Side 1/7
Rubber Pad A
or
Rubber Pad B
or
Rubber Pad A+B
ø 25.4~26 mm Bracket
for ø mm Handlebar25.4~26
2 mm
Allen Key
for ø mm Handlebar31.8~33
3 mm
Allen Key ø 31.8~33 mm Bracket
5˚ 5˚
Copyright © Topeak, Inc. 2015 M-TMS076_77-GB 05/15
WARRANTY
1-year Warranty: All mechanical components against
manufacturer defects only.
Warranty Claim Requirements
To obtain warranty service, you must have your original
sales receipt. Items returned without a sales receipt will
assume that the warranty begins on the date of
manufacture. All warranties will be void if the product is
damaged due to user crash, abuse, system alteration,
modification, or used in any way not intended as described
in this manual.
* The specifications and design are subject
to change without notice.
Please contact your Topeak dealer with
any questions. For USA customer
service call : 1-800-250-3068
www.topeak.com
SOUND SELECTION
SELECTING MODE
ANGLE TOE-IN ADJUSTMENT
2 mm
Allen key
BATTERY CHARGING
The SoundLite USB will be lit GREEN when charging. LED will turn off when battery is Horn Button
fully charged.
The SoundLite USB will be lit RED when the remaining battery power is low. Please On/ Off Button
charge the light as soon as possible.
The SoundLite USB LED will not illuminate if the battery is faulty.
Disconnect the Micro-USB cable from your computer port when the SoundLite USB is removed.
After SoundLite USB is fully charged, unplug the USB cable.
Do not open light body.
Li-ion battery may take 3 to 5 charging cycles to attain full capacity.
Do not leave battery connected to charge source over 48 hours continuously.
Charging with USB hub will take longer.
After long periods of non-use, the battery will lose charge. Always charge the battery fully before
each use and storage.
Maintain the battery by charging it every two months and storing it in a cool, dry place to prevent
from decreasing its lifespan.
Safely and properly dispose of the old Li-ion batteries according to your local regulations.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
Open Micro USB Port Cap Standard charging time
4~5 hours (approx)
USB
To computer USB port
or USB charger
Micro USB
WARNING
• SOUNDLITE USB has sensor which can connect with WIreless Remote Control
(optional accessory, includes in TMS077 series). The sensor will be turn off in
original setting.
• Press and hold Light
Button for 5 secs to
turn light sensor on/off.
• This product might be interfered by wireless communication transmission
equipment (ex. cellphone, radio or WiFi, etc) or high power electrical equipment
(ex. computer or electrical device). To extend battery life, turn off sensor when not
in use.
• Pacemaker users should never use this device.
• Volume output of SoundLite may be affected by water. Normal volume output will
resume when unit has dried.
• Although SoundLite USB is water-resistant (under normal weather conditions of
rain, etc.) never intentionally submerge it underwater.
• For ultimate safety, the SoundLite USB should be used in conjunction with a
specific night riding light.
• In addition to its brightness, the beam is widely diffused. In case you need to use
this light on public roads, be sure to adjust the angle downward so as not to blind
oncoming traffic.
SPECIFICATIONS
Function : 0.6W Constant / Blinking
Burn Time : 4 hr. / 30 hr.
Luminous : 70 Lumens / 28 Lux/5M
Lamp : 0.2W LED x 3
Horn : 75-97 dB, 3W speaker, 4 sounds
Battery : 3.7V 600 mAh Lithium Ion
Charge : USB power supply 5V 500 mA
Weight : 58 g / 2.05 oz.
Reserve Time : 0.5 hr.
On-Off, mode selection
button
ø 25.4~26 mm Bracket
Rubber Pad B
Rubber Pad A
USB-Micro USB Cable
(Allows charging from
computer or USB charger)
0.6W
Constant
Off
Blinking
Handlebar Mount
(ø 31.8~33 mm Bracket)
Press and hold the Horn Button until
the light has blinked times.6
Press the Light Button
to select sound.
If no button is
pressed within 5
sec, the last sound
chosen will be set.
Low Battery Power
Indicator
User's Guide
SOUNDLITE USB
USB-Micro USB Cable
Horn, sound selection
button (4 sounds)
2 mm Allen Key x 1
3 mm Allen Key x 1
GB
Press the Horn Button
several times to test
the sound you selected.
Bird 1
The light will blink and
horn will sound times 2
to confirm setting.
Bird 2 Bike Bell Horn
Micro USB
Port Cap
INSTALLATION OF HANDLEBAR MOUNT
Press release button
to remove the light.
PRESS
5 secs
