introduction

Thank you for purchasing the Traxxas TRX-4 with the 1979

Chevrolet Blazer Body Kit. This ofﬁcially licensed model gets

the full Traxxas treatment with unsurpassed realism, including

molded chrome grill, side mirrors, door handles, and bumpers. The

design of the TRX-4 instantly obsoletes the status quo with greatly

expanded features and versatility. The TRX-4 features the powerful

Titan® 21T 550 motor, waterproof electronics, and a smooth XL-5

HV 3s LiPo-capable electronic speed control. The game-changing

portal axles provide greater ground clearance while the rigid steel

frame eliminates chassis ﬂex and allows you to navigate tough

terrain. The Canyon Trail 1.9 tires feature tuned foam inserts to

deliver superior bite on rocky surfaces. In other words, we built it

the Traxxas way -- rugged, powerful, and ready to handle the rigors

of remote locations and all-day driving fun!

This manual contains the instructions you will need to operate and

maintain your model so that you can enjoy it for years to come.

We want you to feel conﬁdent that you own one of the best-

performing models in the market and that it is backed by a team

of professionals who aim to provide the highest level of factory

support possible. Traxxas models are about experiencing total

performance and satisfaction, not just with your model, but also

with the company that stands behind it.

We know you’re excited about getting your new model on the trail,

but it’s very important that you take some time to read through the

Owner’s Manual. This manual contains all the necessary setup and

operating procedures that allow you to unlock the performance

and potential that Traxxas engineers designed into your model.

Even if you are an experienced R/C enthusiast, it’s important to

read and follow the procedures in this manual.

Thank you again for going with Traxxas. We work hard every day

to assure you the highest level of customer satisfaction possible.

We truly want you to enjoy your new model!

Traxxas Support

Traxxas support is with you every step of the

way. Refer to the next page to ﬁnd out how to

Quick Start

This manual is designed with a Quick

Start path that outlines the necessary

procedures to get your model up

and running in the shortest time possible. If you are an

experienced R/C enthusiast, you will ﬁnd it helpful and fast.

Be sure and read through the rest of the manual to learn

about important safety, maintenance, and adjustment

procedures. Turn to page 10 to begin.

REGISTERING YOUR MODEL

In order to serve you better as our customer, please

online at Traxxas.com/register.

T r a x x a s . c o m / r e g i s t e r

FCC Compliance

This device contains a module that complies with the limits for a Class B digital device as described in part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This

device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

The limits for a Class B digital device are designed to provide reasonable protection against harmful interference in residential settings. This product generates, uses and can radiate radio

frequency energy, and, if not operated in accordance with the instructions, may cause harmful interference to radio communications. The user is cautioned that changes or modiﬁcations

not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

Canada, Industry Canada (IC)

This Class B digital apparatus complies with Canadian ICES-003 and RSS-210. This device complies with Industry Canada license exempt RSS standard(s). Operation is subject to the

following two conditions: This device may not cause interference, and This device must accept any interference, including interference that may cause undesired operation of the device.

Radio Frequency (RF) Exposure Statement

This equipment complies with radio frequency exposure limits set forth by FCC and Industry Canada for an uncontrolled environment. This equipment should be installed and

operated with a minimum distance of 20 centimeters between the radiator and your body or bystanders and must not be co-located or operating in conjunction with any other

antenna or transmitter.

Operation Frequency: 2414~2453 MHz

Maximum Radio Frequency Power: Maximum Peak Power 9.7 dBm

Produkt Specifikationer

Mærke:	Traxxas
Kategori:	Radiostyret legetøj
Model:	TRX-4 Blazer
Bredde:	249 mm
Højde:	255 mm
Vægt:	1:10
Motortype:	Elektrisk motor
Produkttype:	Firhjulstrækker
Antal:	1
Antal understøttede batterier:	1
Længde:	524 mm
Lyseffekter:	Ja
Forhjul, diameter:	49 mm
Baghjul, diameter:	49 mm
Antal kanaler:	4 kanaler
Konstruktionstype:	Klar til at løbe (RTR)
Husets farve:	Orange
Batterier påkrævet:	Ja
Egnet til udendørs brug:	Ja
Lejeteknologi:	Kugleleje
Kompatible batteristørrelser:	AA
Drevtype:	4-hjuls træk (4WD)
Elektronisk hastighedskontrol (ESC):	Ja
Stel materiale:	Nylon
Originalt modelnavn:	Blazer
Antal batterier (sender):	4
Akselafstand:	312 mm
Kopi:	Ja
Bevægelseskontrolfunktioner:	Backward, Forward, Turn left, Turn right
Indbygget servo:	Ja
Senderfrekvens:	2.4 GHz
Originalt mærkenavn:	Chevrolet
Afstand:	80 mm
Affjedring:	Ja
Dæk bredde (for):	48 mm
Dæk bredde (bag):	48 mm
Indbygget kontroller:	Ja
Dæk diameter:	118 mm
