Installation!Guide! ! ! -for!the TechLogix TL RK01!Mounting!Bracket!
"
This"guide"provides"a"brief"introduction"and"usage"method"for" -the"TL RK01"Mounting"Bracket."
"
"
!
1.!Preparation!
!
ü Unpacking!
Remove"the"spare"parts"form"the"TL-RK01"packaging"and"verify"all"of"the"below" ."items"are"present
Packing!List:!
24"x Support" "Brackets1"
12"x Support"Brackets" 2"
1"x"Main"Frame" "
2"x" "Panels
2"x"Metal"Rods"
22" Screws(2.5*5mm)x" "
44" Screws(3*6mm)x" "
11"x"Baffle"plates"
"
"
"
ü Prepare!Spare!Parts!
Support"Brackets1!
!
Support"Brackets2!
!
Screws "(3*6mm)
!
Baffle"plates"
!
Main"Frame"
"
Panels"
"
Metal"Rods"
"
"
Screws "(2.5*5mm)
!"
"
² Pictures"are" "for"reference"only
² The"TL-RK01"is"designed"for"mounting"compatible"TechLogix"electronics"only;"contact"the"factory"for"a"list"of"compatible"products"
² All"compatible"Electronics"are"sold"separately"
"
"
! !
Captive!Screw! !
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
2"
TL-RK01!User!Manual"
www.tlnetworx.com"
2.!Installation!procedure! !
!
Step!1! !(for!small!sized!devices).!
Connect"one"Bracket1"and"one" Bracket2"to"a"compatible"electronic"
device"(sold"separately) " ","and"affix them"with"screws"(3*6mm).
!
Step!1!(for!large!sized!devices).! !
Connect"two"Brackets1" "to a"compatible"electronic"device," a "and" ffix
them"with"screws"(3*6mm)."
!
!
Step!2 !.!
Connect" one" panel" "to" the" one" side" of" main" frame with" screws"
(3*6mm)."
!
Step!3.! !
C "onnect"the"opposite" p an el to"the"other"side"of"main"frame"with"
screws"(3*6mm)."
!
Step!4.! !
Install"the"two"metal"rods" "with"screws"(3*6mm).
"
Step!5 !.!
Install"the"electronics"with"the"brackets"in"the"slots"and"tighten"the"
captive"screws." "
Screw!
Metal!rods!
Screw!
