library weight = 23.6 kg / 52 lbs (not

including drives, magazines or power supply).

Caution Please ensure the StorageLibrary T40+ is mounted in the rack before you remove

the transport screws. The transport locking screws must be removed before the

StorageLibrary T40+ can operate normally.

When following the steps below, please refer to the corresponding numbers and letters on the illustrations.

1. Please refer to the StorageLibrary T40+ Series Pass-Thru Installation Manual for instructions of how to

install the unit. To insert the StorageLibrary T40+ onto the rack-rails, please request help of another

person.

2. Before removing the locking screws, power-on the unit. The StorageLibrary T40+ will automatically eject

the magazines if the transport locking screws are mounted. Remove all magazines, remove the four

transport locking screws, and mount the rack mount ears. Re-insert the magazines.

3. Install SCSI, SAS or Fibre Channel cables.

SCSI installation:

Power-off the unit and the host system before plugging in the SCSI cables. When using more than two

SCSI drives, please refer to the StorageLibrary T40+ Series Installation and User Guide for installation

requirements.

a. Connect a SCSI cable from the host to the

1st drive (bottom SCSI connector).

b. Connect a SCSI jumper cable from 1st drive

(top SCSI connector) to the 2nd drive

(bottom SCSI connector). If required repeat

this step for all drive within the tape library.

c. Terminate the last device on the SCSI bus

using the correct SCSI terminator.

NOTE: The maximum SCSI bus length must NOT exceed 9 meters / 30 feet. Please ensure SCSI cables

and teminators are securely fitted using thumbscrews.

SAS installation:

If your library includes tape drives with SAS

interface, connect a SAS cable to each tape

drive separately and connect other end of the

SAS cable to the host.

Produkt Specifikationer

Mærke:	Tandberg Data
Kategori:	Ikke kategoriseret
Model:	StorageLibrary T40+
Vægt:	37700 g
Produkttype:	Autoloader og bibliotek til opbevaring
Opbevaringstemperatur (T-T):	10 - 90 °C
Relativ luftfugtighed ved drift (H-H):	10 - 40 %
Driftstemperatur (T-T):	20 - 80 °C
Dimensioner (BxDxH):	446.6 x 736.6 x 177.5 mm
Certificering:	CE, FCC, TUV/GS, ICES VCCI, BSMI, CISPR 22, C-tick, UL, C-UL, CB, GOST and EN 55022 Class A
Effektkrav:	100 - 240 VAC, 50 - 60 Hz
Montering:	Stativ
Gennemsnitstid mellem fejl (MTBF):	250000 t
Understøttede medietyper:	LTO-4, LTO-3, LTO-2, LTO-1
Medietype:	Båndpatron
Oprindelig kapacitet:	19200 GB
Komprimeret kapacitet:	38400 GB
Sokkeltype:	Mail
Ikke-registeret fejlhastighed:	< 10(17)
Backuphastighed komprimeret:	1700 GB/t
Sikkerhedskopiering hastighed oprindelig ydeevne:	864 GB/t
Bånd- eller diskdrev (område):	LTO-4
