Side 1/20

CDx4HCT373 Octal Transparent D-Type Latches With 3-State Outputs

1 Features

• 4.5-V to 5.5-V VCC operation

• Wide operating temperature range of

–55°C to 125°C

• Balanced propagation delays and transition times

• Standard outputs drive up to 10 LS-TTL loads

• Significant power reduction compared to LS-TTL

Logic ICs

• Inputs are TTL-voltage compatible

2 Description

The ’HCT373 devices are octal transparent D-type

latches. When the latch-enable (LE) input is high, the

Q outputs follow the data (D) inputs. When LE is low,

the Q outputs are latched at the logic levels of the D

inputs.

Device Information

PART NUMBER PACKAGE(1) BODY SIZE (NOM)

CD74HCT373M SOIC (20) 12.80 mm × 7.50 mm

CD74HCT373E PDIP (20) 25.40 mm × 6.35 mm

CD54HCT373F CDIP (20) 26.92 mm × 6.92 mm

(1) For all available packages, see the orderable addendum at

the end of the data sheet.

Funtional Block Diagram

CD54HCT373, CD74HCT373

SCLS453D – FEBRUARY 2001 – REVISED FEBRUARY 2022

An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,

intellectual property matters and other important disclaimers. PRODUCTION DATA.

Table of Contents

1 Features............................................................................1

2 Description.......................................................................1

3 Revision History.............................................................. 2

4 Pin Configuration and Functions...................................3

5 Specifications.................................................................. 4

5.1 Absolute Maximum Ratings........................................ 4

5.2 Recommended Operating Conditions(1) .................... 4

5.3 Thermal Information....................................................4

5.4 Electrical Characteristics.............................................5

5.5 Timing Requirements..................................................5

5.6 Switching Characteristics ...........................................5

5.7 Operating Characteristics........................................... 5

6 Parameter Measurement Information............................6

7 Detailed Description........................................................7

7.1 Overview.....................................................................7

7.2 Functional Block Diagram...........................................7

7.3 Device Functional Modes............................................7

8 Power Supply Recommendations..................................8

9 Layout...............................................................................8

9.1 Layout Guidelines....................................................... 8

10 Device and Documentation Support............................9

10.1 Receiving Notification of Documentation Updates....9

10.2 Support Resources................................................... 9

10.3 Trademarks...............................................................9

10.4 Electrostatic Discharge Caution................................9

10.5 Glossary....................................................................9

11 Mechanical, Packaging, and Orderable

Information...................................................................... 9

3 Revision History

NOTE: Page numbers for previous revisions may differ from page numbers in the current version.

Changes from Revision C (May 2003) to Revision D (February 2022) Page

• Updated the numbering, formatting, tables, figures, and cross-references throughout the doucment to reflect

modern data sheet standards............................................................................................................................. 1

CD54HCT373, CD74HCT373

SCLS453D – FEBRUARY 2001 – REVISED FEBRUARY 2022 www.ti.com

Product Folder Links: CD54HCT373 CD74HCT373

Produkt Specifikationer

Mærke:	Texas Instruments
Kategori:	Ikke kategoriseret
Model:	CD74HCT373E
Type:	Logisk kredsløb
Bredde:	26.92 mm
Dybde:	6.6 mm
Højde:	4.57 mm
Antal pr. pakke:	20 stk
Pakkedybde:	506 mm
Pakkebredde:	13.97 mm
Pakkehøjde:	11.23 mm
Opbevaringstemperatur (T-T):	-65 - 150 °C
Driftstemperatur (T-T):	-55 - 125 °C
Pakketype:	PDIP
Antal stifter:	20
Bredde (med stifter):	26.92 mm
Højde (med stifter):	8.26 mm
Dybde (med stifter):	10.92 mm
