MG04A xxx – HD – CA Enterprise Capacity D Product Overview

Rev. 00

HDD

MAIN SPECIFICATIONS

RELIABILITY

Model Number MG04ACA600E

MG04ACA600A

MG04ACA50DE

MG04ACA50DA

MG04ACA500E

MG04ACA500A

MG04ACA400E

MG04ACA400A

MG04ACA300E

MG04ACA300A

MG04ACA200E

MG04ACA200A

Interface SATA-2.6 / 3.0 ( 6.0 Gbit/s , 3.0 Gbit/s , 1.5 Gbit/s )

Formatted Capacity 6 TB 5 TB 4 TB 3 TB 2 TB

Performance

Interface Speed

6.0 Gbit/s Max.

Rotation Speed

7,200 rpm ±0.1 %

Average Latency

Time

4.17 ms

Buffer Size

128 MiB

Data Transfer Speed

(Sustained)

205 MiB/s 185 MiB/s 175 MiB/s

Logical ata D

B L lock ength

HOST -

MG04ACAxxxE

512 B ( emulation )

HOST -

MG04ACAxxxA

4,096 B

DISK B 4,096

Supply

Voltage

Allowable Voltage 5 V ± 5%

12 V ± 5 %

Power

Consumption

Read / Write

11.3 W Max.

Low Power Idle

6.0 W Typ.

Model Number MG04ACAxxx

MTTF

1,400,000 hours

Non-recoverable Error Rate

10 errors per 1016 bits read

24 x 7 Operation

Yes

Workloads

550 TB/y

APPLICATIONS

• Engineered for Mid-Line / Nearline Business Critical Workloads

• Tier 2 Business and Storage Systems-Critical Servers

• Servers Supporting Application Workloads that Benefit from Large Capacity per Spindle

• Capacity-Optimized Data Center Storage Systems

KEY FEATURES

• Industry Standard 3.5 inch 26.1 mm Height Form Factor-

• Large-Capacity (6 / 5 / 4 / 3 / 2 TB models)

• 7,200 rpm Performance

• SATA 6.0 Gbit/s Interface

• 550 Total TB Transferred per Year Workload Rating

• 512e or 4Kn Advanced Format Sector Technology

• (512e Model and 6TB Model) Introducing Toshiba Persistent Write Cache

Technology for Data Loss Protection in Sudden Power- -Loss Events

MG04A CAxxx SERIES

ENTERPRISE CAPACITY HDD

Product image may represent a design model.

2 2/

MG04A xxx – HD – CA Enterprise Capacity D Product Overview

Rev. 00

ENVIRONMENTAL LIMITS

MECHANICAL SPECIFICATIONS

E F NVIRONMENTAL EATURE

Definition of capacity: Toshiba defines a megabyte (MB) as 1,000,000 bytes, a gigabyte (GB) as 1,000,000,000 bytes and a terabyte (TB) as 1,000,000,000,000 bytes. A computer operating

system, however, reports storage capacity using powers of 2 for the definition of 1GB = 2

= 1,073,741,824 bytes and therefore shows less storage capacity. Available storage capacity

(including examples of various media files) will vary based on file size, formatting, settings, software and operating system, such as Microsoft Operating System and/or pre installed software -

applications, or media content. Actual formatted capacity may vary.

A kibibyte (KiB) means 2

10, or 1,024 bytes, a mebibyte (MiB) means 2

20, or 1,048,576 bytes, and a gibibyte (GiB) means 2

30, or 1,073,471,824 bytes.

MTTF (Mean Time to Failure) is not a guarantee or estimate of product life; it is a statistical value related to mean failure rates for a large number of products which may not accurately reflect

actual operation. Actual operating life of the product may be different from the MTTF.

Toshiba Semiconductor & Storage Products Company defines "RoHS Compatible" products as products that either (i) contain no more than a maximum concentration value of 0.1% by weight -

in Homogeneous Materials for lead, mercury, hexavalent chromium, polybrominated biphenyls (PBBs) and polybrominated diphenyl ethers (PBDEs) and of 0.01% by weight in Homogeneous

Materials for cadmium; or (ii) fall within any of the application exemptions set forth in the Annex to the RoHS Directive (Di 011/65/EC of the European Parliament and of the Council of rective 2

2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment). "Homogeneous Material" means a material of uniform composition that cannot be

mechanically disjointed (meaning separated, in principle, by mechanical actions such as unscrewing, cutting, crushing, grinding and/or abrasive processes) into different materials. Examples of

"Homogeneous Materials" would be individual types of plastics, ceramics, glass, metals, alloys, paper, board, resins and coatings.

Read and write speed may vary depending on the host device, read and write conditions, and file size.

"2.5- -inch" and "3.5 inch" mean the form factor of HDDs or SSDs. They do not indicate drive's physical size.

Subject to Change: While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications, configurations, and

availability are all subject to change without notice.

Before creating and producing designs and using, customers must also refer to and comply with the latest versions of all relevant TOSHIBA information and the instructions for the application

that Product will be used with or for.

PWC (Persistent Write Cache) with PLP (Power Loss Protection) : PWC with PLP is a function to handle the write data that the drive reports "Normal completion" to the host but not being

stored to hard disk media yet. The write data may be written to the commanded LBA on the hard disk media. The un written data to hard disk media is stored to Flash memory using back up -

power by PLP when the power supply to the drive suddenly is shut down. And, after PLP operation, it may be required more time to start up the drive than in case of normal shutdown. 1) PLP

does not secure data in the mode of all the power shutdowns. When power supplies other than recommended procedure are intercepted, data might be lost. 2) In the power shutdown before it

reports on the Write completion, data not anticipated might be lost.

Model Number

MG04ACA600E

MG04ACA600A

MG04ACA50DE

MG04ACA50DA

MG04ACA500E

MG04ACA500A

MG04ACA400E

MG04ACA400A

MG04ACA300E

MG04ACA300A

MG04ACA200E

MG04ACA200A

Height

26.1 mm Max.

Width

101.6 mm ± 0.25 mm Max.

Length

147 mm Max.

Weight 770 g Max.

MG04ACA50DE/A

770 g Max.

MG04ACA500E/A

720 g Max.

Item Specification

Temperature

Operating

5 °C °C to 55

Non-O perating

- °C 40 °C to 70

Humidity

Operating

5 0 % to 9 % R.H. (No condensation)

Non-O perating

5 % to 95 % R.H. (No condensation)

Shock

Operating

686 m/s

{ 70 G } ( 2 ms duration )

Non-O perating 2,940 m/s

{ 300 G } ( 2 ms duration )

Vibration Operating

7.35 m/s2 { 0.75 G } ( 5 to 300 Hz )

2.45 m/s

{ 0.25 G } ( 300 to 500 Hz )

Non-O perating

49 m/s

{ 5.0 G } ( 5 to 500 Hz )

Altitude Operating - m -305 to +3,048 m { 1,000 to +10,000 feet }

Non-O - m -perating 305 to +12,192 m { 1,000 to +40,000 feet }

Model Number MG04ACAxxx

RoHS

Compatible

Produkt Specifikationer

Mærke:	Toshiba
Kategori:	Harddisk
Model:	MG04ACA400A
Type:	HDD
Bredde:	101.6 mm
Dybde:	147 mm
Højde:	26.1 mm
Vægt:	720 g
Brugervejledning:	Ja
Opbevaringstemperatur (T-T):	-40 - 70 °C
Driftstemperatur (T-T):	5 - 55 °C
Antal:	1
Hurtig start guide:	Ja
Certificering:	RoHS compliant
HDD kapacitet:	4000 GB
Harmoniseret systemkode (HS):	84717050
Understøttede Windows-operativsystemer:	Ja
Understøttede Mac-operativsystemer:	Ja
Understøttede Linux-operativsystemer:	Ja
Andre understøttede operativsystemer:	Ja
Grænseflade:	Serial ATA III
Driftsspænding:	5 / 12 V
Gennemsnitstid mellem fejl (MTBF):	1400000 t
Strømforbrug (læse):	11.3 W
Strømforbrug (skrive):	11.3 W
HDD-størrelse:	3.5 "
HDD hastighed:	7200 rpm
Driftsvibrationer:	0.25 G
Ikke-drift vibration:	5 G
Stød under drift:	70 G
Gennemsnitlig ventetid:	4.17 ms
Ikke-drift stød:	300 G
Lagringsdrev buffer størrelse:	128 MB
Strømforbrug (inaktiv):	6 W
Start/stop-cyklusser:	600000
Overførselshastighed for HDD-grænseflade:	6 Gbit/sek.
Skriv søgetid:	8.5 ms
Læs søgetid:	9.5 ms
Bytes pr. sektor:	4096
HDD vedvarende overførselshastighed:	185 MiB/s
