Side 1/4

TS -811, TS -911

TS-812, TS-912

Chairman UniTS

DelegaTe UniTS

inSTrUCTiOn manUal

Thank you for purchasing TOA’s Chairman Unit and Delegate Unit.

Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.

1. SaFeTY PreCaUTiOnS

•Beforeinstallation or use,be sure to carefullyread all the instructions in this section for

correct and safe operation.

•Besuretofollowalltheprecautionaryinstructionsinthissection,whichcontainimportant

warnings and/or cautions regarding safety.

•Afterreading,keepthismanualhandyforfuturereference.

Indicates a potentially hazardous situation which, if mishandled,

could result in death or serious personal injury.

Warning

Indicates a potentially hazardous situation which, if mishandled, could

result in moderate or minor personal injury, and/or property damage.

CaUTiOn

Warning

•Do not expose the unit to rain or an

environment where it may be splashed by

water or other liquids, as doing so may

resultinreorelectricshock.

•Avoid installing or mounting the unit in

unstable locations, such as on a rickety

table or a slanted surface. Doing so may

result in the unit falling down and causing

personal injury and/or property damage.

•Should the following irregularity be found

during use, immediately stop supplying

the power and contact your nearest TOA

dealer. Make no further attempt to operate

the unit in this condition as this may cause

reorelectricshock.

· If you detect smoke or a strange smell

coming from the unit.

· If water or any metallic object gets into the

unit

· If the unit falls, or the unit case breaks

· If it is malfunctioning (no tone sounds.)

•To prevent a re or electric shock, never

open nor remove the unit case as there

are high voltage components inside the

unit.Referallservicingtoqualiedservice

personnel.

•Do not place cups, bowls, or other

containers of liquid or metallic objects on

top of the unit. If they accidentally spill into

the unit, this may cause a re or electric

shock.

•Do not insert nor drop metallic objects or

ammable materials in any openings, as

thismayresultinreorelectricshock.

•To prevent possible hearing

damage, do not listen at high

volume levels for long periods.

•Avoid installing the unit inhumid or dusty

locations,inlocationsexposedtothedirect

sunlight, near the heaters, or in locations

generating sooty smoke or steam as doing

otherwise may result in re or electric

shock.

•Donotplaceheavyobjectsontheunitas

this may cause it to fall or break which may

result in personal injury and/or property

damage. In addition, the object itself may

fall off and cause injury and/or damage.

•Makesurethatthevolumecontrolissetto

minimum position before power is switched

on. Loud noise produced at high volume

when power is switched on can impair

hearing.

CaUTiOn

2. general DeSCriPTiOn

TheTS-911/811Chairmanunit*andtheTS-912/812Delegateunit*aredesignedtobeconnected

to the conference system by a cable.

EachunitisdirectlyconnectedtotheTS-919B1orTS-919B4Bridgeunit,thentotheTS-910Central

unitviatheTS-918Expansionunit.

Optional2typesofmicrophonesareavailable:TS-903StandardtypemicrophoneorTS-904Long

type microphone, either of which can be selected.

*CollectivelyreferredtoasaConferenceunit.

3. FeaTUreS

•TheTS-911/912unitfeaturesavotingfunctionandbaselanguage/translationlanguageselection

function,whiletheTS-811/812unitisequippedonlywithspeakingandmonitoringfunctions.

•ChairmanunitsfeatureaSpeechpriorityfunctionthatallowsspeechmadebytheChairmanunit

to take precedence over that by the Delegate units with the simple press of the Priority speech

key.

•DIP switch settings determine the following operations: Conference unit operating status after

priority speech completion, Priority chime ON/OFF, and Priority speech key operation mode.

•TheTS-911isequippedwithavotingfunctionenabledbytheDIPswitchsetting.

•ConnectionbetweentheWiredConferenceunitandtheBridgeunitcanbemadeusingasingle

CAT-5 LAN cable, facilitating installation and construction work.

•TwotypesofBridgeunitsareavailable:single-Conferenceunitconnectiontypeand4-Conference

unit connection type, either of which is freely selectable depending on installation conditions.

•ConferenceunitmicrophonesareattachedviaXLRconnectorsthatpermiteasydetachmentfor

more space-saving convenience in storage.

•Two types of Conference unit microphones are made available and freely interchangeable:

StandardtypeandLongtype.

Produkt Specifikationer

Mærke:	TOA
Kategori:	Ikke kategoriseret
Model:	TS-912
Bredde:	210 mm
Dybde:	152 mm
Højde:	68.6 mm
Vægt:	570 g
Ethernet LAN-porte (RJ-45):	1
Driftstemperatur (T-T):	0 - 40 °C
Indgangsspænding:	24 V
Strøm over Ethernet (PoE):	Ingen
Antal personer:	1 person(er)
Lydforbindelse:	Ja
