For more products, accessories, and our support

knowledge base, visit www.turtlebeach.com

Operating Instructions

Connecting to PC

Voice Chat plus Game Audio

Configuring Xbox Settings

The X1 headphones can also be used as

a powered headset and microphone for

PC gaming or VoIP.

Step 1:

Connect the X1's green 1/8"

jack to the speaker output of

your PC's sound card.

Step 2:

Connect the X1's

pink 1/8" jack to

the microphone

input of your PC's

sound card.

Step 3:

Connect the X1's USB/Power

jack to an open USB port on

your PC to power the X1.

IMPORTANT: In order to hear

other players you must make sure that

the following is set from the Xbox 360

dashboard.

1. From the Xbox 360 Dashboard,

press the Xbox Guide button

(the X button in the center of your

controller) to access your Xbox

Live Settings.

2. Navigate to the "Personal

Settings" selection, and press the

"A" button on your controller.

3. Select "Voice" from the following

menu, and press "A".

4. On the Voice screen, make sure

that "Play Through Headset" is

selected for Voice Output selection

and that volume is set to 10

(see below).

5. You can fine tune game audio and

chat volumes using the X1 amplifier

and chat volume controls.

green

1/8" jack

pink 1/8" jack

Optional Power AdapterUsing the Amplifier

The X1 headphones are powered by

USB. If you'd like to use the X1s and

don't have access to a USB port you can

use an optional AC to USB converter.

For more information visit

TurtleBeach.com.

Game Audio Volume:

This dial allows you to control the

amount of amplification that the X1 will

apply to your game audio.

Mic Mute Switch:

This switch will mute your microphone.

Amplifier LED:

When your X1's have power, this LED

will light green. When the Mic Mute

Switch is engaged, your microphone will

be muted and this LED will glow red.

Game Audio

Volume

Xbox Controller

Cable Connection

(on side)

Mic Mute

Switch

Amplifier

LED

Package Contents

• Ear Force X1 headphones

• Transmitter base unit

• USB extender cable

• Xbox controller connection cable

• Audio connection cables

• This user's guide

For warranty information please visit

http://support.turtlebeach.com

Important Information

1. Be careful when turning on the master

volume control on the headphones.

Before placing the headphones over

your ears, set the volume control to

minimum, then slowly increase until you

reach a comfortable level.

2. Like any speakers, overdriving

headphones may cause damage to both

the headphones and your ears. Please

listen at moderate levels.

3. WARNING: Long term exposure to

loud music or other sounds in

headphones may cause hearing

damage. It is best to avoid extreme

volume levels when using headphones,

especially for extended periods. Over

time, your ears adapt to the volume

level, so a level that may not cause

initial discomfort might still damage

your hearing.

About the X1 Headphones

Ear Force X1 amplified headphones give

serious gamers the ultimate competitive

edge by combining Xbox Live chat and

stereo game audio into an immersive

sound experience.

X1's integrated design overcomes the

limitation of communicator headsets

that block game sound from one ear

and eliminates voice chat interference

caused by the headset microphone

picking up sound from external

speakers.

Pump up the volume without disturbing

friends, family or neighbors. Hear every

nuance of the game - from an opponent

sneaking up behind you to your

teammate's voice right next to you.

Trash talk online. Block out distractions.

It's everything you need for an amazing

gaming experience.

reproduced without permission. Turtle Beach, the Turtle

Beach logo and Ear Force are registered trademarks of VTB.

Xbox and Xbox Live are registered trademarks of Microsoft

Corporation. All other trademarks are properties of their

respective companies and are hereby acknowledged.

Product features, visual design, package contents and

specifications are subject to change without notice.

Product# TBS-2055

Connecting the Microphone

The X1 microphone may be used to

communicate with other players during

Xbox Live multi-player gaming sessions.

Use the included cable to connect the

headphones to the Xbox controller.

Connecting the Xbox

Use the included cables to connect the

headphones, Xbox and TV (or sound

system) as shown. This will allow you to

hear the Xbox with either the TV or the

X1 headphones.

Xbox Game Controller

X1 Amplifier

Mic mute button

Step 1:

Video

USB/Power

Splitter

cable

green

1/8" jack

pink 1/8" jack

(PC use only)

Audio

Connect the Xbox audio cables

(red/white) to the X1 splitter

cable (red/white).

Step 3:

Connect the X1

green 1/8" jack to

the 1/8" input on

the splitter cable.

Step 4:

Connect the X1

USB/Power jack to

an open USB port

on the Xbox 360.

Use the included

USB extension

cable if necessary.

Step 2:

Connect the X1 splitter

cable (red/white) to

TV audio input

(red/white).

Insert the "puck" shaped plug

into the headphone jack on

the Xbox game controller.

Use the Mic Mute button on

the X1 amplifier to prevent

your voice from being heard

by other players.

Insert the other end into the

headphone jack on the X1

amplifier.

The volume control on the

"puck" shaped plug may be

used to adjust the volume

of the Xbox Live chat.

Talk back

chat volume

control

Produkt Specifikationer

Mærke:	Turtle Beach
Kategori:	Hovedtelefoner
Model:	Ear Force X1
Vægt:	233 g
Produkttype:	Headset
Volumenkontrol:	Dreje
Impedens:	- ohm (Ω)
Forbindelsesteknologi:	Ledningsført
Kabellængde:	4.87 m
3,5 mm stik:	Ja
Hovedtelefon frekvens:	30 - 20000 Hz
Hovedtelefon følsomhed:	120 dB
Driverenhed:	40 mm
Mikrofon mute:	Ja
Mikrofon frekvens:	50 - 15000 Hz
Stik:	USB
Ørekobling:	Supraaural
Magnet-type:	Neodym
Tilslutning af mikrofon:	3,5 mm
