OPERATING INSTRUCTIONS

MOUNTING BRACKETS

V-Series Mounting Brackets

HY-1200VB

HY-1200VW

HY-1500VB

HY-1500VW

H-Series Mounting Brackets

HY-1200HB

HY-1200HW

HY-1500HB

HY-1500HW

Installation to a ceiling

(V-Series Bracket use)

Installation to a ceiling

(H-Series Bracket use)

Thank you for purchasing TOA's Mounting Bracket.

Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.

TABLE OF CONTENTS

1. SAFETY PRECAUTIONS ............................. 2

2. GENERAL DESCRIPTION ........................... 3

3. SAFETY WIRE INSTALLATION

(For speaker fall prevention) ...................... 4

4. INSTALLING TO A CEILING ........................ 4

5. INSTALLING ON A WALL .......................... 10

6. DIMENSIONAL DIAGRAMS ....................... 14

7. SPECIFICATIONS ...................................... 16

Accessories ................................................. 16

Optional products ........................................ 16

1. SAFETY PRECAUTIONS

• Before installation or use, be sure to carefully read all the instructions in this section for correct and safe

operation.

• Be sure to follow all the precautionary instructions in this section, which contain important warnings and/or

cautions regarding safety.

• After reading, keep this manual handy for future reference.

Safety Symbol and Message Conventions

Safety symbols and messages described below are used in this manual to prevent bodily injury and property

damage which could result from mishandling. Before operating your product, read this manual first and

understand the safety symbols and messages so you are thoroughly aware of the potential safety hazards.

Indicates a potentially hazardous situation which, if mishandled, could

result in death or serious personal injury.

WARNING

When Installing the Unit

• Install the unit only in a location that can structurally support the full weight of the unit and speaker. Doing

otherwise may result in the unit falling down and causing personal injury and/or property damage.

• Since the unit is designed for in-door use, do not install it outdoors. If installed outdoors, the aging of parts

causes the unit to fall off, resulting in personal injury.

• Owing to the speaker's size and weight, be sure that at least two persons are available to install the speaker.

Failure to do so could result in personal injury.

• Do not use other methods than specified to mount the bracket. Extreme force is applied to the unit and the

unit could fall off, possibly resulting in personal injuries.

• Use nuts and bolts that are appropriate for the ceiling's or wall's structure and composition. Failure to do so

may cause the speaker to fall, resulting in material damage and possible personal injury.

• Tighten each nut and bolt securely. Ensure that the bracket has no loose joints after installation to prevent

accidents that could result in personal injury.

• Use the specified speaker in combination. Doing otherwise may cause the speaker to fall off, resulting in

personal injury.

• Do not mount the unit in locations exposed to constant vibration. The mounting bracket can be damaged by

excessive vibration, potentially causing the unit to fall, which could result in personal injury.

• Do not install the unit in indoor swimming pools or such locations where corrosion may occur easily. The

parts deteriorate if corroded, causing the unit to fall, which could result in personal injury.

Indicates a potentially hazardous situation which, if mishandled, could

result in moderate or minor personal injury, and/or property damage.

CAUTION

When Installing the Unit

• Avoid touching the unit's sharp metal edge to prevent injury.

When the Unit is in Use

• Do not stand or sit on, nor hang down from the unit as this may cause it to fall down or drop, resulting in

personal injury and/or property damage.

• Have the unit checked periodically by the shop from where it was purchased. Failure to do so may result in

corrosion or damage to the speaker or the unit that could cause it to fall, possibly causing personal injury.

Produkt Specifikationer

Mærke:	TOA
Kategori:	Ikke kategoriseret
Model:	HY-1500VW
Bredde:	460.4 mm
Dybde:	90 mm
Højde:	403.2 mm
Vægt:	3000 g
Antal pr. pakke:	1 stk
Produktfarve:	Hvid
Pakkevægt:	4100 g
Materiale:	Stål
