Model: TX-250; Article No. 5082; 10/2023

Technaxx

* User Manual

Solar Table Power Plant 400W TX-250

IMPORTANT, KEEP FOR FUTURE REFERENCE: READ CAREFULLY

Before using the appliance for the first time, please read the instructions for use and

safety information carefully.

This appliance is not intended for use by persons (including children) with reduced

physical, sensory or mental capacities, or by persons lacking in experience or

knowledge, unless they are supervised or instructed on the use of this device by a

person responsible for their safety. Children should be supervised to ensure they do

not play with this device.

Keep this user manual for future reference or product sharing carefully. Do the same

with the original accessories for this product. In case of warranty, please contact the

dealer or the store where you bought this product.

Solar Panel

Micro Inverter

Limited Product Warranty – 2 years

Limited Peak Power Warranty - Limited Remedy 2 years

12 years (144months)

limited warranty

Enjoy your product. * Share your experience and opinion on one of the well-

known internet portals.

Specifications subject to change without notice - please make sure you are using the

latest manual available on the manufacturer's website.

2
Model: TX-250; Article No. 5082; 10/2023
Table of Contents
Important notes at the start ................ 3
Intended use .................................. 3
Explanation of the pictograms used 3
Note ............................................... 4
Risk of injury! .................................. 4
Risk of damage! ............................. 4
Safety instructions .......................... 5
Caution measures during installation
 ....................................................... 7
Qualified personnel ........................ 7
Disclaimer ...................................... 7
Features ............................................ 7
Product details ................................... 8
Package content: ............................ 8
Product overview ............................ 8
Preparation ........................................ 9
Requirements for  the  operation of  a
photovoltaic system ........................ 9
Assembly ......................................... 10
General notes ............................... 10
Leg mounting ............................... 10
Connection cable routing/mounting .. 12
Mounting the connection cable to the
leg ................................................ 12
Connecting the micro inverter ....... 12
Connect  the  solar  panels  (DC
connection) ................................... 13
Connecting the micro inverter to the
AC grid (AC connection) ............... 13
Set up the table ................................ 14
Leg  height  adjustment  /  Level  out
unevenness .................................. 14
Use as power plant ........................... 15
Angle adjustment .......................... 15
Estimated yield ............................. 15
How to set up the angle? .............. 15
First commissioning .......................... 16
LED status ........................................ 16
WiFi configuration ............................. 17
Get the APP .................................. 17
Webpage ...................................... 18
Troubleshooting ................................ 19
Technical specifications .................... 20
Table ............................................. 20
Inverter ......................................... 20
Appendix .......................................... 22
Determining the line reserve ......... 22
Load capacity of copper lines ........ 23
Determination of the line reserve .. 24
Support ............................................ 24
Care and maintenance ..................... 24
Storage ............................................ 24
Declaration of Conformity ................. 25
Disposal ........................................... 25



Produkt Specifikationer

Mærke:	Technaxx
Kategori:	Solpanel
Model:	TX-250
Bredde:	173 mm
Dybde:	114 mm
Højde:	4 mm
Vægt:	32500 g
Brugervejledning:	Ja
Produktfarve:	Sort
Maksimal belastningsvægt:	25 kg
Vægt (med stativ):	80 g
Kabellængde:	5 m
Hældningsvinkelområde:	20 - 35 °
Vurderet effekt:	410 W
Bedste anvendelsesmuligheder:	Altan
Installationstype:	Jord
PV-inverter inkluderet:	Ja
Invertertype:	mikro
PV-inverter el:	300 W
