Side 1/12

EN -1-

Whirlpool is a registered trademark of Whirlpool USA

Chart

BEFORE USING THE APPLIANCE FOR THE FIRST TIME CAREFULLY READ THIS QUICK REFERENCE GUIDE AND THE ASSEMBLY INSTRUCTIONS!

5019 300 02637

FOR ENERGY SAVING THE CONTROL PANEL DEACTIVATES AUTOMATICALLY AFTER 30 SECONDS IF NO CYCLE HAS STARTED.

PROGRAM

SELECTION

BUTTON

Push “P” button

(repeatedly) until

selected program

number is shown

on the display

(P1...Px) - see

“Table of

programs” - next

page.

After 3 seconds

the cycle

remaining time is

displayed.

START/PAUSE/

RESUME

BUTTON

Push this button to

start the selected

program: the

indicator lights up

and goes off at the

end of the program.

Press Start button or

open the door

during washing cycle

to pause the cycle -

the Start Indicator

blinks.

To resume the cycle

push Start button

and close the door.

CANCEL/OFF

BUTTON

Push this button to

switch off the control

panel.

If pressed for 3 seconds

when a program is

running it cancels this

program. If pressed

for 3 seconds when

the dishwasher is off,

it drains the water out.

If pressed during

program and delayed

start selection it

cancels the selection

and returns to

previous cycle and

option selection.

ECO PROGRAM

INDICATOR

When lit, it indicates that

standard program is active.

MULTIZONE

INDICATOR

When lit, it indicates the

wash in the upper or lower

rack only.

KEYBOARD LOCK

INDICATOR

When lit, it indicates that

keyboard lock is active.

WATER TAP CLOSED

- Alarm

Blinks when there is no inlet

water or water tap is closed.

WASH TIME DISPLAY

Indicates the cycle duration and the remaining time (h:min). With “Delayed start”

selected it indicates the time remaining until program start: “h24” if above

10 hours delay time remain and “h:mm” if below 10 hours delay time remain.

If “Fx Ey” messages appears on the display, see page 9 - chapter “What to do if...”.

DELAY INDICATOR

When lit, it indicates that delay

is active.

RINSE AID

INDICATOR

When lit (at the end of the

cycle), the rinse aid dispenser

needs to be refilled.

SALT INDICATOR

When lit (at the end of the

cycle), the salt reservoir needs

to be refilled.

POWERCLEAN

Thanks to the additional

power jets this option

provides a more intensive

and powerful wash in the

lower rack, in the specific

area.

TABLET

SETTING

This setting allows to

optimize the cycle

performances

according the type of

detergent used. Push

the Tablet button

(the indicator lights

up) if you are using

the combined

detergents in tablet.

If you are using

powder or gel

detergent, the Tablet

indicator on the

control panel has to

be off.

MULTIZONE

Allows you to choose

the washing zones. The

appliance washes both

racks by default

(indicators are not lit).

To wash only in specific

rack, press this button

repeatedly:

KEYBOARD LOCK

This option allows you

to lock the buttons on

the control panel.

Children will not be

able to accidentally

start the dishwasher by

pressing the buttons on

the control panel when

this option is selected.

If you want to activate

this option hold down

the button for

3seconds.

Repeat the same

operation to unlock the

panel.

only upper rack

(including cutlery

rack) indicator lit

only lower rack

indicator lit

POWERDRY

This technology generates

outstanding drying results

thanks to a condensation

process that occurs inside

the dishwasher.

DELAYED START

BUTTON

Push the button

(repeatedly) to delay the

start of the program.

Adjustable from 0:30 to

24 hours. With each press

of the button, the delay

start increases by: 0:30 if

selection below 4 hours,

1:00 if selection is below

12 hours, 4 hours if

selection is above 12 hours.

If 24 hours reached, and

the button is pressed, the

delayed start is deactivated

- “OFF” message is shown.

Then press the START

button. The delay time can

be adjusted after Start key

press. The dishwasher will

start after the set time.

Quick reference guide

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Opvaskemaskine
Model:	ADP 9070 IX
Vekselstrømsindgangsspænding:	220 - 230 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	597 mm
Dybde:	590 mm
Højde:	850 mm
Vægt:	51000 g
Kontroltype:	Knapper
Indbygget skærm:	Ja
Strøm:	10 A
Pakkevægt:	52200 g
Pakkedybde:	660 mm
Pakkebredde:	640 mm
Pakkehøjde:	870 mm
Energieffektivitetsklasse (gammel):	A+++
Årligt energiforbrug:	233 kWh
Strømforbrug (slukket):	0.4 W
Placering af apparat:	Fritstående
Tilsluttet belastning:	2040 W
Støjniveau:	44 dB
Tilløbsslange, længde:	1.5 m
Antal vaskeprogrammer:	10
Forsinket start-timer:	Ja
Justerbare fødder:	Ja
Dør farve:	Rustfrit stål
Vaskeklasse:	A
Vandforbrug pr. cyklus:	10 L
Bestik rum type:	Skuffe
Farve på kontrolpanel:	Black, Stainless steel
Antal kuverter:	13 kuverter
Cyklustid:	200 min.
Forsinket start (maks.):	24 t
Opvaskeprogrammer:	Eco, Glass/delicate, Intensive, Night, Pre-wash, Quick
Tørringsklasse:	A
Årligt vandforbrug:	2800 L
Energiforbrug pr. cyklus:	0.82 kWh
Antal temperaturindstillinger:	8
AquaStop funktion:	Ja
Udøsslange længde:	2 m
Temperatur (maks):	60 °C
Øverste kurv indstillelig højde:	Ja
Kurves indstillelige placering:	Øvre
