Could-Scale Capacity HDD MG09 Series Product Manual

MG09 SERIES

CLOUD-SCALE CAPACITY HDD

The MG09 Series provides 18 TB

[1]

of conventional magnetic recording (CMR) capacity.

The industry-standard 3.5-inch

[2]

form-factor provides 7200 rpm performance, and

integrates easily into cloud-scale storage infrastructure, business-critical servers and

storage, and File and Object storage solutions.

Toshiba’s leadership in precision industrial laser welding technology is put to use to

permanently seal helium inside the 9-disk mechanics. The helium-sealed design reduces

aerodynamic drag to significantly lower the drive’s operational power profile, which helps

deliver critical TCO benefits for data center infrastructures. The sealed design and

corrosion resistant electronics also mitigate against life-time failure modes due to air bourn

pollutants and other environmental factors.

The massive 18 TB CMR capacity is delivered using Toshiba’s innovative Flux Control

Microwave Assisted Magnetic Recording (FC-MAMR) technology. These advances help the

MG09 Series to achieve optimum storage capacity and application compatibility, with

unsurpassed data reliability. Available with either a SATA 6.0 Gbit/s or a 12.0 Gbit/s SAS

interface

[3]

, the MG09 Series models integrate easily into standard 3.5-inch drive bays to help

reduce the footprint and operational burden of cloud-scale storage infrastructure, File and

Object storage systems, and business critical servers and storage systems.

KEY FEATURES

• 18/16/14/12/10 TB capacity

• Conventional Magnetic Recording (CMR) for broad

compatibility

• Toshiba Flux Control Microwave-assisted Magnetic

Recording (FC-MAMR) Technology

• Industry-leading 9-disk helium-sealed design for superior

storage density

• Industry Standard 3.5-inch 26.1 mm height Form Factor

• 7200 rpm Performance

• Choice of SATA 6.0 Gbit/s and 12.0 Gbit/s SAS Interfaces

• Lower operational power profile, providing excellent power

efficiency (W/TB) for better TCO

• 550 Total TB Transferred per Year Workload Rating

[4]

• 512e or 4Kn Advanced Format Sector Technology; (512e

Model) Includes Toshiba Persistent Write Cache Technology

for Data-Loss Protection in Sudden Power-Loss Events

• Sustained transfer rate and power efficiency improvements

vs. prior MG Series generations

• Sanitize Instant Erase (SIE) option model and Self

Encrypting Drive (SED) option model

[5]

• Support FFMT (Fast Format) for SAS

APPLICATIONS

• Cloud-scale Sever and Storage Infrastructure

• Software-defined data center infrastructure

• File- and Object-based storage infrastructure

• Tiered Storage Infrastructure Solutions

• Workloads and Use-Cases that Benefit from High Capacity

per Spindle disk drives

• Capacity-Optimized Cloud-scale and Rack-Scale Storage

Systems

• Compliance Data Archives and Data Life-Cycle Management

Storage Systems

• Data Center Data-Protection and Data Back-up

Infrastructure

Product image may represent a design model.

2 / 18

Could-Scale Capacity HDD MG09 Series Product Manual

SPECIFICATION

Item

MG09ACA18T

MG09ACP18T

MG09ACA16T

MG09ACP16T

MG09ACA14T

MG09ACP14T

MG09ACA12T

MG09ACP12T

MG09ACA10T

MG09ACP10T

Interface SATA-3.3

Formatted Capacity 18 TB 16 TB 14TB 12 TB 10 TB

Performance

Interface Speed

[3]

6.0 Gbit/s, 3.0 Gbit/s, 1.5 Gbit/s

Rotation Speed 7200 rpm

Buffer Size 512 MiB

[7]

Maximum Sustained

Data Transfer Speed

268 MiB/s

[7]

Logical Data

Block Length

MG09ACAxxxA/AY

4096 B

MG09ACPxxxA

MG09ACAxxxE/EY

[8]

HOST: 512 B, DISK 4096 B

MG09ACPxxxE

[8]

Supply

Voltage

Allowable Voltage 12 V

[9]

±10 % / 5 V

[9]

+10 % / -7 %

[10]

Power

Consumption

Write / Read

( 4KB Q1 ) (Typ.)

8.35W 7.96W 7.43W

Active Idle (Typ.) 4.16 W 3.77W 3.30W

Acoustics

[1２]

Active Idle (Typ.) 20 dB

Item

MG09SCA18T

MG09SCP18T

MG09SCA16T

MG09SCP16T

MG09SCA14T

MG09SCP14T

MG09SCA12T

MG09SCP12T

MG09SCA10T

MG09SCP10T

Interface SAS-3.0

Formatted Capacity 18 TB 16 TB 14TB 12 TB 10 TB

Performance

Interface Speed

[3]

12.0 Gbit/s, 6.0 Gbit/s, 3.0 Gbit/s, 1.5 Gbit/s

Rotation Speed 7200 rpm

Buffer Size 512 MiB

Maximum Sustained

Data Transfer Speed

[6]

268 MiB/s

Logical Data

Block Length

MG09SCAxxxA/AY

4096 B / 4160 B / 4224 B

MG09SCPxxxA

MG09SCAxxxE/EY

[8]

HOST: 512 B, DISK 4096 B

HOST: 520 B, DISK 4160 B

HOST: 528 B, DISK 4224 B

MG09SCPxxxE

[8]

Supply

Voltage

Allowable Voltage 12 V

[9]

±10 % / 5 V

[9]

+10 % / -7 %

[10]

Power

Consumption

Write / Read

( 4KB Q1 )

(Typ.)

8.71 W 8.40 W 7.95 W

Active Idle (Typ.) 4.49 W 4.25 W 3.76 W

Acoustics

[11]

Active Idle (Typ.) 20 dB

Produkt Specifikationer

Mærke:	Toshiba
Kategori:	Harddisk
Model:	MG09SCA18TE
Type:	HDD
Bredde:	101.85 mm
Dybde:	147 mm
Højde:	26.1 mm
Vægt:	720 g
Opbevaringstemperatur (T-T):	-40 - 70 °C
Relativ luftfugtighed ved drift (H-H):	5 - 90 %
Relativ luftfugtighed ved opbevaring (H-H):	5 - 95 %
Strømforbrug (typisk):	8.74 W
Driftstemperatur (T-T):	5 - 55 °C
HDD kapacitet:	18000 GB
Harmoniseret systemkode (HS):	84717050
Driftshøjde:	-305 - 3048 m
Ikke-drift højde:	-305 - 12192 m
Grænseflade:	SAS
Komponent til:	NAS
HDD-størrelse:	3.5 "
HDD hastighed:	7200 rpm
Driftsvibrationer:	0.75 G
Ikke-drift vibration:	3 G
Stød under drift:	70 G
Støjniveau (tomgang):	20 dB
Ikke-drift stød:	250 G
Lagringsdrev buffer størrelse:	512 MB
Strømforbrug (inaktiv):	4.54 W
Hot-swap:	Ingen
Start/stop-cyklusser:	600000
Overførselshastighed for HDD-grænseflade:	12 Gbit/sek.
Middeltid til fejl (MTTF):	2500000 t
HDD vedvarende overførselshastighed:	268 MiB/s
Arbejdsbelastningsgrænse:	550 TB/år
24/7 drift:	Ja
