Side 1/8
GB
-1-
Chart
PROGRAMME
SELECTOR
KNOB
(see “Table of
programmes”
below).
START
DELAY
option
MULTI
ZONE
option
ANTI-
BACTERIAL
RINSE
option
ON/OFF
BUTTON
START BUTTON
The indicator lights up during operation, flashes when a fault occurs, and goes off
at the end of the programme.
START BUTTON RESET FUNCTION:
Press this button for at least 2 seconds; the selected programme and options will
be cancelled. Main failure displays (repeated flashing of the START indicator lamp)
can be cancelled by RESETTING. Detailed instructions are given in chapter
“What to do if...”.
(see at right for options description)
1) Programme data obtained in conformity with European standard EN 50242, obtained under normal conditions (without additional options) and may vary
depending on conditions. Differences of up to 20 minutes are possible with sensor programmes as a result of the appliance’s automatic calibration system
.
2) Reference programme for energy label in compliance with EN 50242 regulations. - Note for Testing Institutes: for detailed information on the
EN/Standard loading comparison test and other tests, contact the following address: “nk_customer@whirlpool.com”.
3) The antibacterial action has been tested by the Institut Pasteur of Lille (France), based on the NF EN 13697 standard of November 2001.
Table of programmes
Deter-
gent
Consumption
P
Programmes
Available
options
Loading instructions
Litres kWh
Minutes
1)
1
Aqua Steam 60-70°C
Delay
Multizone
Antibacterial
rinse
Automatic programme recommended for
heavily soiled crockery with dried-on or
burnt food, for example pans and
saucepans. Thanks to steam action,
soaking or hand pre treatment is no longer
needed. In addition sanitation is ensured
due to the high temperature steam..
X 13-20 1.10-2.00 100-150
2
Sensor Normal 40-55°C
Delay
Multizone
Antibacterial
rinse
Automatic programme recommended
for routine washes, with no dried-on or
burnt food (not for EN 50242).
X 10-13 0.80-1.05 60-120
3
Pre-Wash cold
Delay
Multizone
Crockery to be washed later. — 4.0 0.03 14
4
Glasses 40°C
Delay
Multizone
Light soiling, for example glasses and
cups.
X 10.0 0.85 100
5
Quickwash 45°C
Delay
Multizone
Lightly soiled crockery, with no dried-
on food.
*
Use of tablets not
recommended.
X
*
11.0 0.80 30
6
Eco
2)
50°C
Delay
Multizone
Antibacterial
rinse
Normally soiled crockery.
Energy-saving programme.
X 11.0 1.05 155
5019 396 01796ADG 8196
Options and display description
BEFORE USING THE APPLIANCE FOR THE
FIRST TIME CAREFULLY READ THIS QUICK
REFERENCE GUIDE AND THE ASSEMBLY
INSTRUCTIONS! THE GUARANTEE IS NOT
APPLICABLE IF FAULTS ARE CAUSED BY
INCORRECT USE OF THE APPLIANCE.
DELAYED START
BUTTON
Press the button (repeatedly)
to delay the start of the
programme. Adjustable from 1
to 24 hours. With each press of
the button, the delayed start
indicator increases by one hour
and after 24 restarts from 00.
Then press the START button.
The dishwasher will start after
the set time.
HALF LOAD/MULTIZONE
Allows you to choose the
washing zones. Press this button
to select the wash zones:
both racks
only upper rack
only lower rack
ANTIBACTERIAL RINSE
3)
This function activates an
antibacterial rinse at the end of
the wash cycle, guaranteeing a
further reduction of bacteria.
Press the button to activate or
deactivate the function. This
function can be used with
those programmes marked
with the relative description in
table. The dishwasher door
must be kept shut for the
entire duration of the
programme in order to
guarantee reduction of
bacteria. If the door is opened
the indicator lamp starts
flashing.
RINSE AID INDICATOR
When lit, the rinse aid dispenser needs
to be refilled.
SALT INDICATOR
When lit, the salt reservoir
needs to be refilled.
FAULT INDICATION AND WASH TIME DISPLAY
In normal operation it indicates the remaining time (h:mm),
whereas with “Delayed start” selected it indicates the time
remaining until programme start (hh).
If “F..” appears on the display, see chapter “What to do if...”.
Quick reference guide
