pg 1
tisira | www.tisira.com
User manUal
14 place integrated dishwasher
TDW14I
IMPORTANT // Please ensure that you read through this user manual prior to installation and use. This
manual contains important information to ensure optimal performance and keep you safe. Please retain your
proof of purchase, as this will be required in the event that you require warranty service. Remember to retain
this manual for future reference.
www.tisira.com

pg 2
| tisirawww.tisira.com
CONGRATULATIONS ON THE SELECTION OF THIS TISIRA APPLIANCE. TISIRA
APPLIANCES HAVE BEEN SPECIFICALLY DESIGNED FOR AUSTRALIAN AND
NEW ZEALAND KITCHENS.
Please read through this user manual carefully as it contains information that
will ensure that your appliance is installed correctly, important operating &
care instructions and also some advice of what you need to do if this appliance
is not performing as intended.
hellO

pg 3
tisira | www.tisira.com
CO SNTENT
HELLO 2
CONTENTS 3
WARNINGS 4
PRODUCT OVERVIEW 5-6
OPERATING INSTRUCTIONS 7-17
MAINTENANCE 18-19
INSTALLATION 20-23
TROUBLESHOOTING 24-25
PRODUCT SPECIFICATIONS 26
NOTES 27
CONTACT DETAILS 28

pg 4
| tisirawww.tisira.com
IMPORTANT // To get the best performance from your dishwasher, read all operating
instructions before using it for the first time.
safety infOrmatiOn
WARNING // HYDROGEN GAS IS EXPLOSIVE
Under certain conditions, Hydrogen gas
may be produced in a hot water system that
has not been used for two weeks or more. If
the hot water system has not been used for
such a period, before using the dishwasher
turn on all hot water faucets and let the
water flow from each for several minutes.
This will release any accumulated hydrogen
gas. As the gas is flammable, do not smoke
or use an open flame during this time.
•Do not touch the heating element during
or immediately after use.
•Do not operate your dishwasher unless
all enclosure panels are properly in
place. Open the door very carefully if the
dishwasher is operating. There is a risk
of water leaking out.
•Do not place any heavy objects or
stand on the door when it is open. The
appliance could tip forward.
•Use only detergent and rinse additives
designed for an automatic dishwasher.
Never use soap, laundry detergent,
or hand washing detergent in your
dishwasher.
•Young children should be supervised
to ensure that they do not play with the
appliance.
•The door should not be left in the open
position since this could present a
tripping hazard.
•This appliance is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning
use of the appliance by a person
responsible for their safety.
•If the supply cord is damaged, it must
be replaced by the manufacturer or its
service agent or a similarly qualified
person in order to avoid a hazard.
•Please dispose of packing materials
properly.
•This appliance is intended to be used in
household and similar applications such
as: staff kitchen areas in shops, offices
and other working environments;farm
houses: by clients in hotels, motels and
other residential type environments;
bed and breakfast type environments.
•Dishwasher detergents are strongly
alkaline. They can be extremely
dangerous if swallowed. Avoid contact
with the skin and eyes, and keep children
away from the dishwasher when the
door is open. Check that the detergent
receptacle is empty after completion of
the wash cycle.
warnings

pg 5
tisira | www.tisira.com
PRODUCT
OVERVIEW
CONTROL PANEL
1. Pro in or :gram dicat light u When yo
sele a w ng g m the ct ashi pro ram e,
co espo w l .rr nd g ghin li t il display
2. Pro b on:gram select utt e the Pr ss
bu on to se tt lect th was inge h pr m. ogra
3. Rin a in or :se id dicat light li t w l This gh il
come on wh the e er s to en disp ns need
be e . r filled
4. D i :ry ng light come on w n the To he
dis ash dryinghw e r is .
5. D :isplay To d l del e or e r isp ay ay tim rro
codes e m ed e ft for or the sti at tim le
pro ra to rung mme .
6. D time:elay Th o on w l a w you is pti il llo
to del me w h ay the start ti of any as
cyc to 24 urs enle fo r up ho (dep ding
on de S e t de me mo l). el ct he lay start ti
you want by p g the LAY p . ressin DE ad
Mu le p w e the ltip ressing ill increas
de hou .lay rs
7. ON/OFF B on:utt To turn o e on/ ff th
po upwer s ply.
8. Che w er su y in or:ck at ppl dicat The
in or li up t p n or dicat ghts if he ta tur off
the w er y e u d or pply at suppl int rr pte su
ho nks ie k ed.
9. Ch :ild lock T hild ck be he “c lo ”will
avai yo ss th uttla wh ble en u pre e b on 3
sec s t i or h upa ond ,and he ndicat lig ts
fter 6 es tim
10 60. min pro e:gramm ly w in ly Dai ash on
1 h r.ou
11 io. 3 in 1 funct n: The pro is duct
off ed dd uner w h ait iti nao l f ctio s,n The
ad c ed w h diti alon fu onncti ould be us it
the pro gramme such e ” as “int nsive
“H “ rmal”.eavy” and no
12 ter cti esir ra. Af sele ng the d ed prog m,
cl e t e d er in os he door, th is ashhw
fu on ncti status.
1 235 6 789 10 11
Intensive
Heav y
Rinse
Rap id
So ak
Normal
4

pg 6
| tisirawww.tisira.com
prOdUct
OVerView
DISHWASHER FEATURES
frOnt View
1. Cutlery Tray
2. Upper Basket
3. Lower Basket
4. Detergent Dispenser
5. Cup Holder
6. Spray Arms
7. filters
8. Rinse Aid Dispenser
1
2
3
4
6
7
5
8

pg 7
tisira | www.tisira.com
Operating
instrUctiOns
ATTENTION // Before using your dishwasher for the first time, please make sure that you
read the following sections:
A. Fill the rinse aid dispenser B. Fill the detergent dispenser
A. FILL THE RINSE AID DISPENSER
fUnctiOn Of rinse aid
The rinse aid is automatically released during the last rinse in order to prevent water from
forming droplets on your dishes that can leave spots and streaks.
ATTENTION // Only use branded rinse aid in the dishwasher.
Never fill the rinse aid dispenser with any other substances (e.g. dishwasher cleaning agent,
liquid detergent). This would damage the appliance.
The rinse aid dispenser is located inside the door next to the detergent dispenser.
To fill the dispenser, open the cap and pour the rinse aid into the dispenser until the level
indicator turns completely black. The volume of the rinse aid container is about 140ml.
Be careful not to overfill the dispenser, because this could cause over sudsing. Wipe away any
spills with a damp cloth. Don’t forget to close the cap before you close the dishwasher door.
1. To open the dispenser, turn the cap to the “open” (left) arrow and lift it out.
2. Pour the rinse aid into the dispenser, be careful not to overfill.
3. Replace the cap by inserting it aligned with “open” arrow and turning it to the “closed”
(right) arrow.
ATTENTION // Clean up any rinse aid split during filling with an absorbent cloth to avoid
excess foaming during the next wash.
2
13

pg 8
| tisirawww.tisira.com
Operating
instrUctiOns
when tO refill the rinse aid
dispenser
You can judge the amount of rinse-aid by
the colour of the optical level indicator “D”
located next to the cap. When the rinse-aid
container is full, the whole indicator will be
dark .As the rinse aid diminishes, the size of
the dark dot decreases.
IMPORTANT // You should never let the
rinse aid get below 1 / 4 full.
Full
3 / 4 full
1 / 2 full
1 / 4 full - Should refill to eliminate
spotting
Empty
adjUsting rinse aid dispenser
The rinse aid dispenser has six settings.
Always start with the dispenser set on “4”
If spots and poor drying are problems,
increase the amount of rinse aid dispensed
by removing the dispenser lid and rotating
the dial to “5”. If the dishes still are not
drying properly or are spotted, adjust the
dial to the next higher number until your
dishes are spot-free. The dose is factory set
in position 5.
NOTE // Increase the dose if there are
drops of water or lime spots on the dishes
after washing. Reduce it if there are sticky
whitish streaks on the dishes or a bluish
film on glassware or knife blades.
FILL THE DETERGENT
DISPENSER
Detergents with its chemical ingredients
are necessary to remove dirt, crush dirt
and transport it out of the dishwasher.
Most of commercial quality detergents are
suitable for this purpose.
cOncentrated detergent
Based on their chemical composition,
dishwasher can be split in two basic types:
•conventional, alkaline detergents with
caustic components
•low alkaline concentrated detergents with
natural enzymes
The use of “normal” washing programme
in conjunction with concentrated detergents
reduces pollution and is good for your dishes;
these washing programmes are specially
matched to the dirt dissolving properties of the
enzymes of the concentrated detergents. For
this reason ”normal” washing programme in
which concentrated detergents are used can
Adjust lever
(Rinse)
1
2
3
4
5
6
MAX
D (RINSE-AID
INDICATOR)
1
2
3
4
5
6
MA X

pg 9
tisira | www.tisira.com
Operating
instrUctiOns
achieve the same results that can otherwise
only be achieved using ”intensive” programme.
detergent taBlets
Detergent tablets of different brands dissolve
at different speeds. For this reason some
detergent cannot dissolve and develop their
full cleaning power during short programmes.
Therefore please use long programmes
when using detergent tablets, to ensure the
complete removal of detergent residuals.
detergent dispenser
The dispenser must be refilled before the
start of each washing cycle following the
instructions provided in the “Washing Cycle
Table”. Your dishwashers use less detergent
and rinse aid than conventional dishwashers.
Generally, only one tablespoon of detergent
is needed for a normal wash load. Also, more
heavily soiled items need more detergent.
Always add the detergent just before
starting the dishwasher, otherwise the tablet
can get damp and it will not dissolve properly.
1. If the lid is closed: press release button.
The lid springs open.
2. before Always add the detergent just
starting each washing cycle. Only use
branded detergent aid for dishwasher.
WARNING // Dishwasher detergent is
corrosive! Take care to keep it out of reach
of children. Use only detergent specifically
made for use in dishwashers. Keep your
detergent fresh and dry. o not put powder
detergent into the dispenser until you’re
ready to wash the dishes.
fill in the detergent
Fill the detergent dispenser with detergent.
The marking indicates the dosing levels , as
illustrated above:
1. Main washing cycle detergent dispenser.
MIN means approximately 20g of detergent.
2. Pre washing cycle detergent dispenser.
Approximately 5g of detergent.
Close the lid and press until it locks in place.
1
2
34
5
6
MA X
1 2
1
2

pg 12
| tisirawww.tisira.com
OPERATING
INSTRUCTIONS
FORGET TO ADD A DISH
A forgotten dish can be added any time before the detergent cup opens.
1. Open the door a little to stop the washing.
2. After the spray arms stop working, you can open the door completely.
3. Add forgotten dishes.
4. Close the door, the dishwasher will work after ten seconds.
WARNING // It is dangerous to open the door when washing, because the hot water may
scald you.
SWITCH OFF THE DISHWASHER
The digital display appears “---” and the buzzer rings 6 times, only in this case the programme
has ended. Turn off the dishwasher by pressing the Power button.
Open the door carefully. Hot steam may escape when the door is opened!
•Hot dishes are sensitive to knocks. The dishes should therefore be allowed to cool down
around 15 minutes before removing from the appliance.
•Open the dishwasher’s door, leave it ajar and wait a few minutes before removing the dishes.
In this way they will be cooler and the drying will be improved.
WHEN LOADING ITEMS TO BE WASHED:
•Locate sharp items so that they are not likely to damage the door seal.
•Knives and other utensils with sharp points must be loaded in the basket with their
•points down or placed in a horizontal position.
•When using your dishwasher, you should prevent plastic items from contacting with heating
element.
•Do not wash plastic items unless they are marked dishwasher safe or the equivalent. For
plastic items not so marked, check the manufacturer’s recommendations.
Produkt Specifikationer
Mærke: | Tisira |
Kategori: | Opvaskemaskine |
Model: | TDW14I |
Har du brug for hjælp?
Hvis du har brug for hjælp til Tisira TDW14I stil et spørgsmål nedenfor, og andre brugere vil svare dig
Opvaskemaskine Tisira Manualer

5 September 2024

5 September 2024

5 September 2024
Opvaskemaskine Manualer
- Opvaskemaskine Team
- Opvaskemaskine Nuova Simonelli
- Opvaskemaskine Zanussi
- Opvaskemaskine Sammic
- Opvaskemaskine Luxor
- Opvaskemaskine Miele
- Opvaskemaskine Veripart
- Opvaskemaskine Noble
- Opvaskemaskine Asko
- Opvaskemaskine Balay
- Opvaskemaskine Concept
- Opvaskemaskine Proline
- Opvaskemaskine Siemens
- Opvaskemaskine Candy
- Opvaskemaskine Juno
Nyeste Opvaskemaskine Manualer

8 Juni 2025

8 Juni 2025

8 Juni 2025

8 Juni 2025

8 Juni 2025

8 Juni 2025

8 Juni 2025

8 Juni 2025

8 Juni 2025

8 Juni 2025
