Side 1/4

Simple and Reliable Way

to Overcome the Distance

Limitations

Surveillance | Enterprise | Factory | Park |

WISP | Machine Room | and More

Media Converters and SFP/SFP+ Modules

Simple and Reliable Way to Overcome the Distance Limitations

Machine Room

TP-Link Fast Ethernet Media Converters are designed to address the needs of exible long-range surveillance

deployment with optical bers. It provides an economical path towards extending the distance of an existing network.

TP-Link oers 100 Mbps and 1000 Mbps media converters to realize reliable network connections, making the

long-distance network deployments of surveillance cameras in businesses, factories, and parks simpler.

Flexible Selections of Distance and Speed

A wide range of media converters are available, oering

dierent maximum transmission distances of between 2 km to

20 km. Dierent speeds provide exible deployment options.

Stable Network Transmission

The stability of ber transmission guarantees our stable

monitoring of sensitive areas and point-to-point

connections.

Enterprise Surveillance Park Surveillance Campus Surveillance

Ideal for Flexible Surveillance Deployment

Fiber Ethernet Cable (Power and Data) Ethernet Cable (Data Only) IP Cameras

Media Converter

IP Cameras

Media Converter

Chassis

Switch

NVR

PoE Switch

Cost Eective Solution with WDM*

WDM (Wave Division Multiplexing) technology enables you to

transmit and receive data over one single ber strand instead

of two.

Innovative Combination of PoE and Fiber**

The PoE output port of media converter provides a direct

data and power connection to the IP camera, making

remote camera deployment easier and more convenient.

Product Picture

Model MC100CM MC110 MC111 MC112CS CS CS TL-F AC111 -20 TL-F BC111 -20 TL-FC111PB-20

Power Input 9V/0.6A 5V/0.6A 48V/0.5A

Fiber Ports 2× 100 Mbps iber SC F Ports 1× 100 Mbps iber SC F Port

Copper Ports 1× 10/100 Mbps RJ45 Port RJ45 Port1× 10/100 Mbps

Transmission Diatance 2 km 20 km 20 km

Fiber Type Multi-Mode Singl Single-Mode e-Mode

Fiber Number Dual ibers Single F Fiber Single iberF

Wave Length 1310 nm TX: 1550 nm

RX: 1310 nm

TX: 1310 nm

RX: 1550 nm

TX: 1550 nm

RX: 1310 nm

TX: 1310 nm

RX: 1550 nm

TX: 1310 nm

RX: 1550 nm

Dimensions (W × D × H) 3.7×2.9×1.1 in (94.5×73.0×27.0 mm)

Operating Temperature 0–40˚C (32–104˚ ) 0–50˚C (32–122 ˚ )F F

Environment Storage Tempe atur re: -40–70˚C (-40–158˚ )F

Oper t -Condensing; Stor t -Condensingating Humidi y: 10–90% RH Non age Humidi y: 5–90% RH Non

TP-Link 100 Mbps Media Converters at a Glance

1× 100 Mbps SC F iber Port

1× 10/100 Mbps

RJ45 PoE Port

100 Mbps Media Converters Benet Flexible Surveillance

Produkt Specifikationer

Mærke:	TP-Link
Kategori:	Ikke kategoriseret
Model:	TL-SM5110-SR
Produktfarve:	Sølv
Opbevaringstemperatur (T-T):	-40 - 80 °C
Relativ luftfugtighed ved drift (H-H):	10 - 90 %
Relativ luftfugtighed ved opbevaring (H-H):	5 - 90 %
Driftstemperatur (T-T):	0 - 70 °C
Certificering:	FCC, CE
Harmoniseret systemkode (HS):	85369010
Indgangsspænding:	3.3 V
Maksimal dataoverførselshastighed:	10000 Mbit/s
SFP modtagertype:	Fiberoptisk
Grænsefladetype:	SFP+
Fiber optisk strømstik:	LC (UPC)
Fiber kabeldiametre understøttes (kerne/beklædning):	50/125, 62.5/125 µm
Multitilstand fiber (MMF) understøttet:	Ja
Maksimal overførselsafstand:	300 m
Bølgelængde:	850 nm
Hot-swap:	Ja
Digital diagnose overvågning (DDM):	Ja
