IP-A1PC580R

IP-A1PC580S

IP CEILING MOUNT SPEAKER

IP SQUARE SPEAKER

INSTRUCTION MANUAL

Thank you for purchasing TOA’s IP Speaker.

Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.

TABLE OF CONTENTS

1. SAFETY PRECAUTIONS

......................................................................................................... 2

2. SUMMARY AND FEATURES .................................................................................................. 4

3. ABOUT SECURITY MEASURES ............................................................................................ 4

4. DIMENSIONAL DRAWINGS ................................................................................................... 5

5. NOMENCLATURE AND FUNCTIONS ................................................................................... 6

6. SYSTEM EXAMPLE .................................................................................................................. 8

6.1. SIP Broadcasting/Two-way Communication ........................................................................ 8

6.2. VMS Broadcasting ............................................................................................................... 8

7. HANDLING PRECAUTIONS .................................................................................................... 8

8. INSTALLATION PRECAUTIONS ............................................................................................ 9

9. INSTALLATION ......................................................................................................................... 9

9.1. IP-A1PC580R ........................................................................................................................ 9

9.2. IP-A1PC580S ..................................................................................................................... 10

10. CONNECTIONS ..................................................................................................................... 10

10.1. Connections to Line/Mic Input and Line Output Terminals .............................................. 10

10.2. Connections to Control Input and Output Terminals ....................................................... 11

10.3. Removable Terminal Plug Connections .......................................................................... 12

11. SETTINGS .............................................................................................................................. 13

11.1. System Settings Summary ............................................................................................... 13

11.2. System Requirements ...................................................................................................... 13

11.3. Connection with Browser ................................................................................................. 14

12. INITIALIZATION OF SETTINGS ......................................................................................... 15

13. CAUTIONS REGARDING THE AVC/H.264 PATENT LICENSE ..................................... 16

14. OPEN SOURCE SOFTWARE .............................................................................................. 16

15. ACCESSORIES ..................................................................................................................... 16

1. SAFETY PRECAUTIONS

• Before installation or use, be sure to carefully read all the instructions in this section for

correct and safe operation.

• Be sure to follow all the precautionary instructions in this section, which contain important

warnings and/or cautions regarding safety.

• After reading, keep this manual handy for future reference.

WARNING

When Installing the Speaker

• Do not expose the speaker to rain or an

environment where it may be splashed by

water or other liquids, as doing so may result

in re or electric shock.

• Install the speaker only in a location that can

structurally support the weight of the speaker

and the mounting bracket. Doing otherwise

may result in the speaker falling down and

causing personal injury and/or property

damage.

• Since the speaker is designed for indoor use,

do not install it outdoors. The speaker is to be

connected only to PoE networks without routing

to the outside plant. If installed outdoors, the

aging of parts causes the speaker to fall off,

resulting in personal injury. Also, when it gets

wet with rain, there is a danger of electric shock.

• Do not mount the speaker in locations

exposed to constant vibration. The mounting

bracket can be damaged by excessive

vibration, potentially causing the speaker to

fall, which could result in personal injury.

When the Speaker is in Use

• Should the following irregularity be found

during use, immediately cut off the power

supply from a PoE switching hub and contact

your nearest TOA dealer. Make no further

attempt to operate the speaker in this condition

as this may cause re or electric shock.

· If you detect smoke or a strange smell

coming from the unit

· If water or any metallic object gets into the

speaker

· If the speaker falls, or the speaker case

breaks

· If the LAN cable is damaged (exposure of

the core, disconnection, etc.)

· If the speaker suddenly stops producing

sound

• To prevent a re or electric shock, never open

nor remove the speaker case as there are high

voltage components inside the speaker. Refer

all servicing to qualied service personnel.

• To prevent the electromagnetic wave from

badly inuencing medical equipment, make

sure to switch off the speaker’s power when

placing it in close proximity to the medical

equipment.

CAUTION

When Installing the Speaker

• Attach the safety wire to the speaker. If not

attached, the speaker could fall off, resulting

in personal injury.

• Avoid installing the speaker in humid or dusty

locations, in locations exposed to the direct

sunlight, near the heaters, or in locations

generating sooty smoke or steam as doing

otherwise may result in re or electric shock.

Indicates a potentially hazardous situation which, if mishandled,

could result in death or serious personal injury.

WARNING

Indicates a potentially hazardous situation which, if mishandled, could

result in moderate or minor personal injury, and/or property damage.

CAUTION
