Model: TX-241; Article No. 5064; 02/2023

Technaxx

* User Manual

Solar Balcony Power Plant 800W TX-241

Before using the appliance for the first time, please read the instructions for use and

safety information carefully.

This appliance is not intended for use by persons (including children) with reduced

physical, sensory or mental capacities, or by persons lacking in experience or

knowledge, unless they are supervised or instructed on the use of this device by a

person responsible for their safety. Children should be supervised to ensure they do

not play with this device.

Keep this user manual for future reference or product sharing carefully. Do the same

with the original accessories for this product. In case of warranty, please contact the

dealer or the store where you bought this product.

Enjoy your product. * Share your experience and opinion on one of the well-

known internet portals.

Specifications subject to change without notice - please make sure you are using the

latest manual available on the manufacturer's website.

2
Model: TX-241; Article No. 5064; 02/2023
Table of Contents
Important notes at the start ................ 3
Explanation of the pictograms used 3
Note ............................................... 4
Safety instructions .......................... 4
Intended use .................................. 5
Caution measures during installation
 ....................................................... 6
Qualified personnel ........................ 6
Disclaimer ...................................... 6
Features ............................................ 7
Product details ................................... 7
Package content: ............................ 7
Product variants: ............................ 7
Prduct overview .............................. 7
Preparation ........................................ 8
Requirements for  the  operation of  a
photovoltaic system ........................ 8
Connecting the micro inverter ............ 8
Connect  the  solar  panels  (DC
connection) ..................................... 9
Connecting the micro inverter to the
AC grid (AC connection) ................. 9
Mounting .......................................... 10
General hints ................................ 10
Balcony ......................................... 10
Flat roof (bitumen roof) ................. 10
Facade .......................................... 11
First commissioning .......................... 11
LED status ........................................ 12
Troubleshooting ................................ 12
Technical specifications .................... 14
Inverter ......................................... 14
Appendix .......................................... 15
Determining the line reserve ......... 15
Load capacity of copper lines ........ 16
Determination of the line reserve .. 17
Support ............................................ 17
Care and maintenance ..................... 17
Declaration of Conformity ................. 17
Disposal ........................................... 17



Produkt Specifikationer

Mærke:	Technaxx
Kategori:	Solpanel
Model:	TX-241
Bredde:	1724 mm
Dybde:	80 mm
Højde:	1134 mm
Vægt:	45000 g
Driftstemperatur (T-T):	-40 - 85 °C
Kabellængde:	1.5 m
Maksimal udgangsspænding:	230 V
Vurderet effekt:	410 W
Stiktype:	MC4
Maksimal systemspænding:	1000 V
Energiydelse (år):	850 kWh
Energiydelse (dag):	2.33 kWh
Solarcelletype:	Monokrystallinsk silicium
Celleffektivitet:	20.97 %
Invertertype:	mikro
PV-inverter el:	800 W
Strøm ved maksimal effekt (Imp):	13.04 A
Spænding ved maksimal effekt (Vmp):	31.46 V
Antal bypassdioder:	3
