Side 1/8

Optimum adjustment concept thanks to adjustability of the

entire signal chain incl. analog adjustment

Ethernet, relay and analog outputs allow optimum

integration into individual automation systems

Self-monitoring and early warning guarantee high system

availability

Calculation and presentation of all relevant humidity

parameters

P2A software for parameterization, adjustment and analysis

saves time and costs in commissioning and maintenance

Display with multi-language display

Robust, easy-to-clean metal housing

The industrial humidity

transmitter

testo 6681 + probe

series testo 661x

Industrial humidity measurement demands absolute

professionalism. Not only in running the system, but also

in the measuring technology used. The industrial humidity

transmitter testo 6681, combined with the probe series

testo 661x fulfils these high demands. The testo 6681

has a number of additional features, above and beyond

the properties and benefits of a conventional transmitter,

which will delight practitioners. This and other reasons

make the testo 6681 the first choice in drying technology,

trace humidity and compressed air process technology, as

well as in demanding air conditioning technology, e.g. in

cleanrooms.

www.testo.com

%RH

°C

Supply

Analog outputs

Further outputs

Measurement rate 1/s

Quantity 2, optionally 3 channels (channel freely

selectable)

Resolution 12 bit

Max. load 500 Ω at 24 VAC/DC

Inputs and outputs

Output type 0/4 to 20 mA (2-wire/4-wire)

0 to 1/5/10 V (4-wire)

Ethernet Optional: module can be fitted as

intermediary layer

Voltage supply 2-wire: 24 VDC ±10 %

4-wire: 20 to 30 VAC/DC

Display

Design

Miscellaneous

Installation

Display Optional: 2-line LCD with clear text line

and relay status display

General technical data

Material Metal

Dimensions 122 x 162 x 77 mm (without probe)

Resolution

Protection class IP65

EMC 2004/108/EG

Weight 1.960 kg

(without probe, without Ethernet module)

Operation

Parameterization 4 operating buttons for display / P2A

software

Operating conditions

Humidity

Measurement parameters

Measuring range 0 to 100 %RH

Selectable units Dependent on probe, available are:

relative humidity %RH; normed atm. dewpoint

in °CtdA (°Ftd); dewpoint in °Ctd (°Ftd);

absolute humidity in g/m³ (gr/ft³); degree of

humidity in g/kg (gr/lb); enthalpy in kj/kg (BTU/

lb); psychrometer temperature in °Ctw (°Ftw);

water vapour partial pressure in hPa/H20; water

content in ppmV; mixture dewpoint H2O2 in

°Ctm/°Ftm; %RH acc. to WMO; temperature in

°C/°F

Trace humidity

Measuring range -60 to +30 °Ctd / -76 to +86 °Ftd

(only with testo 6610 L15)

Selectable units Dewpoint in °Ctd/°Ftd

Galvanic isolation Galvanic isolation of the output

signals (2-wire and 4-wire), isolation

of supply from outputs (4-wire)

Accuracy of the analog

outputs

0/4 to 20 mA ± 0.03 mA

0 to 1 V ±1.5 mV

0 to 5 V ±7.5 mV

0 to 10 V ±15 mV

Relays Optional: 4 relays (free allocation to

measurement channels or as collective alarm

with operating menu/PsA software), up to

250 V AC/DC / 3 A (NO/NC)

Other outputs Mini DIN for Testo P2A software

Current consumption max. 300 mA

Probe connection Digital probe connection

Temperature

Measuring range Dependent on probe (testo 661x)

Selectable units Temperature in °C/°F

Operating temperature

(with integrated relay)

-40 to +60 °C

Measurement medium Air, nitrogen

Operating temperatureWithout

display

With display

-40 to +70 °C / -40 to +158 °F

Storage temperature -40 to +80 °C / -40 to +176 °F

Operating temperature 0 to +50 °C / +32 to +122 °F

Storage temperature -40 to +80 °C / -40 to +176 °F

0.1 %RH / °Ctd / °Ftd / °Ctw / °Ftw

or 0.01 °C/°F 1g / kg / g/m³ / ppm

testo 6681 – The industrial humidity transmitter + probe series testo 661x

Technical data testo 6681
