Owner’s Manual

Reliable Emergency Backup Power

Congratulations! You’ve purchased the most advanced, feature-rich Inverter/Charger designed as an alternative energy source during utility

power failures. Tripp Lite APS Inverter/Chargers keep your equipment constantly up and productive through all utility power problems (blackouts,

brownouts and high voltages) by inverting DC power from user-supplied batteries into AC power. Built-in surge suppression provides an additional

level of equipment protection. When utility power is present, APS Inverter/Chargers automatically pass through power to your equipment while

simultaneously recharging your connected battery bank. APS Inverter/Chargers are the quiet alternative to gas generators during emergency

backup applications—with no fumes, fuel or noise to deal with! You get AC electricity anywhere and anytime you need it.

Better for Your Equipment Premium Protection Levels

• Built-In Isobar

Surge Protection

• Automatic Overload Protection

Ideal Output for All Loads (including computers)

• Frequency-Controlled Output

• Fast Load Switching

• Balanced Load Sharing*

Better for Your Batteries Faster Battery Recharge

• High-Amp, 3-Stage Battery Charger (adjustable)

Critical Battery Protection

• Battery Charge Conserver (Load Sense)*

• Battery Temperature Sensing*

• High-Efficiency DC-to-AC Inversion

Better for You Simple, Maintenance-Free Operation

• Multi-Function Lights & Switches

• Moisture-Resistant Construction**

Specifications 2

Safety 3

Feature Identification 4

Operation 5

Configuration 6-7

Battery Selection 8

Mounting 9

Battery Connection 10

AC Input/Output Connection 11

Service/Maintenance 11

Troubleshooting/Warranty 12

Español 13

PowerVerter

APS Series

DC-to-AC Inverter/Chargers

Input Output

Invert: 12, 24, 36 or 48 VDC 120V, 60 Hz. AC

Charge: 120V, 60 Hz. AC 12, 24, 36 or 48 VDC

1111 W. 35th Street, Chicago, IL 60609 USA

Customer Support: (773) 869-1234

www.tripplite.com

* Available on all models except 612 models. ** Inverter/Chargers are moisture-resistant, not waterproof.

Contents

WARRANTY

REGISTRATION

to win a FREE Tripp Lite product!

www.tripplite.com/warranty

200711151 93-2751 120V APS OM.qxd 11/29/2007 2:47 PM Page 1

Specifications

Note on Labeling

Two symbols are used on the APS labels.

V~: AC Voltage : DC Voltage

Inverter/Charger DC Volt: 48

Wire Gauge

Watts 10 8 6 4 2

500 98 ft 156 ft 248 ft 394 ft 626 ft

700 70 ft 111 ft 177 ft 281 ft 447 ft

1000 49 ft 78 ft 124 ft 197 ft 313 ft

2000 25 ft 39 ft 62 ft 99 ft 157 ft

2400 20 ft 32 ft 52 ft 82 ft 131 ft

Inverter/Charger DC Volt: 24

Wire Gauge

Watts 8 6 4 2 0

500 39 ft 62 ft 99 ft 157 ft 249 ft

700 28 ft 44 ft 70 ft 112 ft 178 ft

1000 19 ft 31 ft 49 ft 78 ft 125 ft

2000 10 ft 15 ft 25 ft 39 ft 62 ft

2400 8 ft 13 ft 21 ft 33 ft 52 ft

3000 6 ft 10 ft 16 ft 26 ft 42 ft

Inverter/Charger DC Volt: 12

Wire Gauge

Watts 6 4 2 0 00 (2/0)

500 15 ft 25 ft 39 ft 62 ft 79 ft

700 11 ft 18 ft 28 ft 44 ft 56 ft

1000 8 ft 12 ft 20 ft 31 ft 39 ft

2000 4 ft 6 ft 10 ft 16 ft 20 ft

Minimum Recommended Cable Sizing Charts

†

Use in conjunction with DC wiring connection instructions in the Battery Connection section.

† NOTE: Acceptable power is directly related to cable length (i.e. - the shorter the cable, the better the performance)

MODEL NUMBER: APS612 APS1012 APS1524 APS2012 APS2424 APS2448 APS3624VR APS3636VR

AC Input Connection: Input Cord Input Cord Hardwire Hardwire Hardwire Hardwire Hardwire Hardwire

INVERTER

Common Specifications for All Models

• Output Volts (Nominal): 120 VAC, ± 5% • Output Frequency (Nominal): 60 Hz, ± 0.5% • Efficiency: 88% to 94%, depending on load and temperature

Select Tripp Lite Inverter/Chargers include a Battery Charge Conserver (Load Sense) Control which saves battery power by allowing users to set the minimum load level

at which the unit’s inverter turns on. Users can significantly reduce the No Load DC Input Current to a very low amp level with the use of this control.

Continuous Power (@ 20 C): 600 1000 1500 2000 2400 2400 3600 3600

OverPower™ Peak Surge Power:* 900 1500 2250 3000 3600 3600 5400 5400

Double Boost™ Peak Surge Power:* 1200 2000 3000 4000 4800 4800 7200 7200

DC Input Volts (Nominal): 12 VDC 12 VDC 24 VDC 12 VDC 24 VDC 48 VDC 24 VDC 36 VDC

DC Input Voltage Range: 10-15 VDC 10-15 VDC 20-30 VDC 10-15 VDC 20-30 VDC 40-60 VDC 20-30 VDC 30-45 VDC

Minimum DC Fuse Rating: 100 A 225 A 125 A 400 A 300 A 100 A 300 A 300 A

DC Input Current @ Nominal V DC

Full Load 56 A 95 A 70 A 192 A 112 A 56 A 170 A 114 A

BATTERY CHARGER

Common Specifications for All Models

• Input Volts (Nominal): 120 VAC

Charging Capacity DC: 20 A 55 A/14 A** 36 A/9 A** 100 A/25 A** 55 A/14 A** 15 A/off** 65 A/16 A** 30 A

Acceptance Volts VDC: 14.4 V/14.2 V 14.4 V/14.2 V 28.8 V/28.4 V 14.4 V/14.2 V 28.8 V/28.4 V 57.6 V/56.8 V 28.8 V/28.4 V 43.2 V/42.6 V

Selectable (Wet**/Gel)

Float Volts VDC (w/gel): 13.3 V (13.6 V) 13.3 V (13.6 V) 26.6 V (27.2 V) 13.3 V (13.6 V) 26.6 V (27.2 V) 53.2 V (54.4 V) 26.6 V (27.2 V) 39.9 V (40.8 V)

Input Current AC (Maximum): 4.2 A 11.5 A 16 A 21 A 24 A 13.3 A 29 A 20 A

LINE VAC OPERATION

Common Specifications for All Models

• Minimum Input Volts (Transfer to Battery): Selectable 75,** 85, 95 or 105 VAC • Maximum Input Volts (Transfer to Battery): Selectable 135** or 145 VAC • Input Frequency (Nominal): 60 Hz, ±10%

Total Input AC Current

(Continuous, Charger at Maximum): 9.2 A 12 A 29 A 38 A 44 A 33 A 59 A 50 A

Maximum Output

Current (Continuous): 5 A 8.3 A 12.5 A 16.7 A 20 A 20 A 30 A 30 A

* OverPower duration (up to 1 hour). DoubleBoost duration (up to 10 seconds). Actual duration depends on battery age, battery charge level and ambient temperature. ** Factory setting.

The policy of Tripp Lite is one of continuous improvement. Specifications are subject to change without notice.

Inverter/Charger DC Volt: 36*

Wire Gauge

Watts 8 6 4 2 0

700 63 ft 100 ft 158 ft 252 ft 400 ft

1000 44 ft 70 ft 111 ft 176 ft 280 ft

2000 22 ft 35 ft 55 ft 88 ft 140 ft

2400 18 ft 29 ft 46 ft 73 ft 117 ft

3000 15 ft 23 ft 37 ft 59 ft 93 ft

3600 12 ft 19 ft 31 ft 49 ft 78 ft

* If your model accepts 4 conductors, simply double the acceptable cable lengths.

200711151 93-2751 120V APS OM.qxd 11/29/2007 2:47 PM Page 2

Produkt Specifikationer

Mærke:	Tripp Lite
Kategori:	Batteri
Model:	APS2424
Bredde:	215.9 mm
Dybde:	412.8 mm
Højde:	184.2 mm
Vægt:	17690 g
Produktfarve:	Sort
Pakkevægt:	19960 g
Pakkedybde:	543.6 mm
Pakkebredde:	375.9 mm
Pakkehøjde:	327.7 mm
Dimensioner (BxDxH):	215.9 x 412.8 x 184.2 mm
Udgangseffekt:	2400 W
Udgangsspænding:	120 V
Harmoniseret systemkode (HS):	8504.40.9570
Indgangsspænding:	24 V
Hovedkassen højde (udvendigt):	327.7 mm
Hovedkassens længde (udvendigt):	543.6 mm
Hovedkassens bruttovægt (udvendigt):	19960 g
Hovedkassens bredde (udvendigt):	375.9 mm
Oprindelsesland:	Kina
Produkter pr. hovedkasse (udvendigt):	1 stk
Indgangsfrekvens:	60 Hz
Effektivitet:	90 %
