Model: TX-203,TX-204,TX-228; Article No. 5021,5023,5040; 10/2022

Technaxx® * User Manual

Solar Balcony Power Plant 300W TX-212

Solar Balcony Power Plant 600W TX-220 / TX-228

Before using the appliance for the first time, please read the instructions for use and

safety information carefully.

TX-212

TX TX-220 / -228

This appliance is not intended for use by persons (including children) with reduced

physical, sensory or mental capacities, or by persons lacking in experience or

knowledge, unless they are supervised or instructed on the use of this device by a

person responsible for their safety. Children should be supervised to ensure they do

not play with this device.

Keep this user manual for future reference or product sharing carefully. Do the same

with the original accessories for this product. In case of warranty, please contact the

dealer or the store where you bought this product.

Enjoy your product. * Share your experience and opinion on one of the well-

known internet portals.

Model: TX-203,TX-204,TX-228; Article No. 5021,5023,5040; 10/2022

Table of Contents

Important notes at the start ................ 3

Explanation of the pictograms used 3

Note ............................................... 4

Safety instructions .......................... 4

Intended use .................................. 6

Caution measures during installation

....................................................... 6

Qualified personnel ........................ 6

Disclaimer ...................................... 7

Features ............................................ 7

Product details ................................... 8

Package content: ............................ 8

Product variants: ............................ 8

Prduct overview .............................. 8

Preparation ........................................ 9

Requirements for the operation of a

photovoltaic system ........................ 9

Connecting the micro inverter ............ 9

Mounting .......................................... 11

General hints ................................ 11

Balcony ......................................... 11

Flat roof (bitumen roof) ................. 11

Facade .......................................... 12

Connect the solar panels (DC

connection) ....................................... 12

Connecting the micro inverter to the AC

grid (AC connection) ......................... 12

First commissioning .......................... 13

LED status ........................................ 14

Troubleshooting ................................ 14

Technical specifications .................... 15

Inverter ......................................... 15

Appendix .......................................... 17

Determining the line reserve ......... 17

Load capacity of copper lines ........ 18

Determination of the line reserve .. 19

Support ............................................19

Care and maintenance ..................... 19

Declaration of Conformity ................. 19

Disposal ........................................... 19

Produkt Specifikationer

Mærke:	Technaxx
Kategori:	Solpanel
Model:	TX-220
Bredde:	1555 mm
Dybde:	1038 mm
Højde:	80 mm
Vægt:	38000 g
Brugervejledning:	Ja
Driftstemperatur (T-T):	-40 - 85 °C
Solcellepanel strøm:	600 W
Vurderet effekt:	600 W
Billede:	Ja
Stiktype:	MC4
Solcellepanel spænding:	31.6 V
Solpanel strøm:	10290 mA
Maksimal systemspænding:	1000 V
Energiydelse:	600 W
Energiydelse (år):	570 kWh
Energiydelse (dag):	1.56 kWh
Solarcelletype:	Monokrystallinsk silicium
Celleffektivitet:	22.7 %
PV-inverter inkluderet:	Ja
Invertertype:	mikro
PV-inverter el:	600 W
Batteridåseadapter:	Ja
Endelåg inkluderet:	Ja
